BASS & CELLO RACKS
NOTE: These instructions are based on model #M8340KD-AC. These instructions
work for all Bass Rack and Cello Rack models. Product images are for illustrative
purposes only and may differ from actual product. Quantity of hardware may vary
from model to model.
TOOLS NEEDED
Drill
4mm Allen
Wrench
⑦
④
9
⑥
③
①
②
wibenchmfg.com
1-800-242-2303
wibenchmfg.com
4mm Hex
Phillips
Bit
Screwdriver
⑧
10
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
Phillips
Assistance
Drill Bit
PARTS
#
1
2
⑤
3
4
5
6
7
8
9
10
PARTS x QTY
DESCRIPTION x QTY
Lower Brace x 3
Front Rail x 1
Back Rail x 1
Left Side Panel x 1
Right Side Panel x 1
Lower Back Support Rail x 1
Upper Back Support Rail x 1
Neck Holder x 1
Bottom Support Rail x 1
Heavy-Duty Caster w/ Reinforcement Bracket x 4
507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
V042522 Version subject to change
