Esco GlucCell Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TM
GlucCell
Glucose
Monitoring System
Operation Manual
1
ESCO Bioengineering Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GlucCell and is the answer not in the manual?

Questions and answers

Summary of Contents for Esco GlucCell

  • Page 1 GlucCell Glucose Monitoring System Operation Manual ESCO Bioengineering Co., Ltd.

  • Page 2: Table Of Contents

    DISCLAIMER NOTICE ............................III WARRANTY ................................ III CAUTION ................................IV RETURN OF MATERIAL AUTHORIZATION POLICY ....................V CHAPTER 1 ABOUT THE GLUCCELL SYSTEM ....................1 CHAPTER 2 INSTALLATION AND REPLACEMENT BATTERY ................7 CHAPTER 3 SET THE GLUCOSE METER ......................8 CHAPTER 4 PERFORM A GLUCOSE TEST ......................

  • Page 3: Copyright Notice

    Copyright Notice ESCO BioEngineering Co., Ltd., here in after “EBE” No. 36, 20 Road, Taichung Industrial Park, Taichung, Taiwan 40850, R.O.C. All Rights Reserved. Reproduction, adaptation, or translation without prior written permission from EBE is prohibited. The information contained herein is designed only for use with this product. EBE is not responsible for any use of this information as applied to other products.

  • Page 4: Caution

    Please read the entire User’s Guide before attempting to use this unit. Do not use this equipment in a hazardous atmosphere or with hazardous materials for which the equipment was not designed. GlucCell Glucose Monitoring System Ver. B Operation Manual...

  • Page 5: Return Of Material Authorization Policy

    The return authorization number must appear on the outside of all cartons. Item Description Customer Company Name Customer Name Customer Phone Number Purchase Date Machine Serial Number Invoice Number Reason for Returning Back GlucCell Glucose Monitoring System Ver. B Operation Manual...

  • Page 6: Chapter 1 About The Gluccell Tm System

    GlucCell Glucose Test Strips can be used only with GlucCell Glucose Meters. The meter must be coded only with the corresponding code on the glucose test strips bottle that is used - the codes must match.
  • Page 7 1.4 Component List These items are included in your starter kit of GlucCell Glucose Monitoring System. Item Item Name Quantity GlucCell Glucose Meter 1 set Check Key 1 pc Quick Reference Card 1 copy Case 1 each GlucCell Glucose Test Strip...
  • Page 8 Press M button to enter memory mode to recall the information stored in meter’s memory and to increase values in the setting mode. Strip Slot The slot is a connector for GlucCell Glucose Test Strips, and Check Key. • Backside of the meter...
  • Page 9 M188 to ensure that all digits are working properly. mg/dL; mmol/L Selected unit display DAYAVG Number of days average display Date Month/day display Time The meter is programmed for a 12 hour period format. GlucCell Glucose Monitoring System Ver. B Operation Manual...
  • Page 10 Insert this end of test strip into meter. Important information: • GlucCell System measures the amount of glucose in cell culture medium. Sample can be applied both to the right or left side of the test strip’s apertures and is automatically drawn to the test confirmation window where the reaction takes place.
  • Page 11 Do not place test strips in direct heat or sunlight. Do not carry loose test strips in your carrying case. • Test strips are for single use only. 1.7 Test Strip Vial Item Item Name Code Number Expiry Date Discard Date: 90 days from first opening of bottle GlucCell Glucose Monitoring System Ver. B Operation Manual...

  • Page 12: Chapter 2 Installation And Replacement Battery

    1.8 Check Key The GlucCell Check Key can be used to check that the meter is operating properly. Use when performing quality control check on your meter. Chapter 2 Installation and Replacement Battery 2.1 How to install/replace the battery Push the battery cover with two thumbs and slides down to open.

  • Page 13: Chapter 3 Set The Glucose Meter

    3.1.2 Press “S button” to turn on the meter when battery was installed 3.1.2.1 Press “S button” for 3 seconds to turn on the meter. The meter will enter to the setting mode automatically. 3.2 Set the Year The Year field flashes. GlucCell Glucose Monitoring System Ver. B Operation Manual...
  • Page 14 Wait the new setting flash 3 times to confirm and shifts to the next setting. (i.e., Hour). 3.5 Set the Hour The Hour field flashes. Press the “S or M button” to change the Hour. GlucCell Glucose Monitoring System Ver. B Operation Manual...
  • Page 15 The default unit is mg/dL. The switch of measuring units requires a Unit Switch Key (USK). However, the USK is not included in GlucCell product. If users require to switch units to mmol/L, please contact your local dealers or EBE, and we will send you the USK.

  • Page 16: Chapter 4 Perform A Glucose Test

    3 times to validate the change. The new code number is displayed on the screen. The meter is ready for testing when the flashing droplet symbol appears. GlucCell Glucose Monitoring System Ver. B...
  • Page 17 The meter beeps indicating that the test has started. The Measuring Symbol is displayed to indicate the test is in progressing. The test result displays within 15 seconds, and pauses for 3 minutes or until the GlucCell Glucose Monitoring System Ver. B...
  • Page 18 Record the test results in your logbook Remove the test strip to turn off the meter. The test result has been stored. 4.10 GlucCell Glucose Monitoring System Ver. B Operation Manual...

  • Page 19: Chapter 5 Test Results

    High Glucose Value The HI symbol appears when your glucose test result is higher than 600 mg/dL (33.3 mmol/L). Note: In the situation, please dilute the sample with PBS to proper concentration for next test. GlucCell Glucose Monitoring System Ver. B...

  • Page 20: Chapter 6 Memory Recall

    Chapter 6 Memory Recall The GlucCell cell culture glucose Meter automatically stores 180 test results, letting you review them in order from the most recent to the oldest. If the memory is full and a new result is added, the meter deletes the oldest result.

  • Page 21: Chapter 7 Quality Control Test

    1. Turn off the meter by pressing the M button for 3 seconds and remove the Check Key from the meter. 2. Insert the check Key to repeat the test. If the second result persists, consult your local distributor for help. GlucCell Glucose Monitoring System Ver. B Operation Manual...

  • Page 22: Chapter 8 Display Messages And Solution

    Temperature is above or below The result you have obtained the operating range of test strips. may not be accurate. Move to an area with temperature between 10℃ to 40℃ (50℉ - 104℉). Do GlucCell Glucose Monitoring System Ver. B Operation Manual...
  • Page 23 1. Replace the battery. 2. Open the battery door and use a needle to prink the “reset” hole (with a reset mark GlucCell Glucose Monitoring System Ver. B Operation Manual...

  • Page 24: Chapter 9 Taking Care Of Your Glucose Meter

    # If the error message repeats, please contact your local dealer for help Chapter 9 Taking Care of your Glucose Meter Replacing the battery The GlucCell Glucose Meter comes with a battery (not yet be installed when new purchasing). Please install your battery before started. Battery life will vary depending on usage, so always keep a spare on hand.
  • Page 25 • Display messages and problem solving guide When any of the following messages appear, there is a problem with your GlucCell Cell Culture Glucose Meter or the way in which you are performing a test. These messages will help you to identify certain problems. If error messages appear that are not listed on the following pages, contact with your local distributor for help.

  • Page 26: Chapter 10 System Specifications

    Operating Temperature Range 10℃~40℃ (50℉~104℉) Operating Relative Humidity 20%~80%RH Dimensions of the meter 96 mm *60 mm * 18.5 mm Weight of the meter 70 g included battery Auto Shut-off In 3 minutes GlucCell Glucose Monitoring System Ver. B Operation Manual...

  • Page 27: Chapter 11 Performance Evaluations

    381.0 Accuracy 11.2 Tests were carried by trained technicians in the laboratory setting. Samples from the subjects were tested with both GlucCell Meter and YSI Model 2300 Glucose Analyzer as reference. The results are shown in the following table. Slope 1.07...

  • Page 28: Chapter 12 Related Products

    This product fulfills the requirements of Directive 98/79/EC in vitro diagnostic medical device. Related Products Chapter 12 Item Product Name Item Code GlucCell Glucose Monitoring System 1400009 GlucCell Glucose Test Strip (2 bottles (25 1400010 strips/bottle)) GlucCell Glucose Monitoring System Ver.
  • Page 29 No.36, 20th Rd., Taichung Industrial Park, Taichung City 40850, Taiwan TEL:+886-4-2350-7130 FAX : +886-4-2350-6719 Web: http://www.escobioeng.com e-mail: info@escobioeng.com...
