CONDTROL Beton Pro User Manual

Concrete strength tester
EN Beton Pro
Congratulations on your purchase of concrete strength tester Beton Pro CONDTROL.
Safety instructions should be carefully read before you use the product for the first
time.
SAFETY REGULATIONS
Attention! This user manual is an integral part of your device. The user manual should
be read carefully before you use the product for the first time. If the product is given
to somebody for temporary use, be sure to enclose user manual to it.
- Do not misuse the product.
- Store the instrument beyond reach of children and unauthorized people.
- It is prohibited to disassemble or repair the device by yourself. Entrust repair to
qualified personnel and use original spare parts only.
- Do not use the instrument in explosive environment, close to flammable materials.
- Avoid heating the batteries to avoid the risk of explosion and electrolyte leakage.
In case of liquid contact with skin, wash it immediately with soap and water. In case of
contact with eyes, flush with clean water during 10 minutes and consult a healthcare
practitioner.
INTENDED USE
Concrete strength tester Beton Pro CONDTROL is intended to determine strength of
concrete using non-destructive shock pulse method for carrying out quality control
and inspection of buildings and structures.
The operating principle is based on shock pulse method, i.e. correlation dependence
of concrete strength on the voltage of the sensor transducer sensitive element.
Types of controlled materials:
- Lightweight concrete;
- Heavy concrete;
- Brick.
Main application area: determination of strength, uniformity and workability of
various building materials during their production and use, as well as during the
inspection of structural elements and buildings.
TECHNICAL SPECIFICATIONS
Strength measuring range
Accuracy
Smallest unit displayed
Continuous working time
Memory
Power supply
Operating conditions:
- air temperature
- relative air humidity
Dimensions
Weight
DELIVEERY PACKAGE
1 Concrete strength tester – 1 pc.
2 Grinding stone – 1 pc.
3 Strength reference – 1 pc.
4 Battery (1.5V АА) – 2 pcs.
5 Pouch – 1 pc.
6 User manual – 1 pc.
7 Plastic case – 1 pc.
PRODUCT DESCRIPTION
1 Sensor (striker)
2 Trigger
3 Display
4 Keyboard
User manual
5 Battery cover
Display
1 Impact direction
2 Type of material
3 Measurement results output line 3 Measurement results output line
4 Coefficient of coincidence 4 Coefficient of coincidence
5 Measuring unit
6 Battery charge level
1
4
Keyboard
3,5...99,9 MPa
F2
±7%
0,1 MPa
F1
25 hours
500 values
2 x 1,5V AA LR6
-5°С ...+40°С OPERATION
≤80%
Install/replace the batteries
Install the batteries in the battery compartment observing correct polarity. Use
205*60*175 mm
AA alkaline batteries. All batteries must be made by the same brand and have equal
600 g
charge level. The battery charge level is shown on the display.
Replace batteries when you see
Switch on/off
Switch on: press F1.
Switch off: press and hold F1 for 2 sec.
Select the material type
Press F4 to select the material: heavy concrete, lightweight concrete, brick.
1
2
6
2
3
5
Button Button Short press Long press
Switch on the device / Switch off the
F1 F1
statistics device
F2 F2
F3
Material type Memory
F3 F3
Impact direction Measuring unit
F4
Coefficient of
F4 F4
Language
coincidence
symbol on the display.
Select the measuring unit
Press F3 to select the measuring unit: kg/cm
Change the coefficient of coincidence
4
Press F4 in measuring mode Enter coefficient of coincidence mode
Press F3 or F4 Decrease/increase coefficient of coincidence
3
Press F2 Cancel changes and exit to measurement mode
Press F1 Save changes and exit to measurement mode
Coefficient of coincidence application
Coefficient of coincidence is intended to correct measurements of the device.
Coefficient of coincidence is set 1,00 by default, range of accepted values varies from
0,5 to 1,5.
It is recommended to change coefficient of coincidence when testing materials of a
5
similar type with a slight (±10 MPa) strength variation.
Changing of the coefficient value is carried out by the method of approximation
(decreasing or increasing) to the reference value of the tested samples.
It is recommended to obtain reference value by means of determination of concrete
compressive strength.
Impact direction
The impact direction is set automatically when the device is switched on. Press F3 to
disable automatic selection of impact direction.
Press F3 to select the desired impact direction:
Memory
The averaged measuring results are stored in memory mode.
Press and hold F2 View measuring results
in measuring mode
Press F3 or F4 Flip through measuring results
Press F2 Change measuring unit
Press F1 Exit memory mode
Language
Press and hold F4 Select the language: Russian, German, English.
in measuring mode
, n/mm , PSI, MPa.
2 2
