Summary of Contents for STEMCO AXLE PRO EQUIPMENT
- Page 1 A NEW EVOLUTION IN AXLE ENHANCEMENT Instruction Manual...
-
Page 2: Safety Information
..........2 STEP 5: Alignment Bushing & Drill Placement ....9 The first step in using the Axle Pro Equipment is SAFETY FIRST SAFETY ALWAYS. Please take a moment to make PART LIST/PHOTO GLOSSARY ......4 sure these safety precautions are in place. These components are heavy! For your protection wear safety shoes, STEP 6: safety glasses and use proper lifting techniques. - Page 3 (See Fig. 1A) 2. Clean and inspect axle eye. Using a measuring tool (telescoping gauge and micrometer or STEMCO Kaiser “go no go gauge”) measure your axle eye size. Determine FIG. 1A FIG.
- Page 4 AXLE PRO EQUIPMENT INSTRUCTION MANUAL AXLE PRO EQUIPMENT CROSS-REFERENCE MATRIX AXLE PRO EQUIPMENT CROSS-REFERENCE MATRIX KING PIN APE MASTER APE CUTTER APE REPLACEMENT APE REAMER SLEEVE KING PIN APE MASTER APE CUTTER APE REPLACEMENT APE REAMER SLEEVE AXLE CODE APE CUTTER #...
- Page 5 AXLE PRO EQUIPMENT INSTRUCTION MANUAL STEP 3: STEP 4: AXLE ALIGNMENT ASSEMBLY LEVELING BAR & DRILL SPEED SETUP 1. Install four threaded rods with welded nuts against 1. Place narrow edge of leveling bar against upper plate upper plate. (See Fig. 4A) (Upper plate has no cut-out.) Do Not Tighten.
- Page 6 (See Fig. 9A) 2. Start drill motor, carefully lower cutter into upper plate 2. Using a STEMCO Kaiser bushing driver and brass hammer and slowly begin cutting process. Slow/steady cutting drive axle sleeve into position until flush. (See Fig. 9B) motion is important.
-
Page 7: Maintenance
Learn more at stemco.com Mississauga, ON L55 1R8 | Canada STEMCO, STEMCO Kaiser, Axle Pro Equipment (APE), and QwikKit are trademarks of STEMCO Products Inc. Printed in the USA. © 2024 STEMCO Products Inc. | Part No. 577-0092 | Rev. 5/24...
