XIA microDXP Manual

Hide thumbs Also See for microDXP:
Table of Contents

Advertisement

Quick Links

Download this manual
microDXP
Development Kit Manual
Version 3.26
September 12, 2024
microDXP Hardware Revision: H (8) & J (10)
microCOMU 2.3 & microCOMV-UFF 1.0
ProSpect Software
Software Revision: 1.1.x
XIA LLC
2744 East 11th Street STE H2
Oakland, CA 94601 USA
Email: support@xia.com
Tel: (510) 401-5760; Fax: (510) 401-5761
http://www.xia.com/
Information furnished by XIA LLC is believed to be accurate and reliable. However, no responsibility is assumed by
XIA for its use, or for any infringements of patents or other rights of third parties which may result from its use. No
license is granted by implication or otherwise under any patent or patent rights of XIA. XIA reserves the right to
change hardware or software specifications at any time without notice.
