Schiit Loki Mini+ Owner's Manual page 3

OPERATION
1 Bass Adjustment. (20Hz) Turning the
knob clockwise increases bass, turning it
counter-clockwise decreases bass. Like all
the adjustments on Loki, it has a gradual
effect when first turned off of the center
position, for subtle adjustments.
2 Midbass Adjustment. (400Hz) As before, clock-
wise increases, counter-clockwise decreases.
3 Midrange Adjustment. (2kHz) You've got the
clockwise/counterclockwise thing now, right?
1 2
4 Treble Adjustment (8kHz). Clockwise =
more, counterclockwise = less.
5 Bypass. Up = tone control active, down =
completely bypassed (only a relay and resistor
in the signal path.)
Note: when Loki Mini+ is turned off it is
technically bypassed, but the unpowered
input may cause distortion in some systems.
Best to turn it on and switch it to bypass the
tone controls.
3
LOKI MINI+
26000001
ASSEMBLED IN USA
4
5
