- Page 1 Quick Setup Guide for SGBRIDGE: Discovering and Configuring SGBRIDGE for Cloud...
- Page 2 Contents Discovering and Logging into SGBRIDGE ................. 3 Adding sites to SGBRIDGE ......................5 Configuring Channels for Cloud use ..................12 Information for Adding SGBRIDGE to Cloud ................13...
-
Page 3: Discovering And Logging Into Sgbridge
● While the SGBRIDGE is booting, connect your laptop to the same network the SGBRIDGE is on. ● Download, install, and open the Speco Scanner application. This application will search for your SGBRDIGE. Double-click to access web setup. - Page 4 • Your default web browser will open a login screen. The default login credentials are: Username: admin Password: admin Click ‘Submit’ to proceed.
-
Page 5: Adding Sites To Sgbridge
Adding sites to SGBRIDGE • After logging in, click the hamburger menu on the upper left corner of the interface. • Click ‘Config’. - Page 6 • Click ‘Site Locate’ • Find the device(s) you’d like to add to your SGBRIDGE and click the ‘+’ in their row.
- Page 7 • Enter the correct credentials of the device and click ‘Check Site’ • If successful, a blue message will display stating the ‘Check Site’ was successful and channels have been received. Click the ‘x’ icon of the blue message.
- Page 8 • For recorders, select the channels that you want to go to the cloud. Then click ‘Submit’ • Click ‘Close’ in the Site Locate interface.
- Page 9 • You will then need to perform a restart for the device(s) to be added. Click ‘System Config’. • Click ‘Restart SecureGuard’...
- Page 10 • Click ‘Restart’. • You will be notified that SecureGuard will be restarted and that you’ll need to refresh the web browser page. When you refresh, you’ll have to log in again.
- Page 11 • Log into the web interface again. • Navigate to the Site Config interface and you’ll see your recorder information.
-
Page 12: Configuring Channels For Cloud Use
Configuring Channels for Cloud use • In the web setup, go to ‘Camera Config’. It will take a few seconds for the parameters to come through. Once displayed, ensure that both main and sub stream ‘Encoding’ settings are H.264. Configure Resolution, Frame Rate, and Bit- Rate accordingly. -
Page 13: Information For Adding Sgbridge To Cloud
Information for Adding SGBRIDGE to Cloud • Once you’ve completed your camera configuration, click ‘System Config’ and note the Cloud ID and Cloud Password. You can see the Cloud Password by clicking the eye ball icon. • You can open another tab for the Cloud Portal setup so that you can copy and paste the Cloud information.
