User's Guide
12G-SDI to HDMI(MPO Output) Wall Type Converter
WMC-SD
Thank you for purchasing WMC-SD
WMC-SD, is a MPO/MTP-type wall plate converter for 12G-SDI. It receives an SDI video stream and converts it
into an HDMI TMDS compatible optical signal. The converted optical signal is connected to OPHIT's OMP-HM
Receiver(OMP-HM-R) using one MPO-type optical cable.
www.ophit.com
Advertisement
Related Manuals for Ophit WMC-SD
Summary of Contents for Ophit WMC-SD
- Page 1 WMC-SD Thank you for purchasing WMC-SD WMC-SD, is a MPO/MTP-type wall plate converter for 12G-SDI. It receives an SDI video stream and converts it into an HDMI TMDS compatible optical signal. The converted optical signal is connected to OPHIT’s OMP-HM Receiver(OMP-HM-R) using one MPO-type optical cable.
- Page 2 Check the package and make sure you have everything: 1. Connect the source devices to WMC-SD input port.(SDI) Contents 2. Connect the OMP-HM receiver to WMC-SD output port using (1) WMC-SD the MPO type-A cable. (2) 3-Pin Power Jack x 1ea 3.
- Page 3 Warranty We, OPHIT hereby warrant the final purchase of our product as follows. In the case of troubles on our products, please contact the shop purchased. One year limited warranty Our customers have right to be served with free of charge when there is trouble in this product during 1(one) year from the day purchased.
- Page 4 Technical and Sales Support KOREA HQ OPHIT CO., LTD. #301(Sun technovil), 77, Deogyeong-daero 1471beon-gil, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16681, Republic of Korea TEL: + 82 (0)31 695 5543 FAX: + 82 (0)31 695 5545 E-Mail jhchoi35@ophit.com Regional Office Europe Foreseeson UK Ltd...
