Access & Power Integration
Trove2AG2
- Trove2 enclosure with Altronix/AMAG M4000 backplane (TAG2)
TAG2
- Altronix/AMAG M4000 backplane only
Trove2AM2
- Trove2 enclosure with Altronix/AMAG M2150 backplane (TAM2)
TAM2
- Altronix/AMAG M2150 backplane only
Trove3AM3
- Trove3 enclosure with Altronix/AMAG M2150 / M4000 backplane (TAM3)
TAM3
- Altronix/AMAG M2150 / M4000 backplane only
Installation Guide
All registered trademarks are property of their respective owners.
Rev. TAMAG122418
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
SIGNALING

Advertisement

loading
Need help?

Need help?

Do you have a question about the AMAG Trove2AM2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for G4S AMAG Trove2AM2

  • Page 1 SIGNALING Access & Power Integration Trove2AG2 - Trove2 enclosure with Altronix/AMAG M4000 backplane (TAG2) TAG2 - Altronix/AMAG M4000 backplane only Trove2AM2 - Trove2 enclosure with Altronix/AMAG M2150 backplane (TAM2) TAM2 - Altronix/AMAG M2150 backplane only Trove3AM3 - Trove3 enclosure with Altronix/AMAG M2150 / M4000 backplane (TAM3) TAM3 - Altronix/AMAG M2150 / M4000 backplane only Installation Guide...

  • Page 2: Specifications

    Overview: Trove2AG2/Trove2AM2 and Trove3AM3 accommodates AMAG boards with or without Altronix power supplies and sub-assemblies for access systems. Specifications: Trove2AG2 - Trove2 enclosure with TAG2 Altronix/AMAG M4000 backplane Trove2AG2 accommodates a combination of the following: • Altronix Modules: - Up to two (2) eFlow4NB, eFlow6NB, eFlow102NB, eFlow104NB or PoE201. - One (1) NetWaySP4B.

  • Page 3: Agency Listings

    Agency Listings: • UL 294 - 6th edition: Line Security I, Destructive Attack I, Endurance IV, Stand-by Power II*. * Stand-by Power Level I if no battery is supplied. • This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme á la norme NMB-003 du Canada. •...
  • Page 4 TAG2: Configuration of Altronix Power Supply and/or Sub-Assembly Boards and AMAG M4000 Boards 1. Fasten spacers (provided) to pems that match the hole pattern for Altronix power supply/chargers and sub-assemblies (Fig. 2, pg. 4). Fasten metal spacers in the correct locations to provide proper grounding, see below (Fig. 2, pg. 4). Fasten spacers (provided) to pems that match the hole pattern for AMAG M4000 modules.
  • Page 5 TAM2: Configuration of Altronix Power Supply and/or Sub-Assembly Boards and AMAG M2150 Boards 1. Fasten spacers (provided) to pems that match the hole pattern for Altronix Power Supply/Chargers or Altronix Sub-Assembly boards (Fig. 3, 3a, pg. 5). Fasten metal spacers in the correct locations to provide proper grounding, see below (Fig. 3, pg. 5). 2.
  • Page 6 TAM3: Configuration of Altronix Power Supply and/or Sub-Assembly Boards and AMAG M2150 / M4000 Boards 1. Fasten spacers (provided) to pems that match the hole pattern for Altronix power supply/chargers and sub-assemblies (Fig. 4, pg. 6). Fasten metal spacers in the correct locations to provide proper grounding, see below (Fig. 4, pg. 6). Fasten spacers (provided) to pems that match the hole pattern for AMAG boards.
  • Page 7 Notes: Trove2AG2 / Trove2AM2 / Trove3AM3 Installation Guide - 7 -...
  • Page 8 eFlow Power Supply/Chargers can be Controlled and Monitored while Reporting Power/Diagnostics from Anywhere over the Network... LINQ2 - Network Communication Module LINQ2 provides remote IP access to real-time data from eFlow power supply/chargers to help keep systems up and running at optimal levels. It facilitates fast and easy installation and set-up, minimizes system downtime, and eliminates unnecessary service calls, which helps reduce Total Cost of Ownership (TCO) - as well as creat- ing a new source of Recurring Monthly Revenue (RMR).
  • Page 9 TAG2 / TAM2 Dimensions 25.375” x 19.375” x 0.3125” (644.5mm x 482.6mm x 7.9mm). 19.375” (492.1mm) 2.2” (55.9mm) 2.2” (55.9mm) 0.156” ( 3.96mm) 1.0” (25.4mm) 1.0” (25.4mm) 7.5” (190.5mm) 7.5” (190.5mm) 9.2” (233.7mm) 9.2” (233.7mm) Trove2AG2 / Trove2AM2 / Trove3AM3 Installation Guide - 9 -...
  • Page 10 Trove2 Enclosure Dimensions (H x W x D approximate): 27.25” x 21.75” x 6.5” (692.15mm x 552.5mm x 165.1mm) 21.50” (546.1mm) 2.00” (50.8mm) 2.00” (50.8mm) 5.25” (133.35mm) 3.5”(88.9mm) 3.5”(88.9mm) 5.25” (133.35mm) 0.685” (17.4mm) 1.25” Knockouts 0.5625” (14.3mm) (31.8mm) 1.77” 1.125” (28.3mm) (45mm) 2.415”...
  • Page 11 TAM3 Dimensions 34” x 28” x 0.3125” (863.6mm x 711.2mm x 7.9mm) 28” (711.2mm) 2.5” (63.5mm) 0.156” ( 3.96mm) 1.0” (25.4mm) 1.0” (25.4mm) 13.5” 13.5” (342.9mm) (342.9mm) Trove2AG2 / Trove2AM2 / Trove3AM3 Installation Guide - 11 -...
  • Page 12 Trove3 Enclosure Dimensions (H x W x D approximate): 36.12” x 30.125” x 7.06” (917.5mm x 768.1mm x 179.3mm) 2.00” (50.8mm) 7.12” (222.3mm) 9.5” (241.3mm) 9.5” (241.3mm) 1.25” (31.8mm) 1.55” (39.4mm) 1.78” (45.2mm) 1.07” 30.12” (768.1mm) (27.2mm) 2” (50.8mm) 1.25” (31.8mm) 14.01”...
