PARTS LIST
A. Grooming Arm (1)
B. Control Box (1)
C. Remote Control (1)
LED GROOMING ARM INSTRUCTIONS
TP6288 44 • Master Equipment
Foldable LED Grooming Arm Instructions
A
Magnets
Assembly Instructions
1. Unpack the product and take out the LED foldable grooming arm and all the parts.
2. Extend the LED grooming bar in the direction to complete the assembly.
3. The LED grooming arm could be fixed on the table or clamp after extension.
4. The LED grooming arm is ready for use after installation and fastened. (Note: When
the output of the controller is connecting with the input of LED grooming arm, the
tabs of the output (Figure 3) must be aligned with the notches of the input (Figure 2),
and should not be inserted rigidly, or it will lead to non-lighting of the LED bar, as
well as short-circuiting).
®
B
C
T C
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Master equipment TP6288
- Page 1 TP6288 44 • Master Equipment ® Foldable LED Grooming Arm Instructions PARTS LIST A. Grooming Arm (1) B. Control Box (1) C. Remote Control (1) Magnets LED GROOMING ARM INSTRUCTIONS Assembly Instructions 1. Unpack the product and take out the LED foldable grooming arm and all the parts.
- Page 2 CONTROL BOX INSTRUCTIONS Connection Instructions 1. Pull wire gently from bottom of grooming arm. 2. Carefully lineup the notches in the power connectors and gently push together. 3. Screw the threaded sleeve over the connected wires. 4. Use the magnets to attach the Control Box in a safe location onto the grooming table.
- Page 3 12. Avoid using the product in dusty, vibrating and wet environment and in chemical storage place. LIMITED WARRANTY This Master Equipment Foldable LED Grooming Arm is warranted against defective material or workmanship for one year from the date of purchase. Any Master Equipment ® ®...
