Page 2
Technical specifications of the Output Relay Card General Model FDR0508-01 Dimensions 10 cm (length) × 5.6 cm (height) × 18.5 cm (depth) Weight 0.3 Kg Operating Temperature -10°C to 45°C Storage Temperature -20°C to 60°C Operating Humidity 0% to 60% Operating Voltage 12 V Guaranty...
SAFETY PRECAUTIONS (Before using this product, read the precautions) Please carefully read this manual before using the product and pay full attention to the mentioned points to use the product correctly. In this guide, safety measures are classified into two levels: " Warning"...
Page 4
operating environment may result in electric shock, fire, malfunction, or damage, and degrade the quality of the module. ● Never directly touch the conductive parts or electronic components of the output relay card. Doing so may cause malfunction or failure of the data logger. Note: Never insert or remove cards while the device is powered on.
Page 5
1. Introduction The Output Relay Card Model FDR0508-01 is a key component in industrial automation systems for controlling electrical equipment. The output relay card has the capability to control eight relays simultaneously, allowing for the management of various equipment such as motors, pumps, solenoid valves, and lighting through small control signals.
Page 6
2. Settings The eight switches on the right side of the card are used to activate or deactivate channels, allowing the user to enable or disable any desired channel as needed. Note: To make any changes to the card settings, be sure to completely power off the device and disconnect its main power supply.
Page 7
3. Indicators on the Card Figure 3: Image related to Card Cover The top row of lights indicates the activation and deactivation of the channels , while the bottom row of lights shows whether the channel is on or off. An off channel means that the relay is active but not executing any command.
Page 8
4- Installing the output relay card on the FIDAQUIRE data logger The process of identifying and initializing the card is completely automatic, and after installing and setting up the data logger device, the card will be displayed on the Cards list page. After initializing the card, the channel information will also be displayed on this page (Figure 4).
Page 9
5- Card and Nodes Settings ● The Config menu of the output relay card includes the General, Active Channels, and Channels Data Map stages, which are briefly explained below: ■ The General page is for the general settings of the card. Fill in the Card Name and Card Description fields (Figure 5).
Page 10
Figure 6: Active Channels Page from Config Menu ■ On the Channels Data Map page, you can name the channels and select the last state of the channel after power is connected. Open (Disconnected) means the channel will be off after power is connected, Close (Connected) means the channel will be active as soon as power is connected, and Keep Last State will maintain the last state.
Page 11
● The Alarms menu displays the list of defined alarms for each channel. It is possible to edit, activate or deactivate, and delete the alarm, and the Logs menu provides a detailed list of alarm information and the time of occurrence (Figure 8). Figure 8: Observing Defined Alarms Page for Card ●...
Contact Information Behineh Process Electronics Fidar Engineering Company Phone: +98-21-91308515 Address: West Azerbaijan - Urmia, 10th kilometer of Serow Road, Provincial Science and Technology Park, Headquarters Building, First Floor Email: info@fidarelectronics.com Website: www.fidarelectronics.com...
