KLLOM Bidet Manual
KLLOM is an instantaneous warm water bidet that uses direct water.
Since there is no hot water tank, there are no foreign substances and germs generated
from the hot water tank. It is clean and safe to use.
The safety precautions are for user safety and to prevent property
damage, so be sure to read and use it correctly.
· Quality is not guaranteed when used in regions with different rated voltages.
· The user manual includes the product warranty. Please keep it carefully so that it is not lost.
· The design and specifications of this product are subject to change without notice
for quality improvement.
KL300 Series
Intertec Co., Ltd.
Advertisement
Table of Contents
Summary of Contents for Intertec Data Systems KLLOM KL300 Series
- Page 1 KLLOM Bidet Manual KL300 Series KLLOM is an instantaneous warm water bidet that uses direct water. Since there is no hot water tank, there are no foreign substances and germs generated from the hot water tank. It is clean and safe to use. The safety precautions are for user safety and to prevent property damage, so be sure to read and use it correctly.
-
Page 3: Table Of Contents
Contents Safety Precautions Structure and name of the product How to install Operation check and maintenance How to use 11-13 Function comparison table by model Troubleshooting Specifications Warranty Card... -
Page 4: Safety Precautions
Safety Precautions Follow the instructions to avoid danger or property damage and to use the product correctly. Cautions are divided into “Warning” and “Caution” and their meanings are as follows. Violation of the instructions Violation of the instructions Warning Caution may result in death or may result in personal injury serious injury. -
Page 5: Caution For Safety
Safety Precautions If you use a toilet seat or a warm air dryer for a long time, there is a risk of low-temperature burns. Please be especially careful when using it by children, people who cannot control the temperature on their own, or those with sensitive skin. Warning Caution for safety Never connect the power supply... -
Page 6: Checks Before Installation
Safety Precautions Caution Caution for safety This appliance can be used by children aged Do not step on, climb or forcefully from 3 years and above and persons with lean on the toilet seat or toilet seat reduced physical, sensory or mental cover. - Page 7 Safety Precautions Safety Precautions Marking This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
-
Page 8: Structure And Name Of The Product
Structure and name of the product Bottom view Front view Lighting Seat cover Air inlet for Deodorization Caution sticker Body Main unit Warm air vent Main unit Release button Toilet seat(heated) water inlet Power cord Seat sensor Air outlet for Mounting plate Deodorization assembly area... -
Page 9: How To Install
How to install Precautions before installation Be sure to check the product and outlet voltage before installation. (Check AC220-240V) If electrical work is required, consult a qualified electrical contractor ; Be sure to ground the outlet to prevent short circuit or electric shock. Never connect power until installation is complete. - Page 10 How to install Rubber Install the mounting plate guide on the toilet bowl. expansion (1) Insert the "rubber expansion" into the toilet hole. (2) Install the mounting plate guide correctly. (3) After inserting the washer on the bolt, Mounting use a + screwdriver to fix it to the rubber extension. plate guide + screwdriver ※...
-
Page 11: Operation Check And Maintenance
Operation check and maintenance Operation check Open the water supply valve so that water can be supplied to the bidet body. Check the piping connections for water leaks. If a leak is confirmed, close the water supply valve, repair the leaking part, and then install it again. -
Page 12: How To Use
How to use Use the toilet seat temperature at level 1 or level 2 when used by persons requiring attention as follows. Children, the elderly, people with weak skin, or taking sleep stimulants (sleeping pills, cold medicine), etc. may cause low-temperature burns or accidents, so be careful. -
Page 13: Water Temp
How to use Dry Temp Press "+ "(High) or "-" (Low)" to adjust the drying temperature from 1 to 6 levels. The water pressure LED will switch to the drying temperature indication. When the drying function is stopped, the water pressure setting LED is displayed. When the function is activated, it operates at the drying temperature set before use. -
Page 14: Convenient Function
How to use Rhythm massage When you press the rhythm massage, ①Soft cleaning, ② Impact massage, ③ Soft cold and hot massage, ④ Impact cold and hot massage, ⑤ Finish rinse cleaning are performed for 5 minutes. Rhythm Massage is a “Rear” only function and cannot be used with “Front”... -
Page 15: Function Comparison Table By Model
Function comparison table by model Control panel KL300 KL301 KL302 Function comparison table by model Division KL300 KL301 KL302 Cleaning method Instantaneous warm water Instantaneous warm water Instantaneous warm water Rear cleaning ○ ○ ○ Front cleaning ○ ○ ○ Cleaning Move cleaning ○... -
Page 16: Troubleshooting
Troubleshooting ※ Please check before applying for service. Problem Checklist • Check the water supply shutoff. No water is • Check that the water supply valve is closed. coming out. • Check if the mesh filter (water filter) is clogged. •... -
Page 17: Specifications
Specifications Model KL300 KL301 KL302 Rated voltage 220-240V~, 50-60Hz Rated power consumption 1 700 - 2 000W Length of Power cord about 4.9ft ( 1.5 meters ) Water supply method Direct Inlet flow type Requested water pressure range 0.07~0.75MPa (10.15~108.8psi) Water supply control Static pressure solenoid valve Heat exchange method... -
Page 18: Warranty Card
Warranty Card Warranty Card Thank you very much for purchasing this product. The product is warranted according to the description written on this warranty card. Please submit this warranty card to service center when there are malfunctions. Model : Serial NO : Purchaser Company : Address :... - Page 19 Memo...
- Page 20 Warranty Card Warranty Card Warranty Card Address : 15, Dongtangiheung-ro, Hwaseong-si, Gyeonggi-do, Republic of Korea Tel : +82-31-8015-2620. Fax : +82-31-8015-2625 https://intertec.co.kr...
