RP REL6LED Installation Instructions

REL6LED
INSTALLATION INSTRUCTIONS
SELF-DIAGNOSTIC/SELF-TEST OPTION
SAVE THESE INSTRUCTIONS
1. When AC power is supplied to fixture, the unit will automatically initiate a self-test and self-diagnostic
test as follows:
(1) Verifies battery disconnection, charger board failure, lamps failure and transformer failure at every 5 seconds.
(2) 3 minute self-testing every month.
(3) 90 minutes self-testing on the 12th month of the year after installation.
2. Dual color LED lamp indicator shows the following status:
(1) Green color: ON/ Ready
Blinking: Testing
(2) Red color (Service Alert)
(3) Service Alert LED Code (Red color LED lamp indicator)
One blink ON/pause
Two blinks ON/pause
Three blinks ON/pause (4 seconds)
Four blinks ON/pause
Five blinks ON/pause
Six blinks ON/pause
CAUTION:
After solving the fault of emergency equipment, please press test button for 2 seconds without releasing to reset.
LED indicator will show green.
3. For manual test, press test button as follows:
Press test button once
Press test button twice
Press test button 3 times
Press test button 4 times
4. Remote Capacity for Self-Test Option (when applicable):
In order to connect remote lamp heads with self-diagnostics/self-testing option, please refer to the instruction on the next page.
(4 seconds) Battery is not connected
(4 seconds) Battery is shorted or battery voltage drops below acceptable level
Charger board circuit fault
(4 seconds) Transfer circuit fault
(4 seconds) Emergency lamp fault
(4 seconds) Remote head's emergency lamp fault (if installed)
(within 2 seconds) 30 seconds test
(within 2 seconds) 3 minutes test
(within 2 seconds) 30 minutes test
(within 2 seconds) 90 minutes test
