Questions And Comments - ETI ADH NETCOM 24092 Replacement Procedure

11.
Install the new humidity sensor terminal
block to the electrical connector which
was removed in step 6. Tighten the two
captive end screws to secure the
terminal block in place.
Once the rotation of the humidity sensor
12.
is determined based on the position of
the hoses to the fittings, secure the new
humidity sensor assembly in place by
feeding the two tie wraps from the kit
through the slot in each mount, knurled
side up. Tighten the tie wraps, then cut
off the excess from each one.
Reconnect the "Y" section of the tubing
13.
assembly, disconnected in step 5, to the
outlet port fitting.
Reinstall the front cover removed in step
14.
4 of this section. If it was placed upside
down on the lid of the unit during this
procedure, carefully turn the cover back
over and work it back into position, past
the wires and other components in the
enclosure. Reinstall the four corner
screws securing the front cover to the
chassis.
Reconnect the ground wire by inserting
15.
it behind the retaining screw from which
it was removed in step 3, then tighten
the ground wire retaining screw.
Connect the terminal block to the power
connector by holding it in place then
tightening the two captive screws.
Reconnect both ends of the orange
ethernet cable removed in step 3 of this
section. It does not matter which end of
the ethernet cable goes into which
receptacle.
With the ground wire, power connector
16.
and ethernet cable reconnected, close
the lid of the NEMA enclosure and
secure the two latches opposite the
hinges. Secure the lid in place by
reinstalling the two captive screws in the
two outer corners of the lid.
South Bend, Indiana USA | networketi.com
Restore machine power by plugging
17.
the unit back in.

QUESTIONS AND COMMENTS

For technical
comments concerning
ETI, Inc.,
Customer
between 8:00 a.m. and 5:00 p.m. EST.
DISCLAIMER
ETI, Inc. makes no representations or
warranties, either expressed or implied
with respect to the contents of this
publication or the products that it
describes, and specifically disclaims any
implied warranties of merchantability or
fitness for any particular purpose. ETI,
Inc. reserves the right to revise this
publication and to make changes and
improvements
described in this publication without the
obligation of ETI, Inc. to notify any
person or
revisions, changes or improvements.
No part of this manual may be
reproduced or translated in any form or
by any means, electronic or mechanical
including photocopying and recording,
for any purpose without the express
written consent of ETI, Inc.
The ETI logo, We Manage Heat, and
ADH are registered trademarks of ETI,
Inc. NETCOM is a trademark nc. NETCOM is
Copyright © 2012 ETI, Inc. All rights
reserved.
6
ADH INSTRUCTION MANUAL | PART NO.
help, questions,
this or
product, contact the
Service Department
to the products
organization of such
24105
or
any
REV B
