CAUTION: To reduce the risk of breakage, keep corner protectors on glass while installing.
Keep corner protectors for use in case future adjustments are needed.
Consult your local plumbing codes prior to installation.
Recommended Clearance Heights for Installation:
78 inches (198.1cm) or 62 inches (157.5cm)
Recommended Width for Installation:
48-inch enclosure:
46 - 48 inches (116.8 - 121.9 cm)
60-inch enclosure:
54-3/8 - 60 inches (138.1- 152.4 cm)
60-inch Tub door
INSTALLATION GUIDE
MODEL NUMBER
SD101-6076
SD101-4876
TD111-6060
48-inch Enclosure
1
60-inch Enclosure
Advertisement
Table of Contents
Summary of Contents for Elegant Furniture And Lighting Harlan SD101-6076
- Page 1 INSTALLATION GUIDE MODEL NUMBER SD101-6076 SD101-4876 TD111-6060 CAUTION: To reduce the risk of breakage, keep corner protectors on glass while installing. Keep corner protectors for use in case future adjustments are needed. Consult your local plumbing codes prior to installation. Recommended Clearance Heights for Installation: 78 inches (198.1cm) or 62 inches (157.5cm) Recommended Width for Installation:...
- Page 2 Tools Required ( Not Included ) Stud Finder 1/8" Drill Bit Closed-Toe Shoes 7/32" Tile Drill Bit 32 TPI 3" Deep Miter Box 3' Level or longer Metal File Cut Resistant Non-Slip Gloves 100% Silicone Sealant – Clear Tin Snips IMPORTANT: To install your shower door unit, you must: (1) completely read all instructions, warnings, cautions, and care and maintenance information;...
-
Page 3: Before You Start
BEFORE YOU START CAUTION: Risk of injury or product damage. During installation tempered glass should not come in direct contact with metal parts or hard surfaces (such as tile/concrete flooring) or it may shatter. Gaskets and bushings must always be used between glass and metal. CAUTION: Risk of injury or product damage. -
Page 4: Door Assembly
DOOR ASSEMBLY... -
Page 5: Parts Listing
PARTS LISTING PICTURE PART PART PICTURE DESCRIPTION DESCRIPTION Door Stopper St4x32 Top Rail P strip Bracket Glass to rail Handle connector Door glass Fixed Door Anti-Jump L Strip Glass Fixator St5x35 Rollers Door Guider Bottom Top rail Threshold hreshold End Cap... - Page 6 CAUTION To reduce the risk of breakage , which may result in personal injury, property damage or product failure, DO NOT set glass panels on a hard surface or on their edge. Measure the width of the shower room and mark W. Measure the size from the bottom of the The figure shows the installation fixed glass to the mounting hole and...
- Page 7 " " " Drill the holes at the same position on Install top rail bracket (#2 part) inner the left and right wall. And drill the hole cover plate on the left and right walls, on bottom threshold. and glass fixator (#6 part) inner cover plate on floor or shower base.
- Page 8 15 1 15 15 2 15 The door is on the right and the handle Fixed glass on the left and top rail (# hole is on the right. 17 part) mounting hole on the left. Please move the glass door into the enclosure before installing top rail (#17 part).
- Page 9 The fixed glass is on the left side. The fixed glass is on the left side. Glass-to-wall width Measure the glass-to-wall width and cut Installation of door guider (#7 part) is in length of threshold (#8 part) left and right direction according to shower door direction.
- Page 10 According to the mark position, drill Mark the center hole of door guider (#7 part) and threshold end cap (#9 hole and insert anchor. part). Tighten the screws and put the Place the door glass rollers (16# part) decorative cover. on top rail (#17 part).
- Page 11 Adjust the verticality of the door so that Install the Anti-jump (#14 part), the the glass sides are parallel to the wall. long one is outside. Pay attention to the direction. 1/32"-1/16" Adjust the Anti-jump (#14 part) to Install L-strip (#5 part) to the side appropriate clearance: 1/32"-1/16"...
- Page 12 Install P-strip (#11 part) on door glass. Adjust the position of door stopper (#1 part) so that roller (#11 part) on the door side is close to the wall. > 1" Adjust the position of the door stopper Installtion of handle (#12 part). (#1 part) to make the L-strip (5# part) Pay attention to the direction.
- Page 13 Complete: Apply a good quality mildew-resistant silicone along the connection of shower door and enclosure, make sure apply silicone on both inside and outside. NOTE: Allow 24 hours for the silicone to fully cure before using the shower. CAUTION: Do Not force the door panel to move as doing so may result in breakage and risk of injury. If the following steps do not resolve the associated symptoms or for any questions, contact retailer for assistance.
