Summary of Contents for Kentek Syncro ASM
- Page 1 Syncro ASM Analogue Addressable Marine Fire Control Panel User Manual Man-1100M Issue 02 October 2009...
-
Page 2: Table Of Contents
..................8 5.2 View Devices ....................8 5.3 Test Zones ..................8 5.4 Set System Time ................9 5.5 Contamination Status ..................9 5.6 Access Level 3 6. Routine Maintenance ..................9 Page 2 of 9 Product Manuals/Man-1100M Syncro ASM User_02... -
Page 3: Introduction
1. Introduction The Syncro ASM is a single or two loop analogue addressable fire detection and alarm control panel that conforms to the requirements of European Standards EN54-2:1997 and EN54-4:1997. It is capable of covering a maximum of 16 zones (500 zones on a network) with 126 devices for Apollo protocol, and 127 devices per loop for Hochiki protocol. -
Page 4: Panel Controls
3. Panel Controls 3.1 Access Level 1 The front panel contains controls for operating the panel. Fig 1 – Syncro ASM Front Panel Lamp Test Press this button to illuminate all front panel indicators and validate correct operation. Silence Buzzer This button will silence the internal buzzer, and will illuminate the Buzzer Silenced panel indicator. -
Page 5: Access Level 2
…………………………. Silence Alarm / Acknowledge This button is normally used to mute any fire warning sounders fitted to the Syncro ASM panel. These sounders are installed throughout the protected premises and are used to evacuate the premises. In some cases, the fire warning sounders may be delayed; to allow a search time before building evacuation commences. -
Page 6: Panel Operation
The panel controls will now be enabled and will remain enabled for about 1 minute after the last key has been pressed. Pressing the Acknowledge Alarm button will now silence the sounders Page 6 of 9 Product Manuals/Man-1100M Syncro ASM User_02... -
Page 7: Alert Event
All detection devices, including manual call points, are disabled in the selected zone. Disable Addresses Any loop device can be disabled using this menu option. In devices with more than one input or output, then each sub-address may be individually disabled. Page 7 of 9 Product Manuals/Man-1100M Syncro ASM User_02... -
Page 8: View Devices
Each zone may be individually put in to a Test Mode condition. When test mode is selected, the devices in the zone may be tested and the Syncro ASM panel will automatically reset after 3 seconds. This is used for one man testing of the fire system. -
Page 9: Contamination Status
5.6 Access Level 3 This menu option is used to enter the access 3 password for the engineering function menu. Details of the options available at Access level 3 can be found in the Syncro ASM Product manual. 6. Routine Maintenance Syncro ASM control panels do not require any specific maintenance but should the control panel become dirty it can be wiped over with a barely damp cloth.
