Welcome to the Firefly family! Our top priority is to give you the best experience and value from your
purchase. Please read carefully through the manual to enjoy your new Firefly product.
CAUTION
For your safety, read the manual and safety instructions before installing the fixture. Install and
use the product strictly according to instructions.
SAFETY INSTRUCTIONS AND NECESSARY INFORMATION
• Installation should be done by a fully qualified electrician or technician.
• Carefully unpack the product and check for any damage prior to installation.
• Power should be cut-off before installation, maintenance or inspection.
• Do not use product aside from its intended use.
• Do not use chemicals and other materials that may harm the product. When cleaning, use a
damp-dry cloth.
• Do not use near flammable and explosive materials.
• Do not use the product as cover in any manner.
• Do not look directly to the light source for a long period of time as it may harm your eyes.
• Operating voltage: 220-240V AC 50/60Hz. Operate the product within the specified voltage
range.
• Manufacturer will not be held responsible for defects that may occur in case of
incompatibility. Defects caused by this will not be considered under warranty.
• If the external flexible cable or cord is damaged, the manufacturer or his service agent or a
similarly qualified person shall exclusively replace it.
• Contact the manufacturer or his service agent or a similarly qualified person if the product
fails to function as stated on the packaging or the manual.
• Safekeeping a copy of this manual is encouraged.
Item Code
EDL212707DL
EDL212707WW
EDL212712DL
EDL212712WW
TECHNICAL SPECIFICATIONS
Power
Color Temperature
7 Watts
Daylight (6500K)
7 Watts
Warm White (3000K)
Daylight (6500K)
12 Watts
Warm White (3000K)
12 Watts
B
Cut-out size
USER MANUAL
Lumens (Lm)
784
760
1575
1300
Operating Voltage
Life Hours
CRI
Beam Angle
*This lamp can operate within a voltage range of 220-240V AC 50/60Hz.
LOW GLARE
LED DOWNLIGHTS
Dimensions
(a x b mm)
76 x Ø 120
76 x Ø 120
88 x Ø 160
88 x Ø 160
: 230V AC 50/60Hz
: 25,000 Hours
: >85
: 36°
Cut-Out Size
Ø 105
Ø 105
Ø 145
Ø 145
Advertisement
Related Manuals for Firefly BASIC EDL212707DL
Summary of Contents for Firefly BASIC EDL212707DL
- Page 1 LOW GLARE LED DOWNLIGHTS Welcome to the Firefly family! Our top priority is to give you the best experience and value from your purchase. Please read carefully through the manual to enjoy your new Firefly product. USER MANUAL CAUTION For your safety, read the manual and safety instructions before installing the fixture. Install and use the product strictly according to instructions.
- Page 2 INSTALLATION GUIDELINE Insert Hole Turn OFF the power. Carve a hole on the ceiling according to the cut-out dimension of the LED Downlight. Wire Ceiling Insert the supply wires (220-240V) into the terminal block and check for any loose connection and then use an insulating tape to protect the connection on the terminal block.
