- Page 1 INSTALLATION OF TetraFlex ® SYSTEM...
- Page 2 INSTALLATION OF TetraFlex ® SYSTEM Configuration of BS421 and SB421 ▪ The system is delivered as a Turn Key solution. • BS421 Base station • Service Box SB421 installed with WinXPe Sp2 • TetraFlex ® software package preinstalled • System and client dongles (License) ▪...
- Page 3 ▪ WAN IP configuration for client access ▪ BS421 ▪ Frequency *) *) If known and entered in the System Configuration (order) this will be setup as default by DAMM Please refer to manuals in case further configuration is needed.
- Page 4 TetraFlex ® System Layout With service box SB421 BS421/1 BS421/2 WAN TCP/IP and OpenH323 connection for •HotLine Router (To be mandatory) •NMWS Client IP:192.168.201.11 IP:192.168.201.12 •Dispatcher Client •PABX/IP-telephone •Gatekeeper (e.g. Innovaphone IP400/800) •Etc. IP-Telephone SB421 includes: -48V DC •Pentium PC SB421 •- 48V Power supply IP200...
- Page 5 SB421 48V to external battery back Internal Backup Battery 2 hrs. With 1 BS421 1 hr. With 2 BS421 Minimum values Synchronization LED’s BSC (CPU) Unit Backplane / interconnection card TR1 ON/OFF TR2 ON/OFF CPU Unit ON/OFF LAN ON/OFF External Battery Temperature select Fuses Lightening arrestors Etc.
- Page 6 SB421 Interconnection Board Fuses Temperature sensor select BSC on/off TR1 on/off TR2 on/off Synchronization LED’s LAN power on/off...
- Page 7 SB421 Connection Modules SYNC and Temperature sensor TR1/2 LAN and -48V -48V for external LAN / WAN Alarms equipment LAN/WAN Connection Module TR Connection Module...
- Page 8 SB421 BSC LAN TR1 + TR2 CF Card (Not on TetraFlex ® LAN / WAN BSC Serial Number Status LED...
- Page 9 SYSTEM How does BS421 get its IP address? When the system is delivered from DAMM, the SB421 and the BS421(s) are paired together and should start up without any need of configuration change. BS421(s) are assigned an IP from a DHCP server located on the SB421 The IP assigned are 192.168.201.11 for BS421_1, 192.168.201.12 for...
- Page 10 INSTALLATION OF TetraFlex ® SYSTEM Change of BS421 IP address Open C:\Programs\DHCPServer\dhcpsrv.ini in a text editor All entries above the dotted line are factory preset and MUST NOT be changed If only one IP / MAC is shown it should be assigned 192.168.201.11 (If two BS421, the second should show 192.168.201.12).
-
Page 11: Service Cable
INSTALLATION OF TetraFlex ® SYSTEM Service Cable BS421 Service cable includes • 3 wire power cable • 1 x LAN cable (LAN and 1 sec. pulse) RX/TX A OUT A Power cable LAN to SB421 consisting of: 1 LAN connection (2 pairs) 1 ”LAN”... - Page 12 INSTALLATION OF TetraFlex ® SYSTEM Placement The recommended placement of the Base Station is as close to the antennas as possible to reduced cable loss. The placement of the Base Station and Service Box shall be such that it is securely fastened to a mast or building that is able to carry the weight of the units and withstand the local environmental conditions.
- Page 13 INSTALLATION OF TetraFlex ® SYSTEM BS421 Environmental / climatic requirements The Base Station is designed for outdoor operation, such that it can be placed in the antenna mast close to the antennas. The Base Station is designed to be able to operate at severe environmental conditions. The Base station is guaranteed to operate from –25 to +55 C ambient temperature.
- Page 14 INSTALLATION OF TetraFlex® SYSTEM SB421 Environmental / climatic requirements The Service Box is designed for outdoor operation, such that it can be placed on base of the antenna mast. The Service Box is designed to be able to operate at severe environmental conditions.
- Page 15 End of INSTALLATION TetraFlex ® SYSTEM...
