WCM-9116 Instruction Manual SL

=EX=

=QA=

=QS=

Checked by

Title

=QB=

=QC=

General Tolerance

=QF=

Occurs

Modification Text

Approved by

WCM Instruction Manual SL

Page

1 / 15

Document Number - Revision

11357606 - 00

Table of Contents

Need help?

Do you have a question about the WCM-9116 and is the answer not in the manual?

Questions and answers

Summary of Contents for WCM WCM-9116

Page 1 Internal Internal WCM-9116 Instruction Manual SL =EX= =QA= =QB= =QC= General Tolerance =QS= =QF= Occurs Modification Text Checked by Approved by Page 1 / 15 Title Document Number - Revision WCM Instruction Manual SL 11357606 - 00...
Page 2: Table Of Contents
Regulatory Window ..................... 10 Figure 10 RS9116W-DB00-CC0 Top ......................13 Figure 11 WCM-9116 Label ........................13 Figure 12 RS9116W-BD00-CC0 labeled WCM-9116 ................. 13 Figure 13 Final assembly labeled ......................14 Table 1 Part Numbers to be used by Host ....................5 Table 2 Channel Numbers and Corresponding Center Frequencies ............
Page 3: Introduction
Dräger products that want to implement the WCM-9116 (MS40251 as a wireless solution for the product. The WCM-9116 (MS40251) is not intended for sale to third parties and may only be installed within Dräger products.
Page 4: Installation
Internal Installation The WCM-9116 (MS40251) uses the Silcion Labs RS9116W-DB00-CC0 Wi-Fi module which is solderd to a PCBA and connected to one of the approved antennas listed in section 5 Approved Antennas via a u.fl connector. Figure 1 is an outline of the RS9116W-DB00-CC0 Wi-Fi module PCB landing pattern with dimentions from the Silicon Labs data sheet.
Page 5 Dräger product that will use the MS40251 PBA WCM-9116 INTERPOSER must be sure to provide PCBA clearance to mount the WCM-9116 PBA. The host will also need to install 3 PEM Standoffs M2x2 to secure the PBA (Figure 1, detail A) and the mating connector for the HIROSE DF40C-50DP-0.4V(51) (Figure 1, detail B) Table 1 provides Drager release parts that can be used on the Host platform.
Page 6: Block Diagram
Section 5 to U.FL Test U.FL Connector Conn Points Figure 5 RS9116 CC0 Block Diagram RS9116 CC0 block diagram provided by Silcon Labs datasheet Title Document Number - Revision Page ¤ WCM Instruction Manual SL 6 / 15 11357606 - 00...
Page 7: Wlan Performance Test Application
Qt program that manages the configuration of a Silicon Labs RS9116W CC0 module. wchost270 runs on a Windows Host PC (Win10 tested) and interacts with the WCM-9116 over a 4-wire SPI interface by way of a Diolan 4S USB adapter. The wchost270 program serves as a software prototyping and module-centric configuration and test platform for the WCM-9116 Interposer with RS9116W radio module.
Page 8: Transmit Test
* For more information about using the World region, custom gain tables, and power indices, see Silicon Labs document AN1337: RS9116 Regulatory Certification Application Note Title Document Number - Revision Page ¤ WCM Instruction Manual SL 8 / 15 11357606 - 00...
Page 9: Per Stats (Receive)
2. Under PER Stats, select Issue and Enable, then click on the Send button. 3. Clicking on the Clear button will clear all start and reset to zero. Title Document Number - Revision Page ¤ WCM Instruction Manual SL 9 / 15 11357606 - 00...
Page 10 Internal Internal Figure 7 wchost270 Regulatory Window Title Document Number - Revision Page ¤ WCM Instruction Manual SL 10 / 15 11357606 - 00...
Page 11: Approved Antennas
Low = 5745 MHz Mid = 5785 MHz High = 5825 MHz 802.11a (5GHz U-NII-3) 802.11n 20 MHz MCS0 (5GHz U-NII-3) MCS4 MCS7 Title Document Number - Revision Page ¤ WCM Instruction Manual SL 11 / 15 11357606 - 00...
Page 12: Fcc And Ic Declaration
Internal Internal FCC and IC Declaration PBA WCM-9116 INTERPOSER (MS40251) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation.
Page 13: Labelling Instructions
Internal Internal 7. Labelling Instructions WCM-9116 label (Figure 11) is to be applied to top of RS9116W-DB00-CC0 (Figure 10) See Figure 12. J1 of PCBA (Figure 13) Figure 8 RS9116W-DB00-CC0 Top Figure 9 WCM-9116 Label Figure 10 RS9116W-BD00-CC0 labeled WCM-9116...
Page 14 Internal Internal Figure 11 Final assembly labeled Title Document Number - Revision Page ¤ WCM Instruction Manual SL 14 / 15 11357606 - 00...
Page 15: Change History
December 6, 2022 RS9116 CC0 Connectivity Module Datasheet V1.0.12 December 2022 MS40254 SCH WCM-9116 INTERPOSER July 6, 2023 11152028 PBA WCM-9116 INTERPOSER Elec Assy Drwg July 6, 2023 11275361 PBA WCM-9116 INTERPOSER Mechanical Draw 8/3/2023 Abbreviations and Definitions Abbreviation Definition...
