Summary of Contents for scafom-rux RINGSCAFF
- Page 1 RINGSCAFF | PERMANENT ADVANCED GUARDRAIL (PAG) RINGSCAFF PERMANENT ADVANCED GUARDRAIL INSTRUCTIONS FOR ASSEMBLY AND USE STRONGER. TOGETHER.
-
Page 2: Table Of Contents
T +31 (0) 495 497 204 · INFO@SCAFOM-RUX.COM LIST OF CONTENTS Introduction Assembly and dismantling of the scaffolding Inspection before assembly Assembly procedure (according to Assembly and User Manual RINGSCAFF)) RINGSCAFF Use of the scaffolding Dismantling procedure Stacking and transport... -
Page 3: Introduction
1.2.2 Position the standard lead-off adapter on the base jack (see Figure 1.1) and use wooden proceed to the next scaffold level. The RINGSCAFF system has various solutions for this side boards under the base plate of the base jacks to distribute the loads across the ground. - Page 4 Figure 1.5 1.2.8 Place the RINGSCAFF PAG (in folded state) with the hooks of the short standard in the ledger holes of the rosette at an angle of approximately 45 degrees. First the lower hook and then the upper hook (see figures 1.6.1 to 1.6.3).
- Page 5 T +31 (0) 495 497 204 · INFO@SCAFOM-RUX.COM 1.2.9 Start unfolding the RINGSCAFF PAG by holding the long standard. Then position first the lower hook of this standard and then the upper hook in the rosettes of the opposite standard of the bay of the scaffold (see figure 1.7.1 to 1.7.3).
- Page 6 RINGSCAFF | PERMANENT ADVANCED GUARDRAIL (PAG) INSTRUCTIONS FOR ASSEMBLY AND USE T +31 (0) 495 497 204 · INFO@SCAFOM-RUX.COM 1.2. 1 0 Similarly, place the RINGSCAFF PAGs for shorter lengths at the ends of the scaffold (see figures 1.8.1 to 1.8.3). Figure 1.7.3 The RINGSCAFF PAG is prevented from lifting up by a bottom hook with a flattened end on Figure 1.8.1...
- Page 7 1.2.11 Place steel decks/ladder platforms on the first lift level from below. Then proceed to the secured first level and place the toe boards (see figure 1.9). Figure 1.10 1.2.13 Position the next set of RINGSCAFF PAGs (see figure 1.11) and repeat steps 1.2.8 to 1.2.10. Figure 1.9 Status:...
- Page 8 Figure 1.11 Figure 1.12 1.2.14 The steel decks, (ladder) platforms and toe boards can now be positioned for the second 1.2.15 Place anchoring according to paragraph 6.1 from the RINGSCAFF Assembly and User Manual. level (see figure 1.12). Status: Status:...
-
Page 9: Use Of The Scaffolding
■ figures 1.13 and 1.14). Dismantling procedure The following operations and checks form the basis for safe dismantling of the RINGSCAFF scaffolding system: Figure 1.13 All platforms must be free of loose material. The scaffold is to be inspected to ensure that ■... -
Page 10: Stacking And Transport
RINGSCAFF | PERMANENT ADVANCED GUARDRAIL (PAG) INSTRUCTIONS FOR ASSEMBLY AND USE T +31 (0) 495 497 204 · INFO@SCAFOM-RUX.COM STACKING AND TRANSPORT Stacking procedure 2.1.1 The stacking starts with positioning the first placed PAG against the vertical standards of the scaffold rack (see figure 2.1). - Page 11 RINGSCAFF | PERMANENT ADVANCED GUARDRAIL (PAG) INSTRUCTIONS FOR ASSEMBLY AND USE T +31 (0) 495 497 204 · INFO@SCAFOM-RUX.COM 2.1.4 An additional guardrail can be placed on each guardrail of the first level (see figure 2.5). In total, 50 PAGs can be stacked on a scaffold rack (see figure 2.6).
-
Page 12: Notes
RINGSCAFF | PERMANENT ADVANCED GUARDRAIL (PAG) INSTRUCTIONS FOR ASSEMBLY AND USE T +31 (0) 495 497 204 · INFO@SCAFOM-RUX.COM NOTES Status: Status: 07/2024 07/2024 WWW.SCAFOM-RUX.COM... - Page 13 RINGSCAFF | PERMANENT ADVANCED GUARDRAIL (PAG) MODULAR SCAFFOLDING FAÇADE SCAFFOLDING WEATHER PROTECTION BUILDING SITE PROTECTION PROPS ACCESSORIES IDEAS WWW.SCAFOM-RUX.COM STRONGER. TOGETHER. Scafom Holding B.V. De Kempen 5 · 6021 PZ Budel The Netherlands T. +31 (0) 495 497 204 E. info@scafom-rux.com...
