Sealey VSE4789 Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
instructions protection
1. SAFETY
DO NOT use with air tools.
8
Always keep the force screw well lubricated.
9
IMPORTANT! These instructions are offered as a guide only, albeit compiled with good practical user advice. Always refer to the vehicle
manufacturer's service instructions, or a proprietary manual to establish the current procedure and data.
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this tool.
‰
WARNING! Familiarise yourself with the specific applications and limitations of the kit, as well as any potential hazards.
‰
This kit should be used in conjunction with inspection maintenance procedures recommended in the vehicle manufacturer's manual.
9
Ensure that the kit is correct for the task.
9
Wear the appropriate personal protective equipment for the task. A full range is available from your Sealey Stockist.
9
DO NOT use the kit for any purpose other than that for which it is designed.
8
Ensure that the vehicle is properly supported with axle stands before working under the vehicle.
9
Ensure there is adequate lighting prior to using the kit. A range of inspection lamps are available from your Sealey Stockist.
9
Keep children and unauthorised persons away from the working area.
9
DO NOT use the kit if any parts are damaged or missing, as this may cause failure and/or personal injury.
8
DO NOT use the kit when you are tired, or under the influence of alcohol, drugs or intoxicating medication.
8
After use, store in a safe, dry childproof area.
9
WARNING! Failure to adhere to safety and warning instructions may result in personal injury or damage which would invalidate
‰
the warranty.
2. INTRODUCTION
Suitable for the removal/installation of the front upper control arm bushes on VAG group vehicles. The tool is designed to be used in situ
without having to remove the control arm from the vehicle, which includes the pinch bolt which is often seized and usually snaps. Each vehicle
has four upper control arms. Unique design of the adaptors means the bush is clamped securely, to aid alignment and guide the bush squarely
into position.
3. CONTENTS
Number Part No. Description
1 VSE4789-01 Adaptor A
2 VSE4789-02 Force screw
3 VSE4789-03 Collar
4 VSE4789-04 Force screw T bar
5 VSE4789-05 Press plate
6 VSE4789-06 Nuts (not shown)
7 VSE4789-07 Restraint bar
8 VSE4789-08 Adaptor B
9 VSE4789-09 Washers (not shown)
10 VSE4789-10 Bolts
11 VSE4789-11 Bridge bars
© Jack Sealey Limited
FRONT UPPER CONTROL ARM BUSH TOOL - VAG
VSE4789
MODEL NO:
Wear protective
gloves
Original Language Version
DO NOT USE AIR TOOLS
TO OPERATE FORCE SCREW
ALWAYS KEEP FORCE SCREW
WELL LUBRICATED. MOLYBDENUM
COPPER BASED RECOMMENDED.
VSE4789 Issue 1
X X
08/03/22
