Summary of Contents for AVX AVX-C401

Page 1 COFFEE GRINDER USER MANUAL AVX-C401...
Page 3: Important Safeguards
COFFEE GRINDER USER MANUAL IMPORTANT SAFEGUARDS Read these instructions carefully, because they contain important information about safety of installation, use and maintenance. Keep this booklet carefully for consulting when you need it. Remove and safely discard any ï To protect against electric shock, ï...
Page 4 COFFEE GRINDER USER MANUAL ï Do not use product for any other ï Children should be supervised to purpose than grinding coffee beans. ensure that they do not play with the appliance. ï Do not use pre-ground coffee in ï Unwind the power cord fully before bean hopper.
Page 5 COFFEE GRINDER USER MANUAL ï The installation of a residual current device (safety switch) is recommended to provide additional safety protection when using electrical appliance. It is advisable that a safety switch with a rated residual operating current not exceeding 30mA be installed in the electrical circuit supplying the appliance.
Page 6: Know Your Coffee Grinder
COFFEE GRINDER USER MANUAL KNOW YOUR COFFEE GRINDER...
Page 7: Specifications
COFFEE GRINDER USER MANUAL 1 Bean Hopper Lid SPECIFICATIONS Air tight seal lid to maximise coffee bean freshness. Model AVX-C401 2 Bean Hopper 250g bean hopper with a safe locking Power system for easy removal and bean 150 W transfer.
Page 8: Operating Your Coffee Grinder
COFFEE GRINDER USER MANUAL OPERATING YOUR COFFEE GRINDER BEFORE FIRST USE Remove and safely discard all promotional labels and packing materials attached to your product. Wash hopper, and other accessories in warm soapy water and dry thoroughly. Wipe exterior of grinder with a soft damp cloth and dry thoroughly.
Page 9 COFFEE GRINDER USER MANUAL 4. Wipe and polish exterior of appliance 3. Select Grind Size with a soft damp cloth. For Espresso, start with grind size 5. Rotate the hopper either coarser to finer until your preferred flavour profile is achieved. This should be done in conjunction with GRINDING YOUR COFFEE setting the grind amount.
Page 10 COFFEE GRINDER USER MANUAL 4. Select Grind Amount and Grind 2. Place the coffee container directly under grind outlet. Select the desired amount of ground coffee required by turning the Grind Time Knob. As a guide, increasing the time will increase the coffee dose;...
Page 11: Cleaning The Burrs
COFFEE GRINDER USER MANUAL Grind Size and Amount Recommendations Brewing Method Espresso Moka Pour Over/Drip French Press Suggested Grind Size Fine Medium Medium Coarse Grind Settings 0 - 25 25 - 40 40 - 50 50 - 65 Amount/ 1 Cup 10 secs - - - - - -...
Page 12: Alarm Messages
COFFEE GRINDER USER MANUAL ALARM MESSAGES Cleaning Alarm If blockage trapped in burrs, the On/Off button will blink yellow with continuous “beeps”. It indicates the burrs need to be cleaned. Please unplug power cord and remove bean hopper. Inspect bean hopper and burrs for blockage.
Page 13: Troubleshooting
COFFEE GRINDER USER MANUAL TROUBLE SHOOTING If the machine is not working properly, please make the simple checks set out as follows: PROBLEM POSSIBLE CAUSE SOLUTION Grinder does not start Grinder not plugged in. Plug power cord into outlet. after pressing the button.
Page 14 COFFEE GRINDER USER MANUAL PROBLEM POSSIBLE CAUSE SOLUTION Unable to lock bean Coffee beans obstructing Remove bean hopper. hopper into position. bean hopper locking device. Clear coffee beans from top of burrs. Re-lock bean hopper into position. Not enough or too Grind amount requires Turn the Grind Time Knob to much coffee ground.
Page 15 COFFEE GRINDER USER MANUAL NOTES...
Page 16: Coffee Grinder
COFFEE GRINDER AVX-C401 www.avx.hu...
