Instructions for Use and Installation
Comfortline Excel Overhead Radiant Heating Panels
1. Basic Technical Data
Type
COMFORTLINE EXCEL 9
COMFORTLINE EXCEL 12
COMFORTLINE EXCEL 18
COMFORTLINE EXCEL 24
COMFORTLINE EXCEL 30
COMFORTLINE EXCEL 36
Type
COMFORTLINE EXCEL 9
COMFORTLINE EXCEL 12
COMFORTLINE EXCEL 18
COMFORTLINE EXCEL 24
COMFORTLINE EXCEL 30
COMFORTLINE EXCEL 36
2. Use
These panels are intended for the heating of large spaces mainly halls, workshops, warehouses, patios, alfresco areas, shops function,
halls and sports facilities. They can also be used for the local heating of designated areas (zone temperature maintenance). They have
surface corrosion protection. However, rapid cooling of the panel when it is hot can result in irreversible damage to it.
3. General Information
3.1 Panels are class 1, IP44.
3.2 All heaters must be installed by a Licensed Electrician and shall be provided with a means to ensure that they can be disconnected
from the supply in accordance with the AS/NZS 3000 wiring rules.
3.3 It is very important not to touch the heating panels without gloves or clean hands as it is not possible to remove grease or dirt
marks without damage to the heating surfaces.
3.4 The panels can either be hung from the ceiling on four fixtures using a chain or cords, or with the help of installation brackets.
The brackets are supplied dissasembled in the terminal compartment and need to be removed before installation of the panel.
The brackets can be supplemented with a swivel bracket (for angle mounting) - (Optional extra).
COMFORTLINE EXCEL 9
COMFORTLINE EXCEL 12
COMFORTLINE EXCEL 18
COMFORTLINE EXCEL 24
COMFORTLINE EXCEL 30
COMFORTLINE EXCEL 36
Wattage
Voltage
W
V
900
1200
1800
230/400V
2400
3000
3600
Wattage
Voltage
W
V
960
1300
1960
240/415V
2600
3270
3900
Type
Ingress
Protection
IP44
Ingress
Protection
IP44
Bracket Mounting
Spacing
40 x 1000
100 x 1000
200 x 1000
Dimensions
Weight
mm
1550 x 150 x 60
1550 x 250 x 60
1550 x 350 x 60
Dimensions
Weight
mm
1550 x 150 x 60
1550 x 250 x 60
1550 x 350 x 60
kg
8.1
12.9
17.7
kg
8.1
12.9
17.7
Advertisement
Summary of Contents for Devex COMFORTLINE EXCEL 9
- Page 1 Comfortline Excel Overhead Radiant Heating Panels 1. Basic Technical Data Wattage Voltage Ingress Dimensions Weight Type Protection COMFORTLINE EXCEL 9 1550 x 150 x 60 COMFORTLINE EXCEL 12 1200 COMFORTLINE EXCEL 18 1800 230/400V IP44 1550 x 250 x 60 12.9...
- Page 2 250 mm Chain cord • Lowest recommended height above the floor 40 mm 3.5m (Comfortline Excel 30-36) 2.4m (Comfortline Excel 9-24) Bracket* • The mutual distance between panels is usually similar to the Spacing height of their installation above the floor Panel •...
- Page 3 4. Installing Using a Fixing Bracket (Supplied in the heater terminal compartment) • Attach the mounting bracket so that the opening for the positioning screw is accessible. Slide one side of the panel onto the bracket. • Slide the panel onto the other part of the bracket then fit the positioning screws (supplied) into the pre-drilled hole on one side of each bracket to prevent it from sliding out.
-
Page 4: Maintenance
All wires MUST be tied together at the terminal block to ensure safe operation of the heater. Comfortline Excel 9-12 Comfortline Excel 18 - 24 Single Phase... -
Page 5: Warranty Conditions
Systems is to repair or replace the defective product only free of charge to the customer. The faulty product must be returned to the place of purchase, or to Devex Systems, where Devex Systems reserves the right to repair or replace the unit at no cost within a reasonable period of time.
