WARNING
•Improper installation, adjustment, alteration, service, or maintenance can cause injury or property
damage. Read the installation, operating, and maintenance instructions thoroughly before installing or
servicing this equipment.
WARNING
•Do not store or use gasoline or other flammable vapors and liquids in vicinity of this or any other
appliance.
•An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.
DANGER
If you smell gas:
1) Shut off gas to appliance.
2) Extinguish any open flame.
3) If odor continues, keep away from appliance and immediately call gas supplier or fire
department.
4/24/2017
FPPK Flame Control System
WARNING: FOR OUTDOOR USE ONLY
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
840-FPPK
Installation
We suggest that our products be
installed by professionals that are
locally licensed by the authority having
jurisdiction in gas piping.
Service
We suggest that our products
be serviced by a professional
certified in the US by the
National Fireplace Institute
(NFI) as NFI Gas Specialists.
1
