Summary of Contents for Sibelmed DATOSPIR TOUCH MIP-MEP
- Page 1 DATOSPIR TOUCH SPIROMETER MIP-MEP & SNIFF Module USER’S MANUAL 511-BI0-MU2 • REV. 1.04 • 2017-04...
- Page 2 SIBEL S.A.U., Rosellón 500 bajos, 08026 BARCELONA (Spain) National Sales: Tel. 93 436 00 08 e-mail: comercial@sibelmed.com International Sales: Tel. +34 93 436 00 07 e-mail: export@sibelmed.com Technical service: Tel. +34 93 433 54 50 e-mail: sat@sibelmed.com Fax: +34 93 436 16 11, Website: www.sibelmed.com...
-
Page 3: Table Of Contents
MIP-MEP/SNIFF module user’s manual TABLE OF CONTENTS 1. INSTRUCTIONS FOR USE AND INSTALLATION …… INTRODUCTION MIP-MEP CUSTOMIZATION START-UP AND MIP-MEP/SNIFF TEST PROCEDURE 2. TECHNICAL SPECIFICATIONS ………………………….. PARAMETERS RANGES AND MEASUREMENTS CONTROL 3. PRINCIPALS OF OPERATION ……………………………. SIGNAL ACQUISITION CONTROL PROGRAM 4. -
Page 4: Instructions For Use And Installation
MIP-MEP/SNIFF module user’s manual 1. INSTRUCTIONS FOR USE AND INSTALLATION 1.1. INTRODUCTION The DATOSPIR TOUCH Spirometer includes an optional module to measure Maximal Respiratory Pressures (Maximal Inspiratory Pressure - Maximal Expiratory Pressure, MIP-MEP). This manual is an addendum to the manual of the Spirometer DATOSPIR TOUCH, dedicated exclusively to the operation of this module, and it is designed for use alongside the general manual. -
Page 5: Packing List
MIP-MEP/SNIFF module user’s manual d) Health status: physical and mental condition that allows the performance of the forced maneuver 1.1.1 PACKING LIST 07144 The MIP-MEP module includes: 03052 Shutter probe 07020 Connection module 05602 MIP-MEP mouthpiece 07048 User’s manual 03030 MIP-MEP option for W20s software 07209 Activation code card... - Page 6 MIP-MEP/SNIFF module user’s manual The following screen will appear: 1.2.1 PREDICTED SET SELECTION Press and the following screen will appear: 511-BI0-MU2 • REV. 1.04...
- Page 7 MIP-MEP/SNIFF module user’s manual Choose the desired predicted set for adults and/or children by pressing on them. A will appear on the option selected. Escapes this screen and moves back to the previous one Validates the input data and goes to the next screen. Not all the sets have predicted values for adults and children;...
- Page 8 MIP-MEP/SNIFF module user’s manual Activate desired graphics options and enter the delay time by pressing on them. A will appear on the option selected Escapes this screen and moves back to the previous one Validates the input data and goes to the next screen. The default value for the delay is 1.0 s, although the user can on the calculation of the measurement since no value in this first second (or the time configured by the user) is taken into account.
-
Page 9: Start-Up And Mip-Mep/Sniff Test Procedure
MIP-MEP/SNIFF module user’s manual 1.3. START-UP AND MIP-MEP/SNIFF TEST PROCEDURE Access to the MIP-MEP test by pressing from the main screen. 1.3.1. ENTERING PATIENT DATA When accessing the MIP-MEP Program, enter the patient details. Consult the section ENTERING PATIENT DATA of the general user’s manual of the DATOSPIR TOUCH spirometer. - Page 10 MIP-MEP/SNIFF module user’s manual equipment will show it on screen and it will not allow entering the screen of tests performance. Make sure that the shutter probe is connected to the module. Train the patient about the test performance, as his/her collaboration is essential for the correct execution.
- Page 11 MIP-MEP/SNIFF module user’s manual Escapes this screen and goes back to the previous one Enables to modify the Patient data Starts the maneuver Changes the test, from MEP to MIP or vice versa Performs the Report (If there are performed maneuvers) Once the maneuver is finished, repeat step 3 in order to perform more maneuvers.
- Page 12 MIP-MEP/SNIFF module user’s manual Warnings: >5%: indicates that the variation between the best 3 maneuvers is over 5%. Pressure/time Graphic for the best 3 maneuvers. Pressure/time Graphic for the selected maneuver (pressing one of the keys M1 to M5). ...
- Page 13 MIP-MEP/SNIFF module user’s manual code, or you perform other operations, the data might be lost. Anyway, the device will always warn you with a message on screen, before deleting the information. B. SNIFF PROBE If you have purchased the SNIFF probe, you can perform as well the peak nasal pressure test.
-
Page 14: Displaying The Results
MIP-MEP/SNIFF module user’s manual 1.3.3 DISPLAYING THE RESULTS Pressing on the parameters, at the upper right part of the test screen and new screen will appear containing the data on the maneuvers (up to 8 maneuvers). The following data will be displayed: ... - Page 15 MIP-MEP/SNIFF module user’s manual A. - PRINTING THE RESULTS Press and a report of Maximal or Minimal Pressures will be printed out with the same information displayed on the data screen: patient’s data and curves of selected maneuvers B. - SAVING TESTS IN THE INTERNAL DATABASE Press and the test will be saved in the internal database of the spirometer, in order to display it afterwards, print it out...
-
Page 16: Technical Specifications
MIP-MEP/SNIFF module user’s manual D.- CHANGING OF TEST Press to change from the expiratory test (MEP) to the inspiratory test (MIP) and vice versa E.- TRANSFERRING TESTS The MIP-MEP saved in the database can be transferred to a computer (See section of the general manual). -
Page 17: Control
MIP-MEP/SNIFF module user’s manual 2.3 CONTROL Number of maneuvers: Up to 8 maneuvers for each type can be performed (MEP and MIP) Duration of the maneuvers: The maximum duration is 8 seconds. Start of Maneuver: When the threshold of 2,95 hPa (±3 is surpassed. -
Page 18: Measurement Technique And Predicted Sets
MIP-MEP/SNIFF module user’s manual Start and end of the maneuver The start of a maneuver is considered when the level of 2,95 hPa (3 cmH is surpassed. The end of the maneuver is considered when there is a pressure variation lower than 1 hPa (1 cmH ... - Page 19 MIP-MEP/SNIFF module user’s manual Correct collaboration of the patient to get a maximum effort in the maneuvers. The patient must keep his/her hands against the cheeks and leave them flaccid to attenuate the pressure generated by the facial muscles. To measure the MIP, the patient must perform a deep inspiration from the position of Residual Volume and maintain the effort for at least 3 seconds.
-
Page 20: Cleaning And Maintenance
MIP-MEP/SNIFF module user’s manual B. SH WILSON Predicted normal values for maximal respiratory pressures in Caucasian adults and children. SH Wilson, NT Cooke, RHT Edwards, SG Spiro. THORAX 1984; 39:535-538. C. BLACK & HYATT Maximal Respiratory Pressures: Normal values and relationship to age and sex Black LF, Hyatt RE. -
Page 21: Preventive Maintenance
MIP-MEP/SNIFF module user’s manual To do so, proceed as follows: Disassemble the parts of the shutter probe or sniff probe Immerse each part in a CIDEX® OPA solution (follow the manufacturer’s instructions). Take care that the internal surfaces of all the parts get in contact with the solution, including the interior of the sniff probe and of the measuring tube line. -
Page 22: Corrective Maintenance
MIP-MEP/SNIFF module user’s manual that all the connections are perfectly connected, that no cable, no connector and/or any other element are broken or damaged. In case of detecting any anomaly that the user cannot solve, contact the after sales service of SIBEL S.A.U. or your distributor, to proceed with the checking or repair. - Page 23 MIP-MEP/SNIFF module user’s manual from being used normally, contact the SIBEL S.A.U. After- Sales Service and specify the problem in as much detail as possible. 511-BI0-MU2 • REV. 1.04...
