Summary of Contents for AGCO Valtra Versu SmartTouch
- Page 1 QUICK START GUIDE T SERIES N SERIES VERSU SmartTouch...
-
Page 2: Valtra Connect
VALTRA ACTIVATE NOW valtraconnect.com CONNECT 5 years free of charge for new machines REMOTE SERVICES & CONNECTED SUPPORT FOR YOUR VALTRA MACHINES OVERVIEW OF THE MOST IMPORTANT MACHINE DATA – ANYTIME, ANYWHERE! Simple fleet management using a Minimised downtime due to early computer, smartphone or tablet identification of error codes Increased economic efficiency... -
Page 3: Table Of Contents
T/N Series Quick Guide / Versu VERSU – THE POWERSHIFT YOUR Valtra Connect ..........2 Versu – the powershift revolution .... 3 REVOLUTION Smart A-pillar display ......... 4 SmartTouch Armrest ........6 Drive lever ............. 7 Other controls ..........7 SmartTouch terminal ........ -
Page 4: Smart A-Pillar Display
T/N Series Quick Guide / Versu SMART A-PILLAR DISPLAY The brand new Valtra smart A-pillar display brings all the information you need to exactly where you need it. With the essential information always displayed up top in a clear and easy way you’ll never be left searching for what you need to know. - Page 5 T/N Series Quick Guide / Versu SMART A-PILLAR DISPLAY Use the wheel encoder and two buttons to navigate screen Via the settings menu select “Drive Display Mode” and select whether you want two, one or zero displays Using the encoder select the desired Drive Display and configure it to display the information you want The brightness of the A-pillar display can be adjusted via the left stalk.
-
Page 6: Smarttouch Armrest
T/N Series Quick Guide / Versu SMARTTOUCH Driving / transmission ARMREST Hydraulics 3-point linkage Power Take-Off Electrics / programmable Drive lever Hydraulic joystick Programmable hydraulic function e.g. live 3rd valve in loader Selecto 3rd and 4th valve (for front loader) Hand throttle control Automatic/ Manual mode Memory button 3... -
Page 7: Drive Lever
T/N Series Quick Guide / Versu DRIVE OTHER LEVER CONTROLS Phone holder Emergency brake 3-pin current socket Memory button 1 3-pin current socket (optional) Memory button 2 SmartTouch Extend connector (optional) Speed range (ABCD) up ISOBUS terminal connector (optional) Speed range (ABCD) down Implement signal connector Rear lift (AutoControl): Lift / Stop / Lower / Float switch Button for fuel-operated heater (optional) -
Page 8: Smarttouch Terminal
T/N Series Quick Guide / Versu SMARTTOUCH TERMINAL The user interface has two sections: settings and drive displays. You can move between these sections with the Home (4) and Drive display (5) buttons. The settings have three levels: Home screen, setting screen and pop-ups. -
Page 9: Settings Screen Symbols
T/N Series Quick Guide / Versu SETTINGS SCREEN SYMBOLS Access to all tractor functions with less than three taps or swipes in the touch screen. Front Back Terminal settings Tractor health Implement settings Engine ISOBUS Steering Camera ISOBUS universal terminal Lights ISOBUS ISOBUS... -
Page 10: Drive Display
T/N Series Quick Guide / Versu DRIVE DISPLAY You can access the drive displays from the button in the terminal. This shows 1 or 4 different displays according to your settings. Swipe one of the screens left or right to view different drive displays. Tap the screen you want to modify to open the settings panel. -
Page 11: Driving Modes
T/N Series Quick Guide / Versu DRIVING MODES AUTOMATIC MODE Intelligent drive lever gives you possibility to drive a powershift tractor like a CVT. When you start the tractor the automatic driving mode is automatically selected. There are two main ways of driving: •... -
Page 12: Cruise Control
T/N Series Quick Guide / Versu CRUISE CONTROL Speed cruise control is controlled by the drive lever. It offers the possibility to maintain a steady speed. Push the drive lever to the right to engage cruise, hold for 2 seconds to store new speed. -
Page 13: A-B-C-D = Four Speed Ranges
T/N Series Quick Guide / Versu A-B-C-D = FOUR SPEED RANGES Four speed ranges – less strain = increased efficiency. Versu has also LA and LB creeper ranges standard. 40 km/h 50 km/h 0.4-1.4 0,5-1,7 Very low speed E.g. special crop tasks km/h km/h 0.9-3.0... -
Page 14: How To Change Speed Range
T/N Series Quick Guide / Versu HOW TO CHANGE SPEED RANGE TO CHANGE RANGE MANUALLY Simply push + or - button on drive lever. Via transmission menu select “Lever Range Change” and then you can change up & down ranges by just pushing or pulling drive lever. -
Page 15: Powershift Revolution Autotraction
T/N Series Quick Guide / Versu POWERSHIFT REVOLUTION AUTOTRACTION Autotraction lets you stop the tractor using just the brake pedals! It is the most intuitive and easiest way to drive a powershift on the market! AUTOTRACTION IS AS DEFAULT ACTIVATED, TO DEACTIVATE IT: Go to the transmission screen. -
Page 16: Ecopower Mode
T/N Series Quick Guide / Versu ECOPOWER-MODE (ONLY ON MODELS N155ECO AND T175ECO) EcoPower is a Valtra innovation for more than 15 years. EcoPower-mode is designed especially for work that requires high torque, but not constant engine revs e.g. pulling work on the field. -
Page 17: Engine Speed Memory
T/N Series Quick Guide / Versu ENGINE SPEED MEMORY Valtra VERSU has an Engine Speed memory that will keep engine RPM constant regardless of ground speed. Go to the engine screen with the engine button. You can easily preset Engine Speed memory 1 and 2: Change the value by selecting the appropriate memory and sliding it to the correct position or use the encoder wheel. -
Page 18: Master Activation
T/N Series Quick Guide / Versu MASTER ACTIVATION Hydraulics, steering valve, memory buttons and isobus aux can all be actived via the master activate button on the smarttouch armrest. When starting up the tractor simply press the button on the armrest and then select from the screen which functions you want to activate. -
Page 19: Programmable Functions
T/N Series Quick Guide / Versu PROGRAMMABLE FUNCTIONS MEMORY BUTTONS You can add one-action programmes or sequence (U-Pilot) action programmes to the memory buttons. You can program almost any function in the SmartTouch to the memory buttons. Open the Armrest screen Tap the desired memory button Tap the one-action programme selection icon. -
Page 20: U-Pilot Headland Automatics
T/N Series Quick Guide / Versu U-PILOT HEADLAND AUTOMATICS Open the Armrest screen. Tap the desired memory button. Tap the sequence icon. RECORD A U-PILOT PROGRAMME Tap the record icon. Perform the operations in the required order. Tap the record icon to end the recording. PROGRAM A U-PILOT PROGRAMME Tap add action icon. -
Page 21: Programmable Functions - Hydraulics
T/N Series Quick Guide / Versu PROGRAMMABLE FUNCTIONS HYDRAULICS There are totally 9 different programmable hydraulic controls in the SmartTouch armrest. The auxiliary hydraulic controls are positioned on the armrest. The joystick, fingertip levers and linear levers are programmable, thus you can select which lever controls which valve. Joystick Joystick fingertip lever Upper button (Selecto 3) -
Page 22: Programmable Hydraulics
T/N Series Quick Guide / Versu PROGRAMMABLE HYDRAULICS You have two ways to configurate your hydraulics and hydraulic controls with the SmartTouch armrest: 1. FROM MEMORY BUTTONS SETTING YOU CAN PROGRAM A VALVE TO ANY CONTROL Open the memory buttons setting. Select control you want to program. -
Page 23: Hydraulic Settings
T/N Series Quick Guide / Versu HYDRAULIC SETTINGS You can easily change between front and rear hydraulic setting view with just one swipe in the touch screen. Front valves Lock all valves The number of front valve Lock/unlock all valves and F for front and R for Rear valve from setting changes. -
Page 24: Hydraulic Programming
T/N Series Quick Guide / Versu HYDRAULIC PROGRAMMING VIA HYDRAULIC SETTINGS All settings per valve done via single pop-up. Swipe or tap functionality available. Valve settings locked Valve settings open Priority setting - Sets priority to ensure sufficient oil flow to the valve Flow rate of the + port Function selection of the + port x = no function active... -
Page 25: Front Loader
T/N Series Quick Guide / Versu FRONT LOADER Using the hydraulic joystick is the easiest way to control the front loader, but you can also control the front loader from e.g. the drive lever´s mini linear stick or any other hydraulic control. Open the front hydraulics screen by tapping the hydraulics symbol. -
Page 26: Pick-Up Hitch And Linkage
T/N Series Quick Guide / Versu PICK-UP HITCH AND LINKAGE TO UNLOCK THE PICK-UP HITCH Push the lifting button to fully raise the linkage. Pull the hitch latch lever to unlatch the hitch. Keep the lever pulled. Push the lowering button to lower the linkage. Release the hitch latch lever when the hitch has passed the locking latch. -
Page 27: Rear Controls And Connections
T/N Series Quick Guide / Versu REAR CONTROLS AND CONNECTIONS Front linkage shut-off valve (optional) Trailer coupling, Duo-Matic (optional) Trailer socket for trailer with ABS brakes Trailer coupling, 2-line system (optional) Trailer socket Quick coupling for air pressure devices (optional) Power outlet (12 V) ISOBUS connector (optional) Hydraulic levelling link (optional) -
Page 28: Pto
T/N Series Quick Guide / Versu You can use the power take-off (PTO) to transmit power from the tractor to an implement. Start the engine and tap the PTO symbol on the SmartTouch screen to open the PTO settings. Select the PTO speed. The value stays even in memory when you turn the ignition off. -
Page 29: Auto Pto
T/N Series Quick Guide / Versu AUTO PTO With the automatic power take-off (auto PTO), you can set the limits for the automatic start and stop of the PTO. You can give a different limit for when you lift the rear linkage or lower the rear linkage. The auto PTO controls the start and stop of the PTO in these conditions: •... -
Page 30: Profile
T/N Series Quick Guide / Versu PROFILE All settings of the SmartTouch display are stored in profiles. Every setting you change (except terminal settings) is automatically saved to the active profile. You can create different profiles according to: - User - Specific work - Implement - User + implement combinations... -
Page 31: Quicksteer
T/N Series Quick Guide / Versu QUICKSTEER OPTIONAL QuickSteer is a steering system controlled by an electrohydraulic steering valve. The adjustable steering ratio gives you the possibility to alter the reaction speed between moving the steering wheel and the tractor turning which is helpful whenever the driver needs to steer a lot, for example when driving in a small yard or when doing front loader work. - Page 32 AGCO Valtra Inc. Valmetinkatu 2 Tel. +358 (0)2045 501 FI-44200 Suolahti www.valtra.com...
