Ultratech 0E-SRGE6F2PK User Manual

6 Outlet 6 Outlet
Surge Protector 2-Pack Surge Protector 2-Pack
0E-SRGE6F2PK 0E-SRGE6F2PK
2
2 Protected
USER MANUAL
CONGRATULATIONS ON YOUR PURCHASE
Thank you for selecting the UltraTech 0E-SRGE6F2PK 2-Pack Surge Protector.
This manual explains the features and operation of the 0E-SRGE6F2PK. Please
take a few moments to read this manual.
COPYRIGHT © 2024 ADI All rights reserved.
FEATURES
1. ON/OFF Reset Control Switch and Circuit Breaker
Controls power to all outlets. The switch is also a 15 A breaker. When an overload
occurs, it will automatically switch off. To resume operation, ensure the overload
condition is removed and reset the surge protector by switching the unit ON.
2. Protected LED Indicator
Illuminated when the surge protection feature is working properly.
3. Six Standard Outlets
SURGE PROTECTOR INSTRUCTIONS
1. Set power switch into the "OFF" position. Plug the surge protector into a standard
grounding wall receptacle by fully inserting the plug and ensure that there are no
exposed conductors.
2. Make sure electronic equipment is turned off before plugging into the surge
protector outlets. Do not use extension cords to connect equipment to the surge
protector.
3. Set the power switch into the "RESET" position. The surge protector will now be
providing power and surge protection.
4. Connected equipment can now be turned on.
SPECIFICATIONS (each unit)
1
• Model Number: 0E-SRGE6F2PK
• Outlets: 6 Standard Outlets
• Surge Protection: 1,500 Joules
• Electrical Rating: 125 V/15 A/1875 W
• UL Clamping Voltage: UL 1449 4rd/800 V (H-N, H-G, N-G)
• 3 AC Lines Protected: H-N: 15,000 A, H-G: 15,000 A, N-G: 15,000 A
• Response Time: Less than 1 nanosecond
• Attenuation: Up to 32 dB
• Circuit Breaker: Resettable 15 Amp
• EMI/RFI Filtration: 150 kHz to 100 MHz
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK:
Use only in dry locations and only indoors.
DO NOT plug into another relocatable power tap.
3
DO NOT "daisy chain" surge protectors.
DO NOT use with any aquarium equipment.
DO NOT use if properly grounded outlets are not available.
DO NOT install this device if there is less than 10 meters (30 feet) of wire between
the electrical outlet and electrical service panel.
DO NOT use for medical or life support equipment. This device features an internal
protection that will disconnect the surge protective component at the end of its useful
life, but it will maintain unprotected power to the load.
TROUBLESHOOTING
• If the ON/OFF is switched OFF, the 15 A circuit breaker may have tripped. Examine
your connected equipment and remove the device that is overloading the circuit.
Then, turn the ON/OFF switch back to RESET.
• If the protected indicator does not light, the surge protector's AC lines are no
longer protected from surge. The surge protector may have received a power
surge or spike beyond its specified limits that overloaded the protection circuitry
and rendered it inactive. The surge protector has protected your connected
equipment as designed, but it will not protect against future surges, and spikes. It
should be replaced.
TECHNICAL SUPPORT
Please contact our Tech Support Department with installation, troubleshooting, or
general product questions.
ADI/UltraTech
• US 1-800-233-6261
• Canada 877-234-7378
• Puerto Rico 787-793-8830
LIMITED WARRANTY AND CONNECTED EQUIPMENT GUARANTEE
1. Limited Warranty
a. General
Subject to the terms and conditions of this Limited Warranty, from the date of sale
through the period of time for product categories specified in Section 1(b),
ADI warrants its UltraTech products to be free from defects in materials and
workmanship under normal use and service, normal wear and tear excepted.
Except as required by law, this Limited Warranty is only made to Buyer and may not
be transferred to any third party.
ADI shall have no obligation under this Limited Warranty or otherwise if:
(i) The product is improperly installed, applied or maintained;
(ii) The product is installed outside of stated operating parameters, altered, or
improperly services or repaired;
(iii) Damage is caused by outside natural occurrences, such as lightning, power
surges, fire, floods, acts of nature, or the like.
(iv) Defects resulting from unauthorized modification, misuse, vandalism, or other
causes unrelated to defective materials or workmanship, or failures related to
batteries of any type used in connection with the products sold hereunder.
ADI only warrants those products branded as UltraTech products and sold by ADI.
Any other products branded by third parties are warranted by the third party
manufacturer for a period as defined by the third party manufacturer, and ADI
assigns to Buyer those warranties and only those warranties extended by such third
party manufacturers or vendors for non-ADI branded products. ADI does not itself
warrant any non-ADI branded product and sells only on an as is basis in accordance
with ADI's terms and conditions of sale.
