Summary of Contents for Zotac GAMING ZONE

Page 2: Table Of Contents
Table of Contents Hardware Overview ��3 Front View �� 3 Rear View �� 4 Top View �� 4 Bottom View �� 5 Specifications ��6 Getting Started ��8 Charging �� 8 Starting For The First Time �� 8 WiFi Setup �� 8 Bluetooth Setup ��...
Page 3: Hardware Overview
Hardware Overview Front View 1. Direction Pad Up, down, left, right buttons primarily used to interact with games Twist left or right to quickly adjust system settings. Configurable in ONE 2. Left Radial Dial Launcher App 3. Left Thumbstick Joystick primarily used to interact with games 4.
Page 4: Rear View
Rear View 17. Right Trigger Toggle Toggles the travel distance of the right trigger 18. Macro 1 Button For input shortcuts. Configurable via ONE Launcher App. 19. Kickstand Allows the device to stand upright 20. SPECTRA Light Bar ARGB light bar. Lighting patterns configurable via ONE Launcher App. 21.
Page 5: Top View
Top View Analog input primarily used to interact with games. Travel 23. Left Trigger Distance can be toggled. 24. Left Bumper Button primarily used to interact with games. Turns on or off the device. Supports Windows Hello 25. Power Button and Fingerprint Reader fingerprint login feature Shows battery and charge status.
Page 6: Specifications
Specifications q Dimensions v 285 x 115 x 35 mm / 11.2 x 4.5 x 1.4 in q Weight v 692g / 1.53lbs q Color v Gunmetal Grey q Processor v AMD Ryzen 7 8840U v AMD Radeon™ 780M Graphics v 15W Default, Max 28W q Memory v 16GB LPDDR5X 7500MHz (onboard)
Page 7 q Battery v Polymer Smart Lithium-Ion battery, 3 Cells 11.55/48.5Wh v Max Battery Life: 1.25~7.5hrs v Rapid Charging: Power off/Sleep:~ 1.4hrs q AC Adapter v Output Power: Type C Adapter 20V@3.25A 65W v PD 3.0 specification v AC 100~240V 50~60Hz, Type A/Type C/Type G/Type I q Security v Fingerprint Security v Software TPM...
Page 8: Getting Started
Getting Started Charging 1. Use included power adapter to charge. 2. Insert a suitable plug to power adaptor if necessary. 3. Plug the USB-C cable into one of the USB ports on the ZONE to begin charging. Battery Indicator The three LEDs on top displays the current battery level, as well as charging status when charging. 3 Solid Lights above 66% battery 2 Solid Lights...
Page 9: Airplane Mode
Dirt, oil or moisture on your finger may also prevent the fingerprint reader from working as intended. ONE Launcher APP The ZONE is designed to work with the ONE Launcher, ZOTAC’s handheld software to provide a one- stop gaming experience between gaming platforms as well as allowing users to customize aspects of the ZONE.
Page 10 Outside of games, the ZONE defaults to Desktop Mode with the following control scheme: Right Analog Stick Mouse Cursor Left Analog Stick Arrow Keys Left Bumper Alt + Left Arrow Key Right Bumper Alt + Right Arrow Key Left Trigger Right Mouse Button Right Trigger Left Mouse Button...
Page 11: Entering The Bios
Entering the BIOS To enter the BIOS on the ZONE, connect a physical keyboard through either USB ports. When the de- vice is booting, press F7 until a list of bootable device appears. Select “enter setup” to enter the BIOS, or select an alternate booting device if needed.
Page 12: Cleaning
Cleaning 1. Power: Disconnect the DC power before cleaning your device. 2. Cleaning Method: • Use a clean cellulose sponge or lintless cloth slightly dampened with warm water or a solution with a low concentration of nonabrasive detergent. Do NOT use a cloth or sponge that is completely soaked.
Page 13: Appendix
Appendix FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two condi- tions: (1) This device may not cause harmful interference, and (2) this device must accept any interfer- ence received, including interference that may cause undesired operation. Any Changes or modifica- tions not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
Page 14: Ce Compliance Statement
être évitée. CE Compliance Statement ZOTAC declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. For the full RED DoC file, Please download it as follow web: www. zotac.com/zonesupport The wireless operation frequency: Bluetooth: 2402-2480MHz, Max output pow- er ≤...
