Summary of Contents for MUKUTA 10 Lite
- Page 1 ELECTRIC SCOOTER INSTRUCTION MANUAL...
-
Page 2: Table Of Contents
1 Handle assembly instructions ..........01 2 Getting started guide ............... 04 3 Display operation and porgramming........06 4 The battery and motor instruction ..........13 5 Learning to ride................ 14 6 Daily protection and maintenance ........... 15... -
Page 3: Handle Assembly Instructions
Handle assembly instructions Handle assembly instructions... - Page 4 Handle assembly instructions 1. Insert the T bar into the groove of the main tube. 2. Secure the T bar with screws. (Be careful not to tighten too much).
- Page 5 Handle assembly instructions 3. Adjust the T bar to a comfortable positionand then tighten the screws diagonally one by one.
-
Page 6: Getting Started Guide
Getting started guide Step 1. Loosen the folding buckle Step 2. Take out the hook Step 4. Snap the handlebar's safety hook into Step 3. Fold down the main pole the rear shim... - Page 7 Getting started guide After power on, press power key, then L1 shows on the screen, indicating grade 1. Press again power key, then L3 shows on the screen indicating grade 3. This speed controller maintains the speed between 1 km/h and 65 km/h.
-
Page 8: Display Operation And Porgramming
Display operation and porgramming Speed Level Throttle Speed (km/h) Mode / Enter + Button Battery Indicator - Button Current voltage value NFC card area Token IR Reader Basic operation: 1、Function 1. Displayed content Speedometer / Odometer / Trip meter / Battery level / Cruise-control active light / Gear ondocator / Fault warning light 2. - Page 9 Display operation and porgramming 3.1 Speed display area Unit：mph, km/h The speed signal is taken from the Hall signal inside the motor. Sent to controller by controller (Time of single Hall period,unit:1MS).The display calculate the true speed based on wheel diameter and signal data calculate the true speed (The motor Hall also needs to set the number of magnetic steel) 3.2 Scooter power gear adjustment 0-3 digital display...
- Page 10 Display operation and porgramming Display P-Codes(programming codes) To access this menu,long-press . Use button to scroll through P-codes, change parameterd P01: Backlight brightness: The 1 level is the darkest, Level 3 brightest; Default: 3 P02: Mileage: unit, 0：km;1：MILE; Default: km P03: Voltage level: 24V, 36V, 48V, 52V, 60V, Default: 52V P04: Dormancy time: 0 means no dormancy;...
- Page 11 Display operation and porgramming 2、Introduction of buttons and interfaces 1. When it is shutdown, long-press hold button continuously for 2s to turn on the power. When it is power on ,It can change interface between the ODO、TRIP、VOL, by pressing for short time.
- Page 12 Display operation and porgramming 3、Card binding instructions 1.The instrument is not bound to ID card: After starting up, the LCD displays the normal contents, and the card swiping area displays the power voltage. At this time, the meter can directly enter the working state. The diagram below: 2.How to bind ID card: CARDS are bound by factory defaultLate setting: When using mobile phone or NFC functional card binding,...
- Page 13 Display operation and porgramming 3. The instrument has been bound with ID card: after starting up, the LCD displays card, the power voltage is not displayed in the card swiping area, and the swiping indicator flashes, indicating that the card needs to be swiped to start up.
- Page 14 Display operation and porgramming Dual and Single Press the once to activate the Dual Drive Motor function. Pressing it again will allow Single Drive Motor Function...
-
Page 15: The Battery And Motor Instruction
The battery and Instructions for motor use... -
Page 16: Learning To Ride
Learning to ride... -
Page 17: Daily Protection And Maintenance
Daily protection and maintenance... - Page 18 Daily protection and maintenance Pls avoid recharge when the power is used up, and recharge power timely, it can increase the battery service life. Under normal temperature using, the battery can work for high range and feature. Under below 0℃ temperature, the battery will reduce range and feature.For example, under -20'c temperature, the range only is half of normal temperature even less than half.
- Page 19 Daily protection and maintenance If the main rod shakes during the running, please tighten the nuts for clamp and secure it. If the main rod shakes during the running, please tighten the nuts for clamp and secure it.
