Summary of Contents for Matsusada Precision COR-10B2
- Page 1 Instruction Manual COR-10B2 MODEL *018.9.003* Rev. 0.2 B/N018.9.003...
- Page 2 SAFETY This power supply unit generates high voltage and energy. Electric shock may lead to death or serious injury. Be sure to follow the instructions below and handle the unit with caution. 1. BE SURE TO GROUND!! Be sure to ground the power supply unit before use. 2.
-
Page 3: Meanings Of The Symbols
Symbols Various symbols are used in this instruction manual and on the product for ensuring safety. What will be caused by ignoring the instructions given with the symbols or by improper handling are classified as shown below. Read carefully and understand the descriptions before proceeding to the main body of this manual. - Page 4 Caution ！ Do not install the unit upside down or Do not use the unit in a place subject to on a wrong side. high temperature or in an enclosed, Insufficient heat release may cause limited area. deterioration of parts, which may It not only hampers the unit from generate smoke or set fire.
- Page 5 First-aid procedures to be implemented in case of electrical shock RESCUE 1. Free victim from contact with live conductor quickly. Avoid contact with neither live conductor nor victim’s body. 2. Shut off high voltage at once and ground the circuit. If high voltage cannot be turned off quickly, ground the circuit to discharge, or cut high voltage line by an ax with dry wooden handle.
- Page 6 Artificial respiration 1. PLACE VICTIM 2.Clear throat Place victim in face-upward position horizontally. 2. CLEAR THROAT Turn head to one side quickly wipe out any fluid, mucus, or foreign body from mouth and throat with fingers. 3.Open air passage 3. OPEN AIR PASSAGE Tilt head back and extend neck to open air passage.
-
Page 7: Warranty
WARRANTY 1. WARRANTY POLICY Matsusada Precision Inc. ("Matsusada") warrants that the products supplied by it will be free from defects in materials and workmanship for a period of twelve (12) months from the date of original shipment to buyer. This warranty shall not apply to any product which has been repaired, modified... -
Page 8: Table Of Contents
Table of Contents Table of Contents Page 1 Introduction 1-1 Introduction 1-2 Unpacking the amplifier 1-3 Environmental requirements 1-4 Points to be careful about in handling and care 1-5 What to do before calling for service 1-6 Troubleshooting 2 Exterior view diagram 3 Instructions for operation 3-1 Overview 3-2 Operation... -
Page 9: Introduction
1 Introduction 1 Introduction 1-1 Introduction Thank you very much for your purchase of our product, HIGH VOLTAGE AMPRIFIER. We have done our best for the quality control of our products. Please handle this unit properly according to this instruction manual so that you can use the full performance of this unit safely for long. -
Page 10: Points To Be Careful About In Handling And Care
1 Introduction 1-4 Points to be careful about in handling. WHEN TOUCHING LOAD AFTER TURNING OFF HIGH VOLTAGE Make the setting of an output voltage to zero (0). Turn off the HV ON/OFF switch. Check and confirm that the voltage is zero at an output voltmeter of this unit. Turn off the POWER ON/OFF switch. -
Page 11: What To Do Before Calling For Service
1 Introduction 1-5 Additional points to be noted for operation of HV amplifier When using this unit as a high speed and high voltage amplifier(except when DC mode), make sure to have proper connection to make the stray capacity of HV output line as low as possible. - Page 12 1 Introduction Capacitive Load When operated with a capacitive load of more than 100pF (including floating capacity of output cable), the output might oscillate. In such a case put a high voltage resister of 100Ω (0.1μF) to 1kΩ (1000pF) in series to output. Please also note that with capacitive load the bandwidth is limited according to the formula below.
- Page 13 1 Introduction Slew Rate The responsibility of our high speed amplifier is determined with slew rate (SR). The step responsibility of our amplifier is as shown in fig.3. SR = △V/μS In case of output amplitude is smaller the response time become shorter. COR series reach to greater than SR = 30V/μS at maximum.
-
Page 14: Troubleshooting
1 Introduction 1-6 Troubleshooting ・ In case no output voltage: 1. Check input voltage is correct ・ 115V AC ±10% 50/60Hz single phase of input voltage. ・ Control voltage –10V to 10V (bi-pola type), 0V to 10V (uni-pola type) at the time of controlling over external voltage. ・... -
Page 15: Exterior View Diagram
2 Exterior view diagram 2 Exterior view diagram 2-1 Front view ④ ③ ⑥ ⑤ ⑦ HIGH VOLTAGE POWER SUPPLY LIMIT VOLT CURR ② BIAS Vcon-in POWER ① ⑫ ⑭ ⑪ ⑩ ⑬ ⑨ ⑧ ① POWER ON/OFF switch ② HV ON/OFF switch ③... -
Page 16: Rear View
2 Exterior view diagram Rear view ② ① ④ ③ ⑤ FUSE ＧＮＤ ① ② INPUT AC115V ⑥ ⑦ ⑧ ① GROUND terminal ② Output connector ③ RTN terminal (Banana receptacle) ④ FAN ⑤ FUSE (3A) ⑥ Cable cramp ⑦ Ac input connector ⑧... -
Page 17: Instructions For Operation
3 Instruction for operation 3 Instructions for operation 3-1 Overview This product is a high speed and high voltage bipolar amplifier developed using the knowledge and expertise gained through long years of experience with high voltage. This is highly reliable and high performance product with all solid state parts. 3-2 Operation 1. - Page 18 3 Instructions for operation 4. Connect the AC code. 5. Turn on POWER ON/OFF switch. Orange indicator light up, and unit become stand-by mode. At this status, there is no high voltage at output terminal. POWER 6. Turn on the HV ON/OFF switch. The red indicator will light up to indicate that the power supply is ready for operation.
- Page 19 3 Instructions for operation 8. In order to set the output current limit below 2.1mA, turn “Current limit setting potentiometer(CURR)” counterclockwise. LIMIT CURR VOLT 9. Output voltage V(kV) is displayed in output voltage meter, and output current Ig(mA) in output current meter.
- Page 20 3 Instructions for operation [2] CC mode operation a. CC mode operation Normal(NOR) 1. Operation procedure of 1., 3., 4., 5. and 6 are same as CV mode operation. Regarding step 2., turn the “CV/CC mode change switch” to “CC position(CC mode)”, and turn the “CC mode NOR/RTN select switch”...
- Page 21 3 Instructions for operation b. CC mode operation return(RTN) 1. Connect the product as shown in the diagram below. For your safety, always make sure to connect the ground terminal(GND) of the unit to the ground. Connection diagram of return mode Example: Electrostatic drum application Connection diagram of return mode...
- Page 22 3 Instructions for operation 4. Output current Ir(mA) can be controlled as constant current mode by inputting control voltage to Vcon-in .(input impedance of Vcon-in is 10kΩ) Ｖcon Output current Ig -10V -2mA ＋10V +2mA In case that the resistance of load become high, and output current x load resistance get larger than the set value by “Voltage limit setting potentiometer”, then the voltage is to be limited to prevent the over voltage on the load.
- Page 23 3 Instructions for operation c. Application of return terminal When current operation of electrostatic drum, CC mode operation is not usable if drum is not electrically floated from the ground. It is possible to control only drum current with CC normal mode operation with the following connection.
-
Page 24: Using The Bias
3 Instructions for operation 3-3 Using the bias Turning the bias voltage ON/OFF switch to the ON position makes it possible to control bias voltage using the BIAS knob. Read the setting voltage from the scale on the knob CC mode – a CC mode –b CV mode Scale... -
Page 25: Voltage And Current Limit Setting
3 Instructions for operation 3-4 Setting of voltage and current limit Voltage and current limit can be set between 10% to 105% of rated maximum output(± 10kV, ±2mA) with “Voltage/Current limit setting potentiometer”. Both +(positive)polarity and +(negative)polarity output is to be limited when output is over the set value. -
Page 26: Remote Switch On/Off (Ls)
3 Instructions for operation 3-5. Voltage/Current monitor “Voltage monitor(VM), Current monitor(IM)” is output as per below. VM = ±10V/VO = ±10kV IM = ±10V/IO = ±2mA (Output impedance is 1kΩ for both VM and IM) 3-6 Remote Switch ON/OFF (LS) The output can be turned on and off with remote switch. -
Page 27: Other Function
3 Instructions for operation 3-7 Other functions a) Power outage protection This unit has incorporated a circuit for prevention of action once again when the power failure is corrected. When recovered from power failure while HV is under operation, only POWER ON/OFF switch P.L.(orange color) will be lighted, not generating a high voltage output.
