Summary of Contents for Protecto RHINO
- Page 1 RHINO AUTOMATION FOR SWING GATES Installation and User manual...
-
Page 3: Table Of Contents
INDEX WARNINGS DESCRIPTION AND INTENDED USE CONTENT TECHNICAL FEATURES MOTOR DIMENSIONS LIFE LINE INSTALLATION INTRODU CTION PRELIMINARY CHECKS INSTALLING THE OPERATOR OPENING MECHANICAL LIMIT SWITCH UNLOCKING THE MOTOR WIRINGS CHARACTERISTICS OF THE POWER CABLE CONNECTING THE CONTROL UNIT TO MOTOR TERMINAL END USER SECTION WARNINGS MAINTENANCE... -
Page 4: Warnings
Proteco Srl will not respond in case of using additional and/or fake spares. Before commissioning the system, deliver the last pages of this manual to the user (section 7. END USER’S TIPS). Proteco S.r.l. reserves the right to make changes to the product without notice. RHINO - rev. 01_2024... -
Page 5: Description And Intended Use
20’’ - 24” Duty cycle Cycles per hour 1,25 1,5 1,75 2,25 2,5 2,75 3,25 3,75 4 RHINO 230V RHINO 24V MOTOR DIMENSIONS Without PIN DISTANCE: OPEN – CLOSED MLS (mechanical limit switch) With MLS (mechanical limit switch) RHINO - rev. 01_2024... -
Page 6: Life Line
LIFE LINE TABLE 1C The life of the gearmotor may be affected by multiple waste factors. RHINO 230V RHINO 24V The life expectation can be calculated using the criteria outlined in Leaf max 1,5 m the below table. Leaf max 2 m... -
Page 7: Installing The Operator
Max opening angle Front hole Front hole BRACKET DISTANCE AND LEVELING Picture 4 Picture 3 Picture 5 During the bracket positioning, remove the plastic cover from motor terminal, see pictures 4 and 5. Unlock the motor (picture 15). RHINO - rev. 01_2024... - Page 8 Picture 10 1) Insert the MPE1224 fork pin into the hole of the pillar bracket choosing the hole that best suits the installation, pictures 7 and 8 Picture 7 RHINO - rev. 01_2024...
-
Page 9: Opening Mechanical Limit Switch
Unlock the motor and open the gate to the desired opening position. SCH0190 Fix the opening position closing screw M5 until both plates are firmly locked. The plates shall pair the RHINO toothed metal case (Picture 14) Picture 11 Picture 12 A = Upper plate... -
Page 10: Wirings
2 x 0,5 mm² Flashing light ATTENTION: maximum cable diameter 8 mm 2 x 0,5 mm² 2 x 0,5 mm² Radio receiver For 230V type H05RN-F 4Gx0,75 mm² For 24V type H05RN-F or FROR 20-22 2x1 mm² RHINO - rev. 01_2024... - Page 11 Wire the motor to the control unit respecting the correct terminals. Capacitors are prewired and stowed underneath the motor terminal compartment. Q80A 12 13 14 15 16 17 TERMINAL BLOCK 3 Q60A 13 14 15 16 17 18 RHINO - rev. 01_2024...
-
Page 12: End User Section
This product was designed and built automation area. exclusively for the intended use indicated. Any other use could compromise the integrity and safety of the product and should be avoided. DATE NOTES INSTALLER SIGNATURE OWNER SIGNATURE RHINO - rev. 01_2024... -
Page 13: Maintenance
(e.g. falls, oxidation, overvoltage). When returning a product, remember to include in addition all your data (name, surname, address, telephone number and/or e-mail) to allow us to contact you and update you on your return procedure. RHINO - rev. 01_2024... -
Page 14: Compliance Declaration
Via Neive, 77 - 12050 CASTAGNITO (CN) - ITALY Address: declares that The product type: Automation for swing gates and according accessories RHINO model: RHINO Is built to be integrated into a machine or to be assembled with other machinery to crate a machine under provisions of 2006/42/EC Machinery Directive.
