Light Projects LEDStar 1 Installation Sheet

LEDStar 1,3,4 & XL
Installation Sheet 45xxxxxx
Issue Date: December 2022
Mounting Hole Dimensons
LEDStar 1
Spotlight
50
5
30
Min Hole size
without Mount Tube
38mm
Min Hole size
with Mount Tube
45mm
Luminaire should be installed by a qualified electrician in accordance with these instructions, IEE regulations and
local building regulations. Luminaire should not be modified in any way. Any modification will negate the approvals and
may render the product unsafe.
Metal encased Class III safety extra low voltage luminaire. Do not earth or mount in contact with any part of
the electrical installation connected to a protective earth conductor
CAUTION LED Radiation. Do not stare into beam. Class 2 Laser product.
Luminaire complies with relevant European directives and, in particular, with the requirements of EN60598
Luminaire complies with relevant UK regulation and, in particular, with the requirements of BS. EN60598
Ingress Protection rating: Fitting is protected against ingress of dust and temporary immersion in water
IP67
but is not suitable for continuous underwater use.
Technical Details
Part Number
LEDStar 1 45008xxx-xxx-xx-x
LEDStar 3 45033xxx-xxx-xx-x
LEDStar 4 45034xxx-xxx-xx-x
LEDStar XL 4520xxxx-xxx-xx-x
Possible Tools Required:
1.5mm, 2.5mm, 4mm & 5mm Allen Keys
8mm and 17mm Spanners
Supply: Use only with dedicated LED Driver
LEDStar 3 & 4 LEDStar 3 & 4
Spotlight
70
5
45
LEDStar 1
Recessed
120
Min 10mm
Max 40mm
LED Source
1 x CREE XP-G2 LED (2 SDCM Binning)
3 x CREE XP-G2 LED (2 SDCM Binning)
CREE CXB1310 COB LED (2 SDCM Binning)
CREE CXB1520 COB LED (2 SDCM Binning)
See product specific sheet for full details
LEDStar 3 & 4
Window Reveal
Wall
Locking
Screw
5
41
Min Ø38mm
Hole
Light Projects Limited
23 Jacob Street
London SE1 2BG
design@lightprojects.co.uk
Unless otherwise specified all drawing units are in mm
Tolerances: Linear Dimensions 0.5mm
Angular Dimensions 1
C 2013 Light Projects Ltd.
This drawing is the copyright of Light Projects Ltd and may not
be reproduced in whole or part without written permission
Life: See Individual Specsheets
Operating Temperature: -10°C to +40°C - See product
specsheet for special conditions
Supplied Cable: 3m 2-Core 0.75mm2 AO5RN-F Rubber
LEDStar XL
Spotlight
70
70
45
45
R2.25
LEDStar 3,4 & 5
Recessed
Min Hole size
without Mount Tube
150
65mm
Min Hole size
with Mount Tube
72mm
Product Code
Tel: 020 7231 8282
Description
Fax: 020 7237 4342
Material
Finish
Drawing Name
Drawn By
Sheet
Drawing No.
Spotlight Recessed Wall
0.15kg 0.14kg NA
0.63kg 0.6kg 0.63kg
0.63kg 0.6kg 0.63kg
1.3kg NA NA
5
PartNumber
Description
Material
Finish
DrawingName
Date
DrawnBy Dat
Scale
of
1
1
Rev.
DrawingNo
Window
Reveal
NA
0.65kg
0.65kg
NA
1:3
Re
