111-56-URM-003
TrueOrder KDS Multi-Station
Quick Start Guide
About this Guide
This guide contains instructions for a new user to setup, configure, and use the Epson TrueOrder
KDS in a few steps. It is targeted towards the Multi Station KDS connected to the POS via ethernet
and assumes that the POS is already supported by TrueOrder KDS.
TrueOrder KDS is very versatile – able to be customized in many ways to meet the specific needs
of the individual display stations and the entire kitchen. This guide describes one such use case –
setting up a 2-station system, with one station being the Kitchen Display and the other being the
Expeditor. This guide is applicable to:
EPSON is a registered trademark and EPSON is a registered logomark of Seiko Epson Corporation. All other product and brand names
are trademarks and/or registered trademarks of their respective companies. Epson disclaims any and all rights in these marks.
Copyright 2024 Seiko Epson Corporation.
TrueOrder KDS Multi-Station
111-56-URM-003
Quick Start Guide
R3.20
Page 1 of 17
Form: F-730-028 v1.00
Trademarks

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 111-56-URM-003 and is the answer not in the manual?

Questions and answers

Related Manuals for Epson 111-56-URM-003

Summary of Contents for Epson 111-56-URM-003

  • Page 1 Expeditor. This guide is applicable to: EPSON is a registered trademark and EPSON is a registered logomark of Seiko Epson Corporation. All other product and brand names are trademarks and/or registered trademarks of their respective companies. Epson disclaims any and all rights in these marks.

  • Page 2: Table Of Contents

    3. Configuring the KDS using Configurator ..............6 Appendix A ........................16 Bumping an Entire Order ........................16 Appendix B ........................17 Layout Ticket Configuration ......................... 17 TrueOrder KDS Multi-Station 111-56-URM-003 Quick Start Guide R3.20 Page 2 of 17 Form: F-730-028 v1.00 Trademarks...

  • Page 3: System Requirements

    1. System Requirements Setting up a Multi Station Epson TrueOrder KDS as per this guide requires the following equipment: • Any 2 KDS devices from the list below: o MicroTouch IC-215P-AA2 All-in-One touchscreen o MicroTouch MP-000-AA2 controller box + 1080p HDMI screen + bumpbar...

  • Page 4: Setting Up A Multi Station Kds

    “Demo Device” and flashing “DEMO DISPLAY” (identified by the red box in Picture 2.1) indicate KDS is in a default, parser-less demo mode. Picture 2.1 TrueOrder KDS Multi-Station 111-56-URM-003 Quick Start Guide R3.20 Page 4 of 17 Form: F-730-028 v1.00...
  • Page 5 This default parser-less demo mode can help users verify the communication between POS and KDS device. User must configure the KDS system to enable its various features. The following sections describe the procedures to correctly configure the KDS system. TrueOrder KDS Multi-Station 111-56-URM-003 Quick Start Guide R3.20 Page 5 of 17 Form: F-730-028 v1.00...

  • Page 6: Configuring The Kds Using Configurator

    Using a browser, access the Configurator at http://xxx.xxx.xxx.xxx (IP address of the device). The default username is epson.admin.all@epson.epson, and the default password is 123456. Picture 3.1 Below steps describe the procedure to configure a typical 2 device Multi Station system: One device is a Kitchen display and the second is an Expeditor station.
  • Page 7 Picture 3.3 3. Click “SEARCH”. Picture 3.4 4. Multiple KDS devices will be discovered, click on the device you want to configure. Picture 3.5 TrueOrder KDS Multi-Station 111-56-URM-003 Quick Start Guide R3.20 Page 7 of 17 Form: F-730-028 v1.00 Trademarks...
  • Page 8 “POS Connected Device” (Described in Step 4). 6. Click “DEVICE CONFIG” again, the “Kitchen” device will show. Click “ADD NEW DEVICE”. Picture 3.7 TrueOrder KDS Multi-Station 111-56-URM-003 Quick Start Guide R3.20 Page 8 of 17 Form: F-730-028 v1.00...
  • Page 9 8. Select the next device you want to configure. Picture 3.9 9. Configure the name of the device to “Expo”, then click “Save”. Picture 3.10 TrueOrder KDS Multi-Station 111-56-URM-003 Quick Start Guide R3.20 Page 9 of 17 Form: F-730-028 v1.00...
  • Page 10 2. Set name as “Kitchen” and select “KITCHEN DEFAULT TICKET”, then click “SAVE”. Picture 3.12(a) Scroll the page down to show the rest of configuration. Picture 3.12(b) Lower half of page TrueOrder KDS Multi-Station 111-56-URM-003 Quick Start Guide R3.20 Page 10 of 17 Form: F-730-028 v1.00 Trademarks...
  • Page 11 3. Click “LAYOUT”, the “Kitchen” layout should show. Click “ADD NEW LAYOUT” . Picture 3.13 Set name as “Expo” and select “KITCHEN DEFAULT TICKET”, then click “SAVE”. Picture 3.14 TrueOrder KDS Multi-Station 111-56-URM-003 Quick Start Guide R3.20 Page 11 of 17 Form: F-730-028 v1.00 Trademarks...
  • Page 12 2. Set name as “Kitchen”, station type as “KITCHEN”, select associated layout “Kitchen”, scroll down to select associate device “Kitchen”, then click “Save”. Picture 3.16 TrueOrder KDS Multi-Station 111-56-URM-003 Quick Start Guide R3.20 Page 12 of 17 Form: F-730-028 v1.00...
  • Page 13 4. Set name as “Expo”, station type as “EXPEDITOR”, select associate layout “Expo”, scroll down to select associate device “Expo”, then click “Save”. Picture 3.18 TrueOrder KDS Multi-Station 111-56-URM-003 Quick Start Guide R3.20 Page 13 of 17 Form: F-730-028 v1.00...
  • Page 14 ▪ Set Current KDS Time: Allows the clock on the KDS display to be set to the same time as the configurator device. TrueOrder KDS Multi-Station 111-56-URM-003 Quick Start Guide R3.20 Page 14 of 17 Form: F-730-028 v1.00...
  • Page 15 • Step 5: Publish the Configuration Settings Click “PUBLISH” and confirm with “YES” to apply the settings to system. Picture 3.20 TrueOrder KDS Multi-Station 111-56-URM-003 Quick Start Guide R3.20 Page 15 of 17 Form: F-730-028 v1.00 Trademarks...

  • Page 16: Bumping An Entire Order

    0-9 for ones digit. Note: There are other keys for other functionality on the bump bar that is beyond the scope of this guide. TrueOrder KDS Multi-Station 111-56-URM-003 Quick Start Guide R3.20 Page 16 of 17 Form: F-730-028 v1.00...

  • Page 17: Layout Ticket Configuration

    ▪ Item Font Size - Adjust the font size for the order lines displayed in each tile. ▪ Line Spacing – Adjust line spacing between order lines in each tile. TrueOrder KDS Multi-Station 111-56-URM-003 Quick Start Guide R3.20 Page 17 of 17 Form: F-730-028 v1.00...
