- Page 1 Operators Manual Operators Manual Manuel De L'Opérateur Manual del Operador - Spare Parts Book - Pièces détachées - Libro Despiece 870/30006/0...
-
Page 2: Health And Safety
Connecting To The Power Supply The machine is to be connected to the mains by a residual current circuit breaker (RCCB) or class II isolation transformer with the following characteristics: MINITILE 180 RCCB 230V In 3 A Id 20 mA... -
Page 3: Adjusting The Blade Guard
Adjusting The Blade Guard The machine is equipped with a continuous diamond rim blade. Even though this blade has been designed CAUTION for operator safety if unintentionally touched, pay particular attention to avoid contact between your fi ngers and the blade during operation of the machine. MINITILE &... - Page 4 Operating Instructions MINITILE & MAGIKTILE ONLY!! Cutting at 90° Position the cutting guide and lock it by tightening the knobs fully. (See Figure 5a) The picture on the right shows how to position hands correctlyduring cutting at 90°. The forward movement of the piece must be proportional to the blade cutting capacity, to prevent hazardous fragments that would involve accidents or injuries from breaking off.
-
Page 5: Maintenance
Maintenance Before performing any maintenance operation, ensure the machine is disconnected from the power CAUTION supply. MINITILE & MAGIKTILE ONLY!! DIAMOND BLADE DISASSEMBLY Remove the blade guard. Use the 4mm Allen Key to hold the motor shaft. Unscrew the blade fl ange block nut with the 19mm spanner. -
Page 6: Troubleshooting Guide
Consult local dealer. Warranty Your new Belle Group Tile Saw is warranted to the original purchaser for a period of one-year (12 months) from the original date of purchase. The Belle Group warranty is against defects in design, materials an workmanship. - Page 7 No.1 for Light Construction Equipment www.BelleGroup.com Belle Group Head Office Belle Poland sp. z.o.o. Belle Group (GB), Shanghai Office Sheen, nr. Buxton 96-200 Rawa Mazowiecka Room 213, Zhonghuang Building, Derbyshire. SK17 OEU GB. Ul. Mszczonowska 36, 1007 Zhongshan Nan Er Road,...
