STRANDS SIBERA XP SR Manual

RED: + High beam
BLACK: (-) Negative
GREY: Signal wire connect to +(VDC)
WHITE: +White position light
YELLOW: +Yellow position light
Hello Function:This function is activated by flashing the high beams twice
within 2 seconds. To use this mode, ensure a position light wire is connected.
When you start the LED bar for the first time, it is set to Xperience mode.
To switch back to E-mode, turn off the high beam for 5 seconds, let the high
-
beam run for 2 seconds, then flash the high beam 3times within 5 seconds.
To switch to Xperience mode, turn on the high beam for 2 seconds, then flash
-
the high beam 3 times within 5 seconds.
(Can be connect with aux switch,
canbus solution or wirelss controller)
Alternative for signal connection :
It can be connected with an AUX switch, CANBUS
solution with signal wire, By connecting signal wire
with original cable with car main high beam, or a
wireless controller with 12-24v system.
(Part No.809412,809413,809414,809415,809416,809417,809418,809419)
*25A fuse for above articles , 2.5m cable, Hello function
MANUAL
SIBERA XP SR/SRC LED BAR
Contact us if you need support: support@strands.se or +46(0)320-450450
(Length for SR/SRC version
304.7mm-1273.7mm)12"-50"
