Beijing TT Aviation Technology Co., Ltd.
Add: No.1 TTA Building, Niantou Industrial Park ,Changping District,Beijing, China
1. Products Introduction
This is a 14S1P self-balancing intelligent battery pack with charge and discharge
management function specially designed for UAV. The supporting intelligent data
cloud service system developed and designed can provide users with all-round
application and security services
2. Indicator Description
3. Products Standard
No.
Battery Model
1
Nominal Capacity
2
Nominal Voltage
3
4
Battery Weight
5
Standard Charge
6
Quick Charge
7
G200 PLUS Smart battery
➀ ➁➂
➃➄➅➆
Item
14S1P
17000mAh @ 0.2
51.8 V（Cell 3.7V）
112.5 x 167.5 x 235mm
Size
5900±100g
5A CC （constant current） charge to 58.8V, then
CV（constant voltage 58.8V）charge till the
value of the current≤0.02C
Sustained current：25A,
Sustained voltage：58.8V
Non-conducting voltage：0.02C
www.ttaviation.org
➀ LED7
➁ LED6
➂ LED5
➃ LED4
➄ LED3
➅ LED2
➆ LED1
➇
➇ Button
Parameter
Advertisement
Summary of Contents for TT Aviation 14S1P
- Page 1 G200 PLUS Smart battery 1. Products Introduction This is a 14S1P self-balancing intelligent battery pack with charge and discharge management function specially designed for UAV. The supporting intelligent data cloud service system developed and designed can provide users with all-round application and security services 2.
- Page 2 Beijing TT Aviation Technology Co., Ltd. Add: No.1 TTA Building, Niantou Industrial Park ,Changping District,Beijing, China Standard Charge：5.4h（reference value） Charging time Quick Charge：1.0h（reference value） Maximum constant Maximum constant current：100 A discharge current Non-conducting voltage：44.8V 4. Attention (1) Use TTA approved battery.
- Page 3 Beijing TT Aviation Technology Co., Ltd. Add: No.1 TTA Building, Niantou Industrial Park ,Changping District,Beijing, China ● ● 38%~49% ● ● ⊙ 50%~62% ● ● ● 63%~74% ● ● ● ⊙ 75%~94% ● ● ● ● 95%~100% Table 3 The battery capacity indication of charging state...
- Page 4 Beijing TT Aviation Technology Co., Ltd. Add: No.1 TTA Building, Niantou Industrial Park ,Changping District,Beijing, China ● ● 25%~37% ● 13%~24% ● Below 12% 7. State LED Indicator ➀. Red LED ： Storage indicator, indicates that battery is in storage mode. Current battery voltage is higher than storage voltage,so battery is discharging itself to reach the storage voltage.
- Page 5 Beijing TT Aviation Technology Co., Ltd. Add: No.1 TTA Building, Niantou Industrial Park ,Changping District,Beijing, China 10. Intelligent Storage Function If the standing time will be more than 5 days, please discharge the battery to 40-70% power to storage, which can prolong the life of the battery.If the battery is fully...
- Page 6 Beijing TT Aviation Technology Co., Ltd. Add: No.1 TTA Building, Niantou Industrial Park ,Changping District,Beijing, China This content is subject to change. If you have any questions, please contact TTA: lan.li@ttaviation.com Copyright@2020 TT Aviation All rights reserved. www.ttaviation.org...
