LightSKIN U8 User Manual

Dual cut off High and low beam bike front light
Package Contents
① U8
② Handlebar Mount
③ Garmin to Gopro Adapter
④ USB A to C Cable
⑤ USB A to C Adapter
②
⑥ 2mm Hexagonal Wrench
⑦ User Guide
Specifications
Light Module Low Beam : Aspherical TIR lens
High Beam : MLA Head Lamp Technology
Low Beam Mode Strong / Normal / Power saving / Low Beam Flash(Night)
High Beam Mode Strong / Normal / Daylight Flash(Daylight)
Battery Lithium Ion Battery 21700 / 5,000mAh
Run time Low Beam – 8.5Hours / High Beam – 4Hours
Charging time 4Hours
Dimension / Weight 31x31x118mm / 185g
IP Rating IPX6
KC certificate YU101934-23001
Installation
When using handlebar bracket
When mounted
under the handlebar
Fix the detachable
bracket on the top.
※ Tighten the screw carefully,
ensuring not to exceed a maximum torque of 0.8 Nm
When using
GoPro & Garmin bracket
When mounted
on the handlebar
Fix the detachable
bracket to the bottom.
With a hexagonal wrench,
Secure the detachable mount to the bottom
※ Tighten the screw carefully,
ensuring not to exceed a maximum torque of 0.8 Nm
detachable mount
③ ④
① U8
With a hexagonal wrench,
Secure the detachable mount to the top
Parts Name
ON/OFF &
High/Low beam Button
⑥
⑤
Low Beam lens
High Beam lens
Rubber cover for charging
USB-C Charging port
Installation Angle
Long-distance/road riding, road bike – adjust the low beam to horizontal
It is recommended to be installed horizontally
Most
Medium-distance/Bicycle Road, Downtown – Adjust the high beam to Horizontal
Recommended
Short-distance/Mountain, Downhill – Adjust the High Beam cut-off line to Horizontal
Mode Change Button
Detachable bracket
fixing groove
Side beam lens
High Beam Cut-off Line
High Beam
3.4˚
Low Beam Cut-off Line
3.4˚
Low Beam
3.4˚
3.4˚
High Beam Cut-off Line
3.4˚
3.4˚
Low Beam
High Beam
Low Beam
High Beam
Low Beam
Horizontal
High Beam
