INSTRUCTION MANUAL

Product Model

OL12-D001GB

Please keep this manual carefully for further reference!

Thank you for selecting our dehumidifier. Be sure to read this manual carefully before using it.

Any questions, please contact the

amhyker@163.com

for help.

Table of Contents

Need help?

Do you have a question about the OL12-D001GB and is the answer not in the manual?

Questions and answers

Summary of Contents for Amhyker OL12-D001GB

Page 1 INSTRUCTION MANUAL Product Model OL12-D001GB Please keep this manual carefully for further reference! Thank you for selecting our dehumidifier. Be sure to read this manual carefully before using it. Any questions, please contact the amhyker@163.com for help.
Page 2: Need Help
Welcome Thanks for your purchase and welcome to the Amhyker family. We suggest that you read this user manual before plugging in your new dehumidifier as it contains important safety information, operation instructions, troubleshooting, maintenance tips, and warranty information to ensure the reliability and longevity of your dehumidifier.
Page 3: Table Of Contents
CONTENT CAUTIONS PARAMETERS FEATURES PRODUCT DISCRIPTION OPERATRIONS MAINTENANCE TROUBLE SHOOTING DECOMMISSIONING...
Page 4: Cautions
01 CAUTIONS Please read the operating instructions carefully before using your dehumidifier for the first time. 1.Install the unit on flat and hard floor to diminish vibration or noise. 2.Never immerse the unit in water or other liquids. 3.Never operate the unit if the cable or other connector is damaged, or something abnormal may happen, please call customer service for help.
Page 5: Parameters
Don’t try to repair, dismantle or remold such appliance, or it may make some damage. Even the change of power cord should be done by special qualified person. 02 PARAMETERS Home Dehumidifier OL12-D001GB Power Supply AC115V 60Hz 175W/1.9A @ 80˚F, 60% RH Power Consumption & Current 205W/2.1A @ 86˚F, 80% RH...
Page 6: Product Discription
04 PRODUCT DISCRIPTIO Touch panel Air outlet Right side shell Front shell Castors Back shell Air filter Continuous drainage Water tank 05 OPERATRIONS...
Page 7 Power In the standby state, press the power button to turn on, the operation indicator lights up and the default fan speed is high, at the same time the PURIFY lights up and the default humidity is 50%. In the power-on state, press the power button to turn off, the running indicator light goes off and the compressor stops immediately, and then the fan shut down after 30 seconds delay.
Page 8 “00” to cancel the timer function. The indicator turns out. After the timer is set and completed, the timer LED is on during the timing period. After the timing is over, the timer LED turns off automatically. In the running state, set the time to turn off the machine; in the standby state, set the time to turn on the machine.
Page 9: Maintenance
Empty the tank Grab the notch at the bottom of the tank and pull it out with both hands. ● Take it slowly and steadily in case of spilled water. Empty the water. ● Put the water tank back in position. The dehumidifier automatically starts ●...
Page 10: Continuous Drainage
Ensure the water tank is in right position when putting it back, otherwise the dehumidifier can not start up. If the tank is dirty, wash it with cool/warm water. Do not use cleanser, steel balls, chemically treated dust-proof cloth, gasoline, benzene, thinners or other chemical solvents in case of damage and leakage.
Page 11 For continuous drainage,the hose should not be excessively bent，and the end of the hose should not be submerged in water to prevent it from being blocked or damaged. Spacing When the dehumidifier is in operation, make sure that the rear of the dehumidifier maintains a minimum spacing of 20 cm as shown below.
Page 12: Care And Cleaning
Care & Cleaning To avoid possible electric shock, ensure to turn the dehumidifier off and disconnect the plug from the power source before before performing any cleaning or maintenance. 1. Clean the Vent and Case • Use water and a mild detergent. Do not use bleach or abrasives. •...
Page 13 • Use a vacuum cleaner with a soft brush attachment to remove any large debris or dust build-up from the air filter. • Wash the filter in lukewarm, soapy water, below 40°C (104°F), or use a neutral cleaning agent. • Rinse the filter with clean water and dry thoroughly. •...
Page 14: Trouble Shooting
07 TROUBLE SHOOTING FUNCTIONING TEMP. 5°C ≤ Ambient Temp. ≤ 35°C When the ambient temp is lower dehumidifier stops working. When 5°C ≤ Ambient temp. ≤ 16°C, the compressor automatically defrosts at intervals; during defrosting, the compressor stops and the fan keeps running. BEFORE CALLING FOR SERVICE Before contacting professional service, please review the trouble shooting list that includes common occurrences that are not the result of a defect in...
Page 15 Troubleshooting Problem Possible Cause Solution The power cord is unplugged. Connect to a functioning outlet and switch on Dehumidifier can not tum on The fuse is blown or circuit breaker is Check the fuse or the circuit breaker. tripped. The room humidity has reached the se Set a lower humidity.
Page 16 The above state has a 10min fault delay setting, that is, once the above fault occurs, the compressor can only be started after a 10min delay even if the fault is recovered. If still have other problem,pleasecontact the amhyker@163.com for help.
Page 17: Decommissioning
0 DECOMMISSIONING 1. STORAGE. Long-term storage - If you will not be using the unit for an extended period of time (more than a few weeks) it is best to clean the unit and dry it out completely. Please store the unit per the following steps: Press power button to switch off and unplug the unit.
Page 18 amhyker@163.com...
