Summary of Contents for FIXAIR UV Mini LED
- Page 1 User Manual FixAir UV Mini LED Please read this manual carefully before use and keep it for reference.
- Page 2 BEFORE INSTALLING Read all instructions carefully. Failure to do so could damage the equipment or cause harm to yourself or others. Acknowledge all warnings. Only qualified technicians should perform the installation. INCLUDED INSIDE BOX UV module UV warning label. 3M tapes & Cable ties . Installation &...
- Page 3 UV INSTALLATION NOTES DANGER ULTRAVIOLET RADIATION Protect eyes and skin from direct and reflected radiation. HAZARDOUS VOLTAGE Turn off and disconnect power before servicing. This module is typically used in mini split, cassette unit and other limited space applications. Because space is tight, the best place for mounting the UV lights is usually inside the supply vent with the light shining onto the blower wheel (which is prone to the worst ...
- Page 4 - Stick LED strips to the back of the front panel with 3M tapes. - Or fix LED strips on the rack of air inlet with cable ties. NOTE Proper distance between LED and filters is at least 2cm. - Open the cover of power supply box. - Insert the L,N wire to the corresponding L,N terminal in the power supply box.
- Page 5 - Plug in and enjoy the fresh air. NOTE 1. The energy saving airflow sensor turns the unit on only when the mini-split or cassette air conditioner unit working. 2. When the mini-split or cassette air conditioner off, the UV system will light off automatically.
- Page 6 THANK YOU FOR PURCHASING OUR PRODUCTS FIXAIR LLC 3932 ALEXANDRA OAK CT SUWANEE, GA 30024...
