iTrackSafeX GPS User Manual
Note:The first time you use this device,you need to charge it for more
than 3 hours.
Hard wired GPS tracker please hard wired it with vehicle/motorcycle according to the wiring diagram,
portable gps tracker just insert sim card can turn on it.
Default: Stop uploading when device in sleep mode. Sleep mode can activate by phone call/sms/move.
Indicator light description For:
(AS3N,MT3,MT4,AS3,AS4,P1,PET03,PET02,MT1-3/4,OBD-2/3/4 with CANBUS,R1)
INDICATOR LIGHT STATUS
Yellow light -Flash
Yellow light -Solid
Blue light -Flash
Blue light -Solid
LED light -off
1
V3.0.3
MEANING
No GPRS signal
GPRS connection
No GPS signal
GPS connection
Device power off or sleep
Advertisement
Summary of Contents for Ascend iTrackSafeX MT1-3
- Page 1 iTrackSafeX GPS User Manual V3.0.3 Note:The first time you use this device,you need to charge it for more than 3 hours. Hard wired GPS tracker please hard wired it with vehicle/motorcycle according to the wiring diagram, portable gps tracker just insert sim card can turn on it. Default: Stop uploading when device in sleep mode.
- Page 2 Wiring Diagram For MT1-3/4: Wiring Diagram For MT-3 MT-4: Red:Power +/Black: GND(-)/Orange: ACC Red:Power +/Black: GND(-)/Orange: ACC/ Yellow:Cut oil...
- Page 3 Please insert a SIM card support GSM/GPRS network into the slot. Wiring Diagram For R1: 1.SMS Tracking Red:Power +/Black: GND(-)/Blue&Green/ :Cut oil Text the number g1234 to the gps tracker sim phone number, gps tracker will reply a google maps locationa link.you will receive a Google Maps link of position, when sending message “g1234”...
- Page 4 Set APN by following steps. apn123456 web.gprs.mtnnigeria.net Every sim card carrier has own APN content, contact carrier directly to get their APN, or check sim card apnuser123456 web carrier on internet or put sim card into cell phone to find out APN. apnpasswd123456 web Gps Tracker default password:123456 2.1 WEBSITE TRACKING.(Operate from the computer platform)
- Page 5 2.1.3 Add device ID and vehicle information Select JH134 for VT600X and VT1000 devices. Name:Device name or license plate number If logging in using device ID: Device ID Password:default is Last four digits of ID(Please use this password, if you log in Device ID) 2.1.4 Insert a SIM card support GSM/GPRS network into the slot.Place GPS tracker in an open space without building obstruction, and connect the power supply.
- Page 6 2.2.1 Register on mobile phone.Click “Register” 2.2.4 Add Device Fill in the device ID, device name, phone card number in the device, etc., then click Add. Device ID: the digits number on the device See below 2.2.2 Register login group user name via yourself,you can manage multi-devices in one account. Fill in the login user name, password.
- Page 7 Device Type:If the ID is a 10 digit number and Hard Wired device, select JH195, and if the ID is a Command: FREQ,password,X 10 digit number and Portable device, select JH196. Eg: FREQ,123456,12 If the ID is 11 digits and the device is Hard Wired, select JT808, and if the ID is 11 digits Portable, Reply: SET OK select Jt156.
- Page 8 Why device color is yellow on platform Yellow means no valid gps signal, please put it in open area to get good gps signal Ascend Group Company Limited(i-Trac GPS) Why the location is not correct Please make sure you set ip port apn correct, and...
