Onkyo TX-910 Service Manual

TX-910/ TX-930
Ref. No. 3443
ONKYO SERVICE MANUAL
QUARTZ SYNTHESIZED
TUNER AMPLIFIER
MODEL TX-910
MODEL TX-930
Black and Silver models
BHMD, BHMDN 120V AC, 60Hz
eames =
BHMP, BHMPF, MP, MPF | 230V AC, 50Hz
BHMW | 120V or 220V AC, 50/60Hz
BHMQA 240V AC, 50Hz
SAFETY-RELATED COMPONENT WARNING! !
COMPONENTS IDENTIFIED BY MARK A ON
THE SCHEMATIC DIAGRAM AND IN THE PARTS
LIST ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE THESE COMPO-
NENTS WITH ONKYO PARTS WHOSE PART
NUMBERS APPEAR AS SHOWN IN THIS .
MANUAL.
MAKE LEAKAGE CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM
THE SUPPLY CIRCUIT BEFORE RETURNING
THE APPLIANCE TO THE CUSTOMER.
