- Page 1 TS-1 Handheld Digital Pyrometer User Manual © SYSCON Sensors...
-
Page 2: Table Of Contents
TS-1 User Manual Contents Foreword ........................i Before You Start ......................ii List of Figures ......................iii List of Tables ......................iv Introduction ......................1 Specifications ....................... 1 Application ......................2 Setup ........................3 Quick Start ....................... 5 Operating Controls and Indicators ................. 5 Quick Start Procedure ................... - Page 3 TS-1 User Manual Warranty ........................ 20 © SYSCON Sensors...
-
Page 4: Foreword
TS-1 User Manual Foreword Foreword Thank you for purchasing the SYSCON Sensors TS-1 Handheld Digital Pyrometer. This User’s Manual contains useful information about the functions, installation, wiring, operating procedures, safety, and troubleshooting of the TS-1. The user should carefully read and understand the contents of this manual prior to the use of this equipment. -
Page 5: Before You Start
(ESD). When handling, care must be taken so that the devices are not damaged. Damage due to inappropriate handling is not covered by the warranty. ⚠ NOTE Unauthorized repairs of the TS-1 Handheld Digital Pyrometer may damage the product and void the warranty. © SYSCON Sensors... -
Page 6: List Of Figures
List of Figures Figure 1: TS-1 contact block (type S) ................. 3 Figure 2: TS-1 lance assembly (internal wiring exposed for representation only) ... 3 Figure 3: TS-1 front panel with handle ............... 4 Figure 4: Charging indicator status ................12 Figure 5: SYSCON Sensor products for Foundries and Steel Mills ........ -
Page 7: List Of Tables
TS-1 User Manual List of Tables List of Tables Table 1: Thermocouple comparison (types S, R, B, and K) ............. 2 Table 2: Status indicator lights ......................... 5 Table 3: Frequent operating issues ....................... 11 Table 4: Troubleshooting guidelines ....................14 Table 5: Replacement part numbers .................... -
Page 8: Introduction
TS-1 User Manual Introduction Introduction The SYSCON Sensors TS-1 Handheld Digital Pyrometer is a hand-held, battery operated, temperature measuring device for use with compatible expendable thermocouples in molten metals. This portable instrument allows for quick and accurate temperature measurements up to 3300°F, depending on the thermocouple type. -
Page 9: Application
TS-1 User Manual Introduction Application The TS-1 Handheld Digital Pyrometer is used to measure molten metal temperatures for an immersion/batch or continuous mode of operation. The thermocouple type is determined by the temperature range of the molten metal and the desired accuracy. -
Page 10: Setup
TS-1 User Manual Setup Setup The TS-1 Handheld Digital Pyrometer is easy to use and consists of: • Contact Block The thermocouple is installed such that its tip is in electrical contact with the contact block (see Error! Not a valid bookmark self-reference.). The contact block is shielded from high temperatures by a cardboard tube with or without a heat shield. -
Page 11: Figure 3: Ts-1 Front Panel With Handle
Setup • Instrument Housing and Cover Plate The cover plate is the front panel of the TS-1 (see Figure 3) which consists of the LED display, status indicator lights, POWER button and CHARGE jack. The display represents a TS-1 configured for type S thermocouple input for IPTS 48 calibration standard with degrees Fahrenheit (°F) temperature unit. -
Page 12: Quick Start
The TS-1 Handheld Digital Pyrometer automatically turns off the LED display after 60 seconds and completely shuts down after 90 seconds of inactivity. The last temperature measurement reading is saved in memory and will be displayed the next time the TS-1 is turned ON. -
Page 13: Quick Start Procedure
Quick Start Quick Start Procedure 1. Press the POWER button (see Figure 3) to turn ON the TS-1 Handheld Digital Pyrometer. The POWER button is also used to wake up the LED display after 60 seconds of inactivity and to recall the last temperature measurement. -
Page 14: Repeated Temperature Measurement Guidelines
⚠ NOTE Ensure that the thermocouple input type and calibration standard of the TS-1 (IPTS 48 or IPTS 68) matches that of the thermocouple tip used for temperature measurement. Use only Rechargeable NiCad (Nickel Cadmium batteries). Non- rechargeable alkaline batteries can cause damage to the TS-1 and battery charger. -
Page 15: Lance/Immersion Probe Temperature Measurement Guidelines
To get an accurate and reliable reading, SYSCON Sensors recommends the following procedure: 1. Immerse the probe quickly into the molten metal, penetrating the slag as quickly as possible. -
Page 16: Technical Circuit Information
TS-1 Handheld Digital Pyrometer. • LED Display The LED display on the TS-1 uses four one-half inch high LED digits that can be easily read even in high ambient light. The display reads temperature in °F or °C with one- degree resolution. -
Page 17: Maintenance
Maintenance Maintenance The internal electronics of the TS-1 require no maintenance. The most frequent cause of operating problems is the need for maintenance of the thermocouple lance hardware used with the TS-1 Handheld Digital Pyrometer. The most common issues are problems with contact blocks and the compensated measurement cable inside the lance. -
Page 18: Table 3: Frequent Operating Issues
TS-1 User Manual Maintenance Table 3: Frequent operating issues Issue Cause Effect Action Taking reading Multiple electrical with furnace Turn furnace power OFF grounds created power ON Measurement probe doesn’t penetrate to desired depth for Make measurements below Operating Slag Thickness an accurate and the slag line. -
Page 19: Battery Use And Charging
LED turns ON. To check the condition of the batteries, press the POWER button to turn ON the TS-1 Handheld Digital Pyrometer and remove the thermocouple from the lance. The TS-1 displays the... -
Page 20: Important Note Regarding Battery Use
TS-1 User Manual Battery Use and Charging 120°F, charging stops even though the status indicator continues to flash. Disconnect the charger and allow the TS-1 to cool. If the batteries still do not charge, contact SYSCON Sensors. Important note regarding battery use Use only SYSCON Sensors NiCad Batteries (Part no. -
Page 21: Troubleshooting
Before proceeding with the troubleshooting guidelines, verify that the TS-1 is setup for the correct thermocouple type and calibration standard (IPTS 48 or IPTS 68). The calibration standard of the TS-1 is displayed after POWER is turned ON and should match that of the thermocouple tip used for temperature measurement. -
Page 22: Ordering Information
TS-1 User Manual Ordering Information Ordering Information Ordering Information TS-1 TS-1 head unit + battery charger. Specify: Thermocouple type: S, K, R, B Specify: IPTS 48, 68 Calibration Measurement Lance, X: Type-S, R or B LH-X-LL-BB LL: Lance length: 36”, 48”, 60”... -
Page 23: Replacement Parts
Stainless Steel Lance Rechargeable Grooved Handle Contact NiCad Battery Battery Charger Block Figure 6: TS-1 schematic with replacement parts labeled. Table 5: Replacement part numbers Part Number Description IN-C1 Battery Charger (100-240V AC 60Hz) IN-B1 NiCad (Nickel-Cadmium Battery) Rechargeable battery, 1.2V, 600mAh, AA... -
Page 24: Calibration Certificate
TS-1 User Manual Calibration Certificate Calibration Certificate Calibration Certificate is available for IPTS 48 and 68 standards. SYSCON Sensors uses standards traceable to National Institute of Standards and Technology (NIST). Figure 7: Template Calibration Certificate for TS-1 © SYSCON Sensors... -
Page 25: Figure 8: Template Report Of Calibration For Ts-1
TS-1 User Manual Calibration Certificate Figure 8: Template Report of Calibration for TS-1 © SYSCON Sensors... -
Page 26: Contact Us
TS-1 User Manual Contact Us Contact Us SYSCON Sensors Address: 1108 High Street South Bend, Indiana, USA - 46601 Phone: +1 (574) 232 - 3900 www.sysconsensors.com © SYSCON Sensors... -
Page 27: Warranty
SYSCON Sensors’ obligation under this warranty shall be limited exclusively to the repair or replacement of any products determined to be defective by an authorized SYSCON Sensors representative, whose determination shall be final.
