WATER HYACINTH CHEST-LARGE
Assembly Instructions
631/2723
- Please keep for future reference
Dimensions
Width - 120 cm
Depth - 44 cm
Height - 45cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: Argos
0345 6400800
Issue 1 - 07/10/16
Advertisement
Summary of Contents for Argos Home 631/2723
- Page 1 WATER HYACINTH CHEST-LARGE Assembly Instructions 631/2723 - Please keep for future reference Dimensions Width - 120 cm Depth - 44 cm Height - 45cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos...
-
Page 2: Care And Maintenance
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • To reduce the components and tools listed on or put weight on the product, likely hood of the following pages this could cause damage. - Page 3 Components If you have damaged or missing components, call the Customer Helpline: Argos 0345 6400800 Please check you have all the panels listed below Front Panel 120*41 cm Top Panel 120*44 cm Front Panel 120*41 cm Left Panel 38*41 cm Right Panel 38*41 cm 114.5*38 cm...
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Allen key Bolt Ø3*30 mm x 6 Screw Ø6*50 mm x 8 Screw...
- Page 5 Assembly Instructions Step 1 Attach left panel right panel into bottom panel . Using 2pcs of screw Step 2 Attach back panel into bottom panel , left panel and right panel Using 4pcs of screw 4pcs of screw as shown in the figure.
- Page 6 Assembly Instructions Assembly Instructions Step 3 Attach front panel into bottom panel , left panel and right panel Using 4pcs of screw 4pcs of screw as shown in the figure. Step 4 Connect top panel back panel 3 using 6pcs bolt at the hinges.
