Our products are designed to be used correctly and with care for the purpose for

which they are intended. No liability is accepted by the Tool Connection for incorrect

use of any of our products, and the Tool Connection cannot be held responsible for

any damage to personnel, property or equipment when using the tools. Incorrect use

will also invalidate the warranty.

If applicable, the applications database and any instructional information provided

has been designed to offer general guidance for a particular tool's use and while all

attention is given to the accuracy of the data no project should be attempted without

referring first to the manufacturer's technical documentation (workshop or instruction

manual) or the use of a recognised authority such as Autodata.

It is our policy to continually improve our products and thus we reserve the right to

alter specifications and components without prior notice. It is the responsibility of the

user to ensure the suitability of the tools and information prior to their use.

Infra-red Laser

Thermometer |

Instructions

Infrared Thermometer

-50º to +650ºC

-58º to +1202ºF

6430

Digital

Need help?

Do you have a question about the LASER 6430 and is the answer not in the manual?

Page 1 6430 Our products are designed to be used correctly and with care for the purpose for which they are intended. No liability is accepted by the Tool Connection for incorrect use of any of our products, and the Tool Connection cannot be held responsible for any damage to personnel, property or equipment when using the tools.
Page 2 Infra-red Laser Thermometer - Digital Specification The Laser 6430 is an infrared laser thermometer designed for a large range of Temperature Range: -50° to 650°C (-58° to 1202°F) garage and workshop applications, for example, checking vehicle heating and air- conditioning systems, engine radiator and thermostat function, exhaust manifolds, brakes, etc.
Page 3 Emissivity Values Controls and Display Key for Figure 1: Thermal Thermal Substance Substance Emmissivity Emmissivity LCD Display Asphalt 0.90 to 0.98 Cloth (black) 0.98 SCAN (Temp measuring in progress) Measurement HOLD Concrete 0.94 Human skin 0.98 Display backlight switch Cement 0.96 Lather 0.75 to 0.80...
Page 4 Distance and Spot Size Instructions As the distance (D) from the object increases, the diameter (S) of the area measured 1. Hold the thermometer by the handle grip and point towards the objector surface becomes larger. to be measured. 2. Pull and hold the trigger to turn the thermometer on (the display will light if battery D:S=12:1 12.5mm @ 150mm...
