Summary of Contents for Wohler eVAM1-1

  • Page 1: User Guide

    1RU Multi-Channel Audio Video Monitor User Guide Part Number 821844, Revision A...
  • Page 2 In no event will Wohler Technologies, Inc. be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect in the hardware, software, or its documentation, even if advised of the possibility of such damages.
  • Page 3: Table Of Contents

    Speaker Options................. 21 Meter Scales..................22 Unit Configuration ................24 Phase Configuration................25 Meter Mode ..................26 System Options Menu ................. 27 Network Settings................27 System Reboot .................. 29 System Update .................. 30 Factory Reset ..................31 Page 3 eVAM1-1...
  • Page 4 System Information ................32 CHAPTER 3: Technical Info ............... 33 CHAPTER 4: The eVAM1-1 Web GUI............. 36 Web Browser / Control Device................ 36 First Time IP Assignments ................36 Peer-to-Peer Connection..............36 Network Connection................37 Network Setup..................... 38 Dashboard ....................39 Audio Meters ....................
  • Page 5 Updating via the Web GUI using a Flash Drive ..........62 Updating an eVAM1-1 Remotely ..............64 Updating Multiple Units Remotely ..............66 APPENDIX E: API Documentation ............69 Introduction ....................69 API: Presets ....................69 Page 5 eVAM1-1...
  • Page 6: Chapter 1: Installation

    Any channels (or channel pairs) from any audio/video source stream may be monitored. Either 8 or 16 channel meters can be displayed. The eVAM1-1 includes two 3G SDI inputs and it can monitor both video and audio from them. It contains APIs for remote management.
  • Page 7: Safety Symbols

    Sympathetic Vibration Sympathetic vibration from other equipment (cables, etc.) in the rack may be serious enough to interfere with the unit’s sound quality. If you experience sympathetic vibrations, use thin card stock, felt, foam, or weather-stripping Page 7 eVAM1-1...
  • Page 8: Mechanical Bracing

    ICES-003 This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. Page 8 eVAM1-1...
  • Page 9: Chapter 2: Local Operation

    CHAPTER 2: Local Operation Operation The eVAM1-1 can be operated easily and simply from controls on its front panel, as described in this chapter. It may be accessed remotely in two ways, via the Wohler Web GUI for administrative purposes or by third party equipment via Application Programming Interface (API) commands.
  • Page 10 9. Status: This indicator lights green when the system is powered and ready for use. A solid or blinking yellow color indicates that the product is starting up. A red color indicates that a system update is taking place. Refer to Appendix A. Page 10 eVAM1-1...
  • Page 11: Rear Panel

    Chapter 4 of this manual. Third party equipment, connecting to the eVAM1-1 via a LAN plugged into this port and using an API commands, can view and change product options, as well. This API is described in Appendix E of this manual.
  • Page 12 Volume and Balance controls. The Analog Outputs are standard on the eVAM1-1. Refer to Figure 2-4 for the pinout of this connector. Figure 2-4: Analog XLR-M Output Connections 8.
  • Page 13: Channel Meters And Touch Operations

    1. Channel Identifiers: Above the level meters are the Channel Identifiers. They indicate the consecutive channel numbers in the selected source. 2. Channel Pair Touch Selection Area: Touching the meters of any channel pair will let you mute, un-mute, or solo the associated Page 13 eVAM1-1...
  • Page 14 Mute / Un-Mute Selection: A violet box surrounds any channel pair that is muted. Typically, when the eVAM1-1 is first powered, all of the channel pairs are muted. Touching a muted channel pair un- mutes it and removes the violet box. Muting and un-muting by touching is an alternate action function.
  • Page 15: Video Screen

    2. Video Signal: This translucent box displays the resolution and frame rate of the video signal. Note: If the Video Source and Video Signal displays have been optioned to disappear after 5 or 10 seconds and you wish them to reappear, simply touch the video screen. Page 15 eVAM1-1...
  • Page 16: Menu / Option Touchscreen

    Screen Unit Configuration Phase Configuration Meter Mode Screen Meter Mode Network Settings Screen System Options System Reboot Network Settings Screen System Reboot System Update System Update Screen Factory Reset Factory Reset System Details Screen System Details Screen Page 16 eVAM1-1...
  • Page 17: Main Menu

    The selected source is shown in a light color. You may simply touch another source in this menu to switch to it. Figure 2-10 shows the Source Select Menu. Figure 2-10: Source Select Menu Touch Menu to exit this menu. Page 17 eVAM1-1...
  • Page 18: Preset Favorites

    Preset to select it. To exit this screen without making a selection, touch Menu. If no Favorite Presets have been designated, this screen will appear as shown in Figure 2-12. Figure 2-12: Preset Favorites Screen - No Favorites Page 18 eVAM1-1...
  • Page 19: All Presets

    All Presets Touch the All Presets button to display the All Presets Group Selection screen as shown in Figure 2-13. The eVAM1-1 can contain up to 8 Presets. If no Presets have been created, the screen in Figure 2-15 appears instead.
  • Page 20: Unit Settings

    Touching the Unit Settings selection on the Main Menu screen proceeds to the Unit Settings Menu, which contains additional menu selections. The Unit Settings Menu is shown in Figure 2-16. This is an intermediary menu which leads to other menus and screens. Figure 2-16: Unit Settings Menu Page 20 eVAM1-1...
  • Page 21: Speaker Options

    Touching the Speaker Options selection on the Unit Settings Menu screen proceeds to the Speaker Options screen. The controls on this screen affect various characteristics of the monitored audio as heard on the eVAM1-1. This screen is shown in Figure 2-17.
  • Page 22: Meter Scales

    Touch the left or right arrows to select the scale. A representation of the chosen scale will be shown at the right. The possible scales that can be selected are shown in Figure 2-19. Figure 2-19: Meter Scale Selection Page 22 eVAM1-1...
  • Page 23 10 ms to reach -2 dB of IEC Type II -24 dB 2.8 sec. settled reading None Bar or Floating Segment Not Displayed When you have made your choices, touch Save to retain them. Touch Back or Meters to exit this screen. Page 23 eVAM1-1...
  • Page 24: Unit Configuration

    3. AES termination: AES signals should have one and only one termination. This termination should physically be at the last destination of an AES coax cable. If the eVAM1-1 is the last connection in a series of AES connections, then its terminations should be turned on. A symptom of too many terminations (or no termination) is that no signal appears to be present on the AES input.
  • Page 25: Phase Configuration

    Unit Settings menu. 3. Save & Exit: When you have finished making the changes you want on this screen, touch the Save & Exit button to save the changes and return to the Unit Settings menu. Page 25 eVAM1-1...
  • Page 26: Meter Mode

    Touch the On - Off switch to change the 8 Channel Mode setting. To exit this menu and save your selection, touch Save & Exit. To exit this menu without saving your selection, touch Cancel & Exit. Page 26 eVAM1-1...
  • Page 27: System Options Menu

    Use DHCP Address 192.168.1.185 Mask 255.255.255.0 Gateway 192.168.1.1 192.168.1.1 1. To change the IP Address, Net Mask, Gateway, or DNS, tap the item you would like to change. A keypad will appear, as shown in Figure 2-25. Page 27 eVAM1-1...
  • Page 28 Figure 2-26: Network Settings: DHCP Cancel and Exit Save and Exit Use DHCP Address 192.168.1.185 Mask 255.255.255.0 Gateway 192.168.1.1 192.168.1.1 1. To complete the network addressing scheme change, touch the Save button. This will save the changes you selected. Page 28 eVAM1-1...
  • Page 29: System Reboot

    Figure 2-27: System Reboot If you have any doubt as to whether you should press Yes, press Back or No instead, and contact Wohler Technical Service for advice. Pressing Back or No will return you to the System Options menu.
  • Page 30: System Update

    Touching the System Update selection in the System Options Menu displays System Update screen as shown in Figure 2-28, showing the current software version of the product. To update the system software locally from the eVAM1-1 front panel, follow the procedure in the Local Update from the Front Panel section of Appendix A.
  • Page 31: Factory Reset

    Mac address 28.) If you have any doubt as to whether you should press Yes, press Back or No instead, and contact Wohler Technical Service for advice. Pressing Back or No will return you to the System Options menu.
  • Page 32: System Information

    System Details screen as shown in Figure 2-30. This screen lets you view the product Serial Number, Software Version, and various other information. Figure 2-30: System Details Screen The information shown on this screen is read only and cannot be changed. Touch Back to return to the System Options Menu. Page 32 eVAM1-1...
  • Page 33: Chapter 3: Technical Info

    CHAPTER 3: Technical Info Table 3–1: eVAM1-1 Specifications Specification Values/Domains Power Requirements 100 VAC to 240 VAC ± 10%, 50/60Hz Power Consumption 65 Watts Dimensions 1.75” x 19” x 5.5” (44mm x 483mm x (H x W x D) 140mm), standard 19” rack mounting Shipping/Net Weight 8 lbs.
  • Page 34 Power Output 5 Watts RMS, 12 Watts peak (each side) Acoustic Frequency 150 Hz to 16 kHz (± 5 dB) Response Headphone Out - Stereo 40 Hz to 20 kHz (± 1 dB) Headphone Load 8Ω to 150Ω Page 34 eVAM1-1...
  • Page 35 Figure 3–1: eVAM1-1 Block Diagram SDI-1 Menu Touchscreen for Video / Audio Meters / Control Video Selector 3G-SDI Input 1 3G-SDI Input 2 3G-SDI Selected Output Graphics / Touch Processors from SDI 1, SDI 2, or HDMI Volume / Select...
  • Page 36: Chapter 4: The Evam1-1 Web Gui

    Web GUI. The eVAM1-1 Web GUI also allows you to have a remote view of the Meter Screen. Refer to the Audio Meters section in this chapter.
  • Page 37: Network Connection

    GUI. Network Connection When connected to a network, the eVAM1-1 address will need to be changed to another address in order to be compatible with the address assignments for that particular network. Immediately after the host setup is complete, change the eVAM1-1’s address.
  • Page 38: Network Setup

    Network Setup Make network IP Address changes for the local eVAM1-1 Management (MGMT) Port here. Figure 4–2: Set IP Addresses The procedure for changing the IP Address information is as follows: 1. Use DHCP? Check this box if your network has a DHCP server and you want to use dynamic addressing.
  • Page 39: Dashboard

    Throughout the Web GUI, pages are a click or two away using the list of selections on the left side. The Dashboard page shows all of the available Preset configurations at a glance. The eVAM1-1 allows you to assign Presets to particular groups. In Figure 4-3, one group is shown.
  • Page 40 Clicking a Group Edit button will cause the screen in Figure 4-5 to appear. Figure 4–5: Dashboard Group Edit eAMP1-S8-MDA eVAM1-1 The Edit options for a Group are as follows: 1. Delete: Delete the Group and all of the Presets it contains.
  • Page 41: Audio Meters

    Audio Meters Click on Audio Meters to remotely display the audio meters of the eVAM1-1. This display is shown in Figure 4-6. Also displayed is the name of the source that the meters are displaying. In Figure 4-6, this is SDI-1.
  • Page 42: System Preferences

    Reference. This tab is shown in Figure 4-7. This System Audio Clock Reference setting can be overridden by the optional System Clock Reference setting in the Preset Management menu when the Preset is chosen. Figure 4–7: System Audio Clock Reference Tab Page 42 eVAM1-1...
  • Page 43: Phase Indicator Configuration Tab

    Select All and Reset All buttons are also provided. Figure 4–8: Phase Indicator Configuration Tab When you have finished making the settings click Apply to save them or click Cancel to discard them. Page 43 eVAM1-1...
  • Page 44: Preset Management

    This delay may range from 0 to 170 mS. Typically, delay is used to align the monitored audio with a video monitored signal. 4. Input Selection: Audio from any of the input sources may be applied to the Page 44 eVAM1-1...
  • Page 45 8. Mute/Unmute: A Mute/Unmute control is provided for each channel, although the adjustment will affect all channels in the Cluster. This allows the operator to just see the meters for certain channels and not hear the audio. Page 45 eVAM1-1...
  • Page 46 To set up a different input to output routing scheme for the Preset you are creating, click the Global Output Routing tab and uncheck the Apply Global Output Routing checkbox. You may then adjust the output routing as you desire on this tab and it will only apply to this Preset. Page 46 eVAM1-1...
  • Page 47: Output Routing

    1. Speaker/Headphone: Selected inputs will be sent to the left and right speakers. The default routing is set as per the Speaker Assignment, left channels are sent to the left speaker and right channels are sent to Right Page 47 eVAM1-1...
  • Page 48: Source Inputs

    4. Volume Control: This setting determines whether each output pair is adjusted by the Volume Control knob. Speaker/Headphone outputs are always affected by the volume control knob, as are any outputs that are in Speaker Mix mode. Page 48 eVAM1-1...
  • Page 49: Typical Questions Regarding Output Routing

    What signal outputs can be controlled using the Output Routing feature? All the outputs on the eVAM1-1 can be controlled using the Output Routing feature. This includes – Internal Speakers, Analog XLR outputs, and AES outputs. What is the difference between Global Output Routing and Output Routing in Presets? Both are used to configure the unit outputs.
  • Page 50: How Do I Make The Xlr Outputs Follow The Audio Meter Screen Solos & Mutes While The Aes Pair-1 Does Not

    13, and 15 are routed to the left analog XLR output and Audio Meter channels 10, 12, 14, and 16 are routed to the right analog XLR output. Unchecked channels are not routed. Make sure the Speaker Mix selection is turned off to enable this selection. Page 50 eVAM1-1...
  • Page 51: How Do I Keep The Internal Speakers Muted And Have Audio Only On The Analog Xlr Outputs

    Insertion checkbox is ON then the outputs get automatically muted when a headphone is inserted into the Headphone jack. As shown below, if a headphone is inserted then the output on the Analog XLRs will be muted, while the audio on AES Pair 1 will remain on. Page 51 eVAM1-1...
  • Page 52 In the Output Routing setting, for the Analog XLR outputs, keep the Volume Control checkbox unchecked and the Solo/Mute checkbox checked. This ensures that the Volume Control is not applied to the outputs, while the Solos/Mutes are. Page 52 eVAM1-1...
  • Page 53: Preset Replication

    To start Preset Replication, click on the Preset Replication tab on the master unit. This will start the unit discovery process and will list all the eVAM1-1 units that you currently have on your network. The discovery process will continue for a period of 2 minutes.
  • Page 54: Import/Export Presets

    The eVAM1-1 will create Preset Tags for the each set of Presets. Refer to Figure 4- 13. You may also change these Preset Tags, using the Preset Change Field. They allow you to quickly resolve questions about which Presets on various units are the most up to date.
  • Page 55: Export Configuration

    Export Configuration Use the following steps to save the Preset configuration in the eVAM1-1 to the computer hard drive: 1. If you need to, revise the Preset Tag name, observing the advice in the advice in the previous section. 2. Click the Export button on the Import / Export Presets page, as shown in Figure 4-13.
  • Page 56: System Information

    System Information This screen displays a variety of information about the eVAM1-1. It is shown in Figure 4-14. This information could be useful to view if you are contacting Wohler Technical Service. Figure 4–14: System Information Screen Page 56 eVAM1-1...
  • Page 57: Factory Reset

    If you have any doubt as to whether you should perform a Factory Reset, do not click the Initiate Factory Reset button. Contact Wohler Technical Service for advice. Factory Reset will also reset your IP address to the default one. After a Note: Factory Reset, the IP Settings will need to be updated.
  • Page 58: Reboot System

    The Reboot System function should be used with a bit of caution. It puts the eVAM1-1 out of service for several minutes while it is rebooting, and this may unexpectedly interfere with the use of the product by the remote operator.
  • Page 59: Appendix A: Software Upgrades

    Introduction This chapter describes how to download a software update file to your computer, transfer it to a USB flash drive and install the update into an eVAM1-1. Download the Software The eVAM1-1 software update can be found at http://www.wohler.com, under Product Downloads on the Products >...
  • Page 60: Local Update From The Front Panel

    USB flash drive. 2. Insert the USB flash drive with eVAM1-1 update package(s) into the front panel USB jack. 3. From the Menu screen, touch System Options. The screen shown in Figure A-1 will appear.
  • Page 61 The upgrade will take 5 minutes or more, after which the eVAM1-1 will restart. After the system has completed its restart cycle and is once again operational, you may then remove the flash drive.
  • Page 62: Updating Via The Web Gui Using A Flash Drive

    USB flash drive. 2. Connect to the eVAM1-1 with the Wohler Web GUI. Navigate to the System | System Update menu, as shown in Figure A-5. If the eVAM1-1 has...
  • Page 63 Figure A-7 – System Update Verification 6. Next, the update begins, showing the screen in Figure A-8. The circle in the center of the screen, along with status messages below it, will indicate the progress of the update. Page 63 eVAM1-1...
  • Page 64: Updating An Evam1-1 Remotely

    Use the following steps to update the eVAM1-1 software: 1. The Software Update files you downloaded earlier must be in the same computer that is running the Web GUI. Connect to the eVAM1-1 with the Wohler Web GUI. Navigate to the System | System Update menu. Click within the large blue dotted line rectangle at the right of the screen.
  • Page 65 3. At this point, wait for the update to complete. It may take several minutes, until the it is critical not to disturb the eVAM1-1 or the Web GUI update process is complete. When it is complete, the eVAM1-1 will restart.
  • Page 66: Updating Multiple Units Remotely

    Use the following steps to update one or more eVAM1-1 units remotely by transferring the software from a previously updated eVAM1-1: 1. If any of the eVAM1-1 units that you intend to update remotely may be in use, contact the people using them and let them know what you will be doing.
  • Page 67 Figure A-13 – List of Found eVAM1-1 Units 4. Then click Update Selected Devices. The window shown in Figure A-14 will appear. Figure A-14 – Apply System Package 5. Click Apply System Update. The screen shown in Figure A-15 will appear.
  • Page 68 6. At this point, wait for each update to complete. It may take several minutes, it is critical not to disturb any of the eVAM1-1 units or the Web until the update process is complete. When it is complete, each eVAM1- 1 will restart.
  • Page 69: Appendix E: Api Documentation

    Follow the instructions in the First Time IP Assignments section of Chapter 4 to achieve the required network connection. API: Presets 1. GET Active Preset Method: GET /api/cf/presets/current Example Response: "serial_number": "", "model": "eVAM1-1", "version": 1.3, "name": "eVAM1-1", "result": { "group": { "Id": 1, "Name": ""...
  • Page 70 "NumberOfMeters": 2, "FirstMeter": 3, "Name": "Stereo 2.0 #2", "Type": "Stereo", "MuteOnPresetRecall": true "NumberOfMeters": 2, "FirstMeter": 5, "Name": "Stereo 2.0 #3", "Type": "Stereo", "MuteOnPresetRecall": true "NumberOfMeters": 2, "FirstMeter": 7, "Name": "Stereo 2.0 #4", "Type": "Stereo", "MuteOnPresetRecall": true "NumberOfMeters": 2, Page 70 eVAM1-1...
  • Page 71 "Cage": 1, "Channel": 8, "ConnectorType": "BNC", "InputNo": 1, "InputIndex": 0, "Type": "SDI" "VolumeDb": 0, "DelayMs": 0, "Speaker": "Right" "2": { "Source": { "Slot": 1, "Cage": 1, "Channel": 2, "ConnectorType": "BNC", "InputNo": 1, "InputIndex": 0, "Type": "SDI" "VolumeDb": 0, Page 71 eVAM1-1...
  • Page 72 "Source": { "Slot": 1, "Cage": 1, "Channel": 11, "ConnectorType": "BNC", "InputNo": 1, "InputIndex": 0, "Type": "SDI" "VolumeDb": 0, "DelayMs": 0, "Speaker": "Left" "15": { "Source": { "Slot": 1, "Cage": 1, "Channel": 15, "ConnectorType": "BNC", "InputNo": 1, "InputIndex": 0, Page 72 eVAM1-1...
  • Page 73 "InputIndex": 0, "Type": "SDI" "VolumeDb": 0, "DelayMs": 0, "Speaker": "Right" "6": { "Source": { "Slot": 1, "Cage": 1, "Channel": 6, "ConnectorType": "BNC", "InputNo": 1, "InputIndex": 0, "Type": "SDI" "VolumeDb": 0, "DelayMs": 0, "Speaker": "Right" "7": { "Source": { Page 73 eVAM1-1...
  • Page 74 "Cage": 1, "Channel": 1, "ConnectorType": "BNC", "InputNo": 1, "InputIndex": 0, "Type": "SDI" "VolumeDb": 0, "DelayMs": 0, "Speaker": "Left" "SystemClockSource": { "Slot": 0, "Cage": 0, "ConnectorType": "None", "InputNo": 0, "Type": "None", "Pair": "Favorite": 0, "PresetId": 1, "GroupName": "G1" Page 74 eVAM1-1...
  • Page 75 "Name": "SDI", "Id": "Id": "Name": "AES", "Presets": [ "Favorite": 0, "Name": "dfsdf", "Id": "Id": 4. GET to recall the preset Method: GET api/op/presets/<int:presetID>/activate Example Response: "error": null, "params": { "PresetId": "result": { "PresetId": 1, "GroupId": 1, "PresetName": "SDI", Page 75 eVAM1-1...
  • Page 76 Method: POST api/op/preset/<int:presetID>/delete Example Response: "error": null, "params": { "PresetId": "result": { "PresetId": 7. POST to rename group Method: POST /api/op/group/<int:groupID>/newGrpNameSdi/rename Example Response: "error": null, "params": { "GroupId": 1, "GroupName": "newGrpNameSdi" "result": { "GroupId": 1, "GroupName": "newGrpNameSdi" Page 76 eVAM1-1...
  • Page 77 Example Response: "error": null, "params": { "PresetId": 4, "Favorite": "result": { "PresetId": 4, "Favorite": 10. Source Select Method: POST /api/op/sourceselect Body content for SDI "SourceType": “<String: SDI Input Source>” Note: Allowed SDI input sources are: "Bnc-1.Sdi", "Bnc-2.Sdi", Page 77 eVAM1-1...
  • Page 78 2. Body content for Analog "SourceType": "Analog.XLR" "SourceType": "Analog.DB25" Body content for Aes "SourceType": "Aes" Page 78 eVAM1-1...
