AT-SP3X
Powered Bookshelf Speakers
User Manual
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT-SP3X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Audio Technica AT-SP3X

Summary of Contents for Audio Technica AT-SP3X

  • Page 1 AT-SP3X Powered Bookshelf Speakers User Manual English...

  • Page 2: Safety Precautions

    Safety precautions Although this product was designed to be used safely, failing to use it correctly may result in an accident. To ensure safety, observe all warnings and cautions while using the product. Important information Warning To prevent fire or shock hazard, do not expose this apparatus to rain or moisture. Caution Do not expose this apparatus to drips or splashes.

  • Page 3: For Customers In Canada

    Safety precautions Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 4: Notes On Use

    Notes on use Be sure to read the connected device’s user manual before use. Audio-Technica will not be liable in any way for any loss of data in the unlikely event that such losses should occur while using the product. Minimize the volume on your device before connecting the product.

  • Page 5: Part Names And Functions

    Part names and functions Left speaker Speaker body Speaker cable terminal Used to connect the speakers (L/R) to each other. Right speaker Speaker body Power button / indicator lamp Turns the product power on/off. Displays the current mode (Bluetooth mode or wired mode) and Bluetooth connection status of the product. Volume control knob Adjusts the volume.
  • Page 6 Part names and functions Audio input terminals Used to connect a RCA audio cable. The red terminal connects the right channel, and the black terminal connects the left channel. USB terminal (USB Type-A) Used for updating the firmware. This terminal is not normally used. It also cannot be used for USB charging. Power supply terminal Used to connect the AC adapter.

  • Page 7: Attaching The Rubber Feet

    Getting ready to use the product Attaching the rubber feet Before setting up the product, be sure to attach the rubber feet to the bottom of the speakers. About installation of the speaker Be sure to install the product on a level surface. Install the product while paying close attention to the placement of the left and right speakers.
  • Page 8 Getting ready to use the product Attaching an AC adapter replacement plug to the AC adapter Attach the AC adapter replacement plug for the outlet you are using to the AC adapter. Select the plug that fits the outlet you are using. Align the tabs on the underside of the plug with the recesses on the AC adapter, and slide the plug into the AC adapter until it clicks into place.

  • Page 9: Turning The Power On/Off

    Turning the power on/off Turning on the product Insert the plug of the AC adapter into the power supply terminal. Plug the AC adapter into an outlet. The indicator lamp will light in red. Press the power button. The power turns on, and the indicator lamp lights up as follows. Indicator lamp Status Lights solid green...
  • Page 10 Turning the power on/off Turning off the product Press and hold the power button (for at least 3 seconds). 3 SEC The indicator lamp will light in red.
  • Page 11 About wireless and wired connections The product can be operated via a Bluetooth wireless connection or a wired connection, according to user's preference. Wireless connection To connect to the product wirelessly via Bluetooth, please see "Wireless use" (p. 11). Bluetooth-capable turntable Wired connection To connect to the product using a RCA audio cable, please see "Wired use"...

  • Page 12: Wireless Use

    For information about using your Bluetooth device, refer to the device’s user manual. Select “AT-SP3X” and register it in the Bluetooth device that you will connect to. Some devices may ask for a passkey. In this case, enter “0000”. The passkey may also be called a passcode, PIN code, PIN number, or password.

  • Page 13: About Pairing

    Wireless use About pairing When connecting a new Bluetooth device, you need to pair it with the product. Once the Bluetooth device and the product are paired, you do not need to pair them again. The product supports multipairing, in which a connection history is saved.

  • Page 14: Listening To Music

    Wireless use Listening to music Make sure the volume of the product is turned all the way down before playing music from a connected Bluetooth device. Press the power button to enter Bluetooth mode (with the indicator lamp lit in blue). The product will switch between wired mode (with the indicator lamp lit in green) and Bluetooth mode (with the indicator lamp lit in blue) every time the power button is pressed.

  • Page 15: Wired Use

    Wired use The product can be connected to turntables or other audio equipment using wired connection. Connecting audio device Connect a commercially available RCA audio cable to the audio input terminal of the product. Be sure to match the color of the RCA audio cable plugs with the color of the audio input terminals.
  • Page 16 Wired use...
  • Page 17 Cleaning Get into the habit of regularly cleaning the product to ensure that it will last for a long time. Do not use alcohol, paint thinners, or other solvents for cleaning purposes. Use a dry cloth to clean the product. Wipe away any perspiration or dirt from the cable with a dry cloth immediately after use.

  • Page 18: Troubleshooting

    Troubleshooting Unable to pair (Bluetooth mode) Confirm that the Bluetooth device communicates using Ver. 2.1+EDR or higher. Place the product and the Bluetooth device within 1 m (3.3') of each other. Remove the pairing information for the Bluetooth device then pair the product with this device again. No sound is heard / Sound is faint (Bluetooth mode) Turn on the power of the product and the Bluetooth device.
  • Page 19 Dimensions (Unit: mm)

  • Page 20: Communication Specifications

    Specifications Speakers Speaker unit 76 mm (3.0”) × 2 Tweeter unit 27 mm (1.1”) × 2 Frequency response 55 to 20,000 Hz Maximum output 30 W Communication specifications Communication system Bluetooth version 5.3 Maximum RF output 10 mW EIRP Maximum communication Line of sight - approx.
  • Page 21 Specifications For product improvement, the product is subject to modification without notice.
  • Page 22 Trademarks ® The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc., and any use of such marks by Audio-Technica Corporation is under license. Other trademarks and trade names are those of their respective owners.
  • Page 23 株式会社オーディオテクニカ 〒194-8666 東京都町田市西成瀬2-46-1 www.audio-technica.co.jp Audio-Technica Corporation 2-46-1 Nishi-naruse, Machida, Tokyo 194-8666, Japan www.audio-technica.com ©2024 Audio-Technica Corporation Global Support Contact: www.at-globalsupport.com 351713930-02-01 ver.1 2024.07.01...
