MOTOROLA T505 - MOTOROKR Quick Start Manual

Bluetooth in-car speakerphone & digital fm transmitter.
Hide thumbs

BEFORE YOU BEGIN
Before using this product, read the Important Safety and Legal Information
pamphlet and follow its instructions.
Take a moment before you get started to familiarize yourself with your new MOTOROKR
T505 Bluetooth
®
In-Car Speakerphone & Digital FM Transmitter.
motorola
Front View
T505
Microphone
Play/Pause
Visor Clip
Quick Start Guide
FM Indicator
Main
Call
Volume Down
Speaker
Indicator
Button
Button
(on bottom)
Light
Motorola, Inc.
Consumer Advocacy Office
YOU'RE FINISHED!
1307 East Algonquin Road
Schaumburg, IL 60196
After you have successfully set up your
MOTOROKR T505, you don't need to repeat
www.hellomoto.com
these steps.
1-877-MOTOBLU
1-888-390-6456 (TTY/TDD United States for
For daily use, ensure that your T505 is turned
hearing impaired)
ON and your phone and/or music device's
Bluetooth feature is ON.
Guide Number: 6809503A46-O
To use the T505 with your FM car radio, see
"Using With Your FM Car Radio" on the
reverse side.
To configure T505 settings, see "Configure
Your MOTOROKR T505" .
Bluetooth QD ID:B013331
MOTOROLA and the Stylized M Logo are registered in the US
Patent & Trademark Office. The use of wireless devices and their
accessories may be prohibited or restricted in certain areas.
Always obey the laws and regulations on the use of these
products. The Bluetooth trademarks are owned by their
proprietor and used by Motorola, Inc. under license. All other
product or service names are the property of their respective
owners.
© Motorola, Inc. 2007
NOTICE
At the time of printing, use of FM
032374o
transmitter portion of this product
is restricted in the following
countries: Austria, France,
Rear View
Greece, Ireland, Italy,
Netherlands, Czech Republic,
Cyprus, Hungary, Lithuania,
Button
Latvia, Malta, Poland, Slovakia,
Bulgaria, Croatia, Moldava,
Serbia, and Montenegro.
032374o
Handsfree call audio broadcast to
your FM radio using the
transmitter feature can potentially
be picked up by another radio in
close proximity. Call audio heard
FM
Charging
on the internal speaker is not
Volume Up
Power
Light
Button
Port
impacted.
Button
Button
START HERE >
USING YOUR
TIPS
MOTOROKR
Use the following tips when using your T505:
T505
If your T505 remains in an idle state (not
connected to a Bluetooth device) for 15
minutes, it stops searching for the last
See
connected device.
Features and
When this occurs, you can manually initiate a
Functions Guide
search (or "page") for the last connected
on the reverse side
device by tapping the Call button.
for details on
If your T505 remains in an idle state for 30
using your T505
minutes, it will automatically turn off.
When this occurs, turn on your T505 to
connect to your device.
When answering an incoming call, a single
tone indicates when call setup is complete.
1
PAIR
Step B - TURN ON BLUETOOTH FEATURE
ON YOUR DEVICE
Your MOTOROKR T505
Before you can use your MOTOROKR T505, you
To use your MOTOROKR T505, you must turn
must pair (link) it with your Bluetooth device.
on the Bluetooth feature in your phone or music
Step A - ENSURE T505 IS IN PAIRING MODE
device.
1
Verify any Bluetooth devices previously
For most Motorola phones:
paired with your T505 are turned off.
> Settings > Connection >
1
Press
M
(
Menu
)
2
Power on your T505 by pressing and holding
Bluetooth Link > Setup.
the Power button for approximately three
seconds. The main indicator light flashes and
you hear an audible tone sequence to
2
Scroll to
Power.
indicate the device is powered on.
3
Select
Change.
After a few moments, the main indicator
light will be steadily lit to indicate T505 is in
4
Scroll to
On.
pairing mode.
Main Indicator Light
5
Press
Select
to turn on the Bluetooth
(steadily blue
feature. The Bluetooth feature remains on
for pairing mode)
until you turn the feature off.
Note: These steps are for most Motorola phones.
For other phones, see your phone's user's guide.
If your T505 is not pairing mode, see
TROUBLESHOOTING for help.
CONFIGURE
3
Voice prompt type
Your MOTOROKR T505
Description: Replace spoken prompts with
tones (FM stations are always
Your MOTOROKR T505 uses a default set of
spoken)
configuration settings. You may change the
default settings at anytime.
Options:
On or Off
4
Voice prompt volume
To modify T505 configuration settings, enter
setup mode by pressing and holding the Call
Description: Adjust the loudness of the
button while powering up. The main indicator is
voice prompts (or tones)
steadily lit in green to indicate your T505 is in
Options:
Seven volume levels (steps)
setup mode.
For each setting, press the Volume up and down
There are four configurable settings in your T505
keys to select a different option. To make a
(default setting in italics).
selection, press the Play/Pause key. The main
1
Voice prompt language
indicator light flashes green to confirm your
selection.
Description: Set language for voice prompts
Options:
English, French, Spanish, and
Upon completing configuration, your T505 plays
Portuguese
power up tones and enters the standard power
2
up sequence.
Caller ID
Description: Hear the phone number of the
If you fail to complete all four customization
the incoming caller
settings, your T505 will not save your changes.
Options:
On or Off
2
TEST AND USE
Step C - SET YOUR DEVICE TO LOOK FOR
YOUR T505
While your T505 is in pairing mode, use your
Your MOTOROKR T505 and phone or music
phone or music device to perform a device
device are now paired and connected. Do the
discovery. Refer to your device's manual for
following to verify proper operation:
detailed instructions on accessing Bluetooth and
placing it in device discovery mode.
To verify handsfree calling operation,
dial the number you want to call on the
For most Motorola phones:
phone and press SEND key on your
1
Menu
> Settings > Connection >
Press
M
(
)
phone. If your phone and T505 are
Bluetooth Link > Handsfree > Look for Devices.
successfully paired, you will hear ringing
on your T505.
The phone lists Bluetooth devices it finds.
2
Select
Motorola T505.
To verify streaming audio operation,
play music on your portable Bluetooth
3
Select
OK
or
Yes
to pair your T505 with your
music device. If your music source and
phone.
T505 are successfully paired and
connected for streaming music, you hear
4
If prompted, enter the passkey:
0000
music on your T505.
5
Select OK.
Note: These steps are for most Motorola phones. For
other devices, see your device's user's guide.
When your T505 successfully pairs and
connects with your phone or music device, the
main indicator light flashes purple and blue.
TROUBLESHOOTING
My MOTOROKR T505 will not enter pairing
mode.
Make sure that any devices previously paired with
the T505 are turned off. If the main indicator light
is pulsing in blue, first turn off the other device,
then turn your T505 off and on. The main indicator
light becomes steadily lit in blue indicating the
T505 is now in pairing mode.
My phone/music device doesn't find my
MOTOROKR T505.
Make sure the indicator light on your T505 is on (lit
in blue) and steady when your phone/music
device is searching for devices (see step 1a).
My MOTOROKR T505 worked before but now
it's not working.
Make sure your phone/music device is on and the
Bluetooth feature is turned on in your device (see
step 1b). If the Bluetooth feature was turned off or
was turned on only temporarily, you may need to
restart the Bluetooth feature (see step 1b) and pair
your device and T505 again (see step 1c).
Support.
If you need more help, contact us at
1-877-MOTOBLU or visit us at
www.hellomoto.com/Bluetoothsupport
