Set-Top Box & Remote
KSTB2020
User Guide
Rev. 012120

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KAON KSTB2020 and is the answer not in the manual?

Questions and answers

Related Manuals for Blonder tongue KAON KSTB2020

Summary of Contents for Blonder tongue KAON KSTB2020

  • Page 1 Set-Top Box & Remote KSTB2020 User Guide Rev. 012120...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WHAT’S IN THE BOX? _____________________________________________ SET-TOP BOX AT A GLANCE ______________________________________ REMOTE CONTROL FUNCTIONALITY ______________________________ KURV 1.0 SEARCH REMOTE _______________________________________ KURV 2.0 VOICE REMOTE ________________________________________ KURV 1.0 / KURV 2.0 REMOTE OK BUTTON FUNCTIONALITY _______ KURV 1.0 / KURV 2.0 REMOTE GOOGLE ASSISTANT BEHAVIOR ____ KURV 1.0 / KURV 2.0 REMOTE BATTERY INSTALLATION ___________...

  • Page 3: What's In The Box

    KSTB2020 - User Guide WHAT’S IN THE BOX? KSTB2020 Set-Top Box Power Adapter (STB) HDMI Cable KURV Remote RCA Analog Composite KURV 2.0 Voice Remote Control Breakout Cable Shown (Optional) AA Batteries...

  • Page 4: Set-Top Box At A Glance

    KSTB2020 - User Guide SET-TOP BOX AT A GLANCE Top View Front View Status Indicator LED: Indicates power status of STB (Red = Off, Green = On). Infrared (IR) Sensor: Used to communicate with the Power Button: KURV Remote Control. Used to power the Kaon STB On or Off.

  • Page 5: Rear View

    KSTB2020 - User Guide Rear View Side View RJ45: USB: 10/100 Ethernet port used to This port has an output connect to a home router. power capability of 5V DC @ 1 amp. HDMI: Digital A/V output, used to connect to a TV via HDMI cable. AV Out: SD Analog A/V output, used to connect to older-style TVs...

  • Page 6: Remote Control Functionality

    KSTB2020 - User Guide REMOTE CONTROL FUNCTIONALITY Backlighting Hot Keys The remote control is a motion detecting device and will backlight when the remote is picked up or moved. Backlighting will remain on for 3 seconds. KURV 2.0 Voice Remote Control Shown...
  • Page 7 KSTB2020 - User Guide Hot Keys The following Hot Keys are dedicated short cuts to return the user to the video service regardless of the content or App being viewed. MENU: Displays the Main Menu. LAST: Displays the last 15 items that have been watched. HOME: Displays the main Android TV menu including access to Apps.

  • Page 8: Button Functionality

    KSTB2020 - User Guide Button Functionality TV POWER: Powers on or off TV if remote is programmed with a TV infrared code. TV INPUT: Changes video input on TV if remote is programmed with a TV infrared code. POWER: Switches STB power on or into standby or off mode.
  • Page 9 KSTB2020 - User Guide GOOGLE HOME: Launches AndroidTV main menu including access to Apps. LAST: Displays the last 15 items that have been watched. BACK / EXIT: Returns to previous menu or state within current App. From live video, this key opens the Main Menu.

  • Page 10: Kurv 1.0 Search Remote

    KSTB2020 - User Guide KURV 1.0 SEARCH REMOTE Remote Pairing Operation STB / Remote IR – RF Mode Conversion For customers who wish to place the STB in a non-line of sight position (with respect to the remote control) the remote must operate in RF mode. As the remote operates in IR mode by default the user will have to convert the remote operation from IR mode to RF mode by the following sequence: •...
  • Page 11 KSTB2020 - User Guide TV / Remote Programming By default, the remote controls the Volume and Power on the STB. To program the remote to the TV, such that remote Master Power key presses adjust Power and Volume on the TV by Infrared commands directly follow the instructions below: •...
  • Page 12 KSTB2020 - User Guide Volume and Mute Controlling Device Link By default, the remote controls the Volume and Mute on the STB. To program the remote to control Volume and Mute on the TV follow the instructions below: • Press and hold the key until the remote LED turns green.

  • Page 13: Kurv 2.0 Voice Remote

    KSTB2020 - User Guide KURV 2.0 VOICE REMOTE Remote Pairing Operation STB / Remote IR – RF Mode Conversion For customers who wish to place the STB in a non-line of sight position (with respect to the remote control) the remote must operate in RF mode. As the remote operates in IR mode by default the user will have to convert the remote operation from IR mode to RF mode by the following sequence: •...
  • Page 14 KSTB2020 - User Guide TV / Remote Programming By default, the remote controls the Volume on TV, and Power on the STB. To program the remote to the TV, such that remote Master Power key presses adjust Power and Volume on the TV by Infrared commands directly follow the instructions below: •...
  • Page 15 KSTB2020 - User Guide Volume and Mute Controlling Device Link By default, the remote controls the Volume and Mute on the TV or Sound Bar. To program the remote to control Volume and Mute on the STB, such that remote can adjust volume on the Sound Bar by Infrared commands directly, follow the instructions below: •...

  • Page 16: Kurv 1.0 / Kurv 2.0 Remote Ok Button Functionality

    KSTB2020 - User Guide KURV 1.0 / KURV 2.0 REMOTE OK BUTTON FUNCTIONALITY When pressing the OK/Select key for an extended time, on either the KURV 1.0 or KURV 2.0 remote controls, the Operator in app search screen appears on the TV. The KURV 1.0 SEARCH remote control is only capable of a manual text search using the keyboard.

  • Page 17: Kurv 1.0 / Kurv 2.0 Remote Google Assistant Behavior

    KSTB2020 - User Guide KURV 1.0 / KURV 2.0 REMOTE GOOGLE ASSISTANT BEHAVIOR When pressing the Google Assistant button on the remote, behavior is dependent upon whether the user is signed in or not to Google. Users signed in to Google will experience a broader interaction.

  • Page 18: Kurv 1.0 / Kurv 2.0 Remote Battery Installation

    KSTB2020 - User Guide KURV 1.0 / KURV 2.0 REMOTE BATTERY INSTALLATION Battery Monitoring The remote The remote has ability to output battery status. Follow requires two AA the steps below to check Batteries: batteries. • Press and hold the key until the remote LED Hold the remote turns green.

  • Page 19: Self-Install Guidelines

    KSTB2020 - User Guide SELF-INSTALL GUIDELINES HDMI Cable Connection What You Need • An HD or Ultra High Definition (UHD) TV that can support 720p, 1080p or 4K UHD. • A broadband Internet connection that supports a wired or WiFi wireless home network (802.11 g, n, or ac).
  • Page 20 KSTB2020 - User Guide Analog Composite Breakout Cable Connection Connect the analog composite cable as shown below. This connection scheme should only be used if the TV does not have a working HDMI port. Video Audio Output to TV Connect the Analog Composite to the TV Ports and Select the corresponding AV Source on the TV Input thru WiFi or Ethernet Cable...

  • Page 21: Wired Network Connection

    KSTB2020 - User Guide Network Connection You must connect your new STB to an internet connection through either a WiFi wireless connection or a wired Ethernet connection. Wired Network Connection If your home router is near the STB location, a CAT-5/5e/6 Ethernet cable may be used for internet connectivity.

  • Page 22: Wifi Network Connection

    KSTB2020 - User Guide WiFi Network Connection Connect Automatically Using WPS Navigate to the Android main menu by pressing the following key sequences: Home — > Settings — > Network — > WiFi — > Select to enable. Once WiFi has been enabled, using the remote scroll down and select “Connect via WPS”.

  • Page 23: Troubleshooting

    KSTB2020 - User Guide TROUBLESHOOTING Observation Things to Check Remediation WiFi signal strength in STB Relocate router and STB closer Video/audio quality is poor on Network connection menu. in proximity with each other STB or network if possible, such that signal Ideal for consistent video: connection error is strong or very strong.

  • Page 24: Usage Constraints

    KSTB2020 - User Guide USAGE CONSTRAINTS External DVR via USB Drive The USB port cannot be used to connect an external USB drive to support local DVR capability.

  • Page 25: Appendix A: Tv Codes For Remote Pairing

    KSTB2020 - User Guide APPENDIX A TV Codes for Remote Pairing - Top 10 US TV Brands - TV Maker Code / Brand Number SAMSUNG 10305 10265 10001 10012 10051 10092 10011 10118 10124 10132 10145 10176 10221 10306 10542 10315 10439 10479...
  • Page 26 KSTB2020 - User Guide TV Maker Code / Brand Number APEX DIGITAL 10303 10373 10384 ARCHER 10388 ASTAR 10390 AUDIOVOX 10345 10319 10380 10374 10388 AURORA SYSTEMS 10391 AVENTURA 10311 BELCOR 10001 10011 10315 BELL & HOWELL 10393 BENQ 10395 10396 BLAUPUNKT 10084...
  • Page 27 KSTB2020 - User Guide TV Maker Code / Brand Number CROSLEY 10415 CROWN 10045 10132 10380 CURTIS MATHES 10001 10092 10011 10132 10365 10413 10415 10393 10319 10436 10542 10439 10368 10504 10543 10271 10045 10380 CYBERHOME 10416 CYTRON 10417 10418 DAEWOO 10011...
  • Page 28 KSTB2020 - User Guide TV Maker Code / Brand Number ERAE 10442 10317 10318 10311 FISHER 10013 10058 10393 FUJITSU 10149 10228 10333 10334 10376 FUNAI 10033 10045 10380 10311 10376 10452 FUTURETECH 10045 10380 GATEWAY 10310 10486 10001 10014 10015 10038 10057...
  • Page 29 KSTB2020 - User Guide TV Maker Code / Brand Number INITIAL 10356 INKEL 10120 INSIGNIA 10091 10366 10311 10417 10274 10148 10415 JCPENNY 10001 10011 10014 10015 10030 10035 10092 10132 10145 JENSEN 10019 10234 10261 10270 10038 10040 10079 10239 10550 KAWASHO...
  • Page 30 KSTB2020 - User Guide TV Maker Code / Brand Number MEMOREX 10013 10069 10091 10011 10393 10431 10315 10376 10516 METZ 10084 10001 10011 10033 10044 10050 10074 10315 10439 10484 MIDLAND 10413 MINERVA 10084 MINTEK 10356 MITSUBISHI 10216 10011 10030 10033 10034...
  • Page 31 KSTB2020 - User Guide TV Maker Code / Brand Number PHILIPS 10148 10321 10011 10040 10060 10067 10132 10145 10001 10222 10003 10371 10415 10479 PILOT 10001 10011 10439 10315 PIONEER 10504 10024 10029 10031 10032 10011 10248 10254 10304 10001 POLAROID 10335...
  • Page 32 KSTB2020 - User Guide TV Maker Code / Brand Number SIEMENS 10084 SIGNATURE 10069 10011 SIGNATURE 2000 10011 SIGNET 10519 10478 10520 SIM2 MULTIMEDIA 10430 SIMPSON 10001 SKYWORTH 10522 SOLARISM 10523 SOLE 10358 10483 10301 10479 10354 SONY 10043 10075 10117 10130 10067...
  • Page 33 KSTB2020 - User Guide TV Maker Code / Brand Number TELERENT 10069 TERA 10156 THOMAS 10452 10011 10315 10543 10378 TOSHIBA 10021 10013 10035 10041 10052 10063 10092 10142 10146 10178 10179 10393 10303 10464 10419 10517 TOTEVISION 10132 TRUTECH 10353 10431 ULTRA...

  • Page 34: Appendix B: Audio System Codes For Remote Pairing

    KSTB2020 - User Guide APPENDIX B Audio System Codes for Remote Pairing Audio Maker Code / Brand Number ADCOM 20088 20098 20218 20147 20233 AIWA 20142 20182 20025 20141 20022 20110 AKAI 20128 ANAM 20026 20188 20189 ANTHEM 20004 B&K 20102 20103 BOSE...
  • Page 35 KSTB2020 - User Guide Audio Maker Code / Brand Number LUXMAM 20042 20084 MAGNAVOX 20013 20092 MARANTZ 20013 20093 20047 20072 20063 20203 20221 20250 MAXELL 20078 MCINTOSH 20160 20016 MITSUBISHI 20164 20165 20036 NAKAMICHI 20167 20047 NILES 20168 ONKYO 20178 20053 20113...
  • Page 36 KSTB2020 - User Guide Audio Maker Code / Brand Number TAEKWANG 20128 20186 20195 TEAC 20066 20067 20026 20190 TECHNICS 20126 20094 20109 20014 20137 THOMSON 20217 TOSHIBA 20155 20118 20237 20255 VICTOR 20020 20112 VIZIO 20180 WARDS 20015 YAMAHA 20140 20166 20201...
