- Page 1 TSL.410 Deck-Mounted Manual Soap Dispenser...
- Page 2 contents Safety and Warnings Box Contents Diagram Technical Data Before You Install Dimensions How To Install Commissioning & Operation Troubleshooting Cleaning Maintenance Warranty Contact Details TSL.410 MANUAL...
- Page 3 TSL.410 Read and save these instructions WARNING Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer (see back page for more details). For more information contact: Tel: +1 310 410 5008 info.usa@thesplashlab.com TSL.410 MANUAL...
-
Page 4: Box Contents
box contents Body Bottle connector Flat washer Base collar Fixing nut Fixing nut Soap feed pipe Soap reservoir TSL.410 MANUAL... - Page 5 diagram Body Bottle connector Base collar Soap feed pipe Flat washer Soap reservoir Fixing nut Fixing nut TSL.410 MANUAL...
-
Page 6: Technical Data
technical data Overview The TSL.410 is a stainless steel deck mounted soap dispenser, available in a variety of coloured finishes with a sleek and minimalist design. Codes Power Finishes TSL.410.CS Pump-action Brushed Stainless Steel TSL.410.CP Pump-action Brushed Copper TSL.410.BK Pump-action Brushed Black TSL.410.BR Pump-action... - Page 7 technical data Related Products Soap Feed Systems LST1 - 1.32 gallons reservoir with 78.74 inch feed pipe LST1 - 1.32 gallons reservoir with 2 x 6'-6 3/4" feed pipe LST1 - 1.32 gallons reservoir with 3 x 6'-6 3/4" feed pipe LST1 - 1.32 gallons reservoir with 4 x 6'-6 3/4"...
-
Page 8: Before You Install
Installation Requirements The soap dispenser is intended to be mounted in a countertop or basin adjacent to a tap. As a guide, The Splash Lab recommends a minimum distance of 4 inches betwwen the dispense and a tap. The TSL.410 is supplied with a single-feed reservoir fitted to the underside of the dispenser. -
Page 9: Technical Drawing
technical drawing SIDE FRONT 3 5/8” Ø 1 1/8” Ø 1 1/8” Soap cap adaptor Soap bottle Dispenser hole cut-out 1” TSL410 MANUAL... -
Page 10: How To Install
how to install Soap Installation Mark soap hole centers onto the surface Drill 1” diameter hole in countertop. for installation. Insert dispenser through hole in basin or Slide washer over mounting shank and countertop with the stainless steel bezel then tighten the fixing nut by hand. above the counter. - Page 11 how to install Soap Installation Assemble the 2nd nut on the mounting Connect the soap feed pipe to the spigot shank and then tighten this against the below the countertop 1st nut. (Use 2 spanners for this) Screw the bottle connector onto the Tighten the locking grub screw using a mounting shank so that 1 turn of thread 3/32"...
- Page 12 how to install Soap Installation Screw the reservoir onto the connector. Ensure all parts of the product are tight and do not move unintentionally. Once all nuts are tightened, use the pump action to dispense soap. WARNING: Ensure all connections are fully tightened to ensure full seal of the soap dispenser.
-
Page 13: Operation
commissioning Fill the reservoir with liquid soap of viscosity in the range of 100 - 3800 cPs Screw the reservoir onto the connector Pump the dispenser head until soap is dispensed from the spout operation The dispenser is depressed by the user, which draws a measured amount of soap (1ml) from the reservoir and is then dispensed from the spout onto the user’s hands. - Page 14 Use a soft cloth or sponge with a mild solution of soapy water as part of the regular washroom janitorial routine. Do not use abrasive or cream cleaners as these will damage the surface finish. If further information is required, contact The Splash Lab technical team for more detailed stainless steel care guidelines. soap A good quality liquid soap of viscosity 100 –...
-
Page 15: Maintenance
maintenance Occasionally purge the dispenser by pumping warm water (hand warm) through the unit. This will remove any congealed soap. refilling Single feed reservoir Unscrew the reservoir from the connector cap. Fill the reservoir with liquid soap of viscosity in the range 100 – 3800 cPs. Screw reservoir onto the connector, Pump the dispenser head until soap is dispensed from the spout. -
Page 16: Warranty
The Splash lab will replace necessary parts, free of charge, if they are defective from the manufacturer. The Splash Lab guarantees all of its products against manufacturing defects under the terms and conditions listed below Faucets TSL backs every faucet with a lifetime guarantee against material defect. - Page 17 contact General information info.usa@thesplashlab.com 310 410 5008 20809 Higgins Ct Torrance, CA 90501 Technical support info.usa@thesplashlab.com For further information visit: www.thesplashlab.com/usa TSL.410 MANUAL...
