How to Connect Your Push3 Gateway to a SFTP Server
To connect to your Gateway UI, use its IP. Find it by logging into your
account, navigate to your Gateway MAC Address on the left-hand side, and click on the displayed
IP (e.g., LAN IP: 192.168.0.3) under 'LAN IP':
Log into your Gateway UI, navigate to Settings > SFTP/Archive, and select Enable SFTP. Next, you
will find explanations on how to connect using either User/Password or Perform client authentication
using public/private key.
For our example server, the login details are as follow:
Host: 192.168.0.10
User: test
Password: Test123
Using User/Password Authentication
If you only have the IP, username, and password of your remote server where you want to save
your files, you can fill them into the corresponding inputs, like this::
Host: 192.168.0.10
User: test
Password: Test123
Finally, press the 'Apply' button to save the filled configurations.
https://api.ekmpush.com/
Advertisement
Summary of Contents for EKM Push3
- Page 1 How to Connect Your Push3 Gateway to a SFTP Server To connect to your Gateway UI, use its IP. Find it by logging into your https://api.ekmpush.com/ account, navigate to your Gateway MAC Address on the left-hand side, and click on the displayed IP (e.g., LAN IP: 192.168.0.3) under 'LAN IP':...
- Page 2 You have to wait for at least 15 minutes to check if the data has been successfully saved to the server. Using a Private Key for Authentication If you already have experience with Private/Public Keys and don't need to follow the next steps because you already have your own Private Key, select Perform client authentication using public/ private key.
- Page 3 Enter file in which to save the key (/home/myLaptop/.ssh/id_rsa):(Simply press ENTER) Enter passphrase (empty for no passphrase): YOUR_SECURE_PASSWOR_HERE Enter same passphrase again:REPEAT_YOUR_SECURE_PASSWOR_HERE Your identification has been saved in /home/myLaptop/.ssh/id_rsa Your public key has been saved in /home/myLaptop/.ssh/id_rsa.pub The key fingerprint is: SHA256:iB5mwc8jFw7jeb31tNWlp2OLKsosDoS1OzWuThNkzLM myLaptop@myLaptop The key's randomart image is: +---[RSA 3072]----+ o_ o .
- Page 4 You have to wait for at least 15 minutes to check if the data has been successfully saved to the server. Create your Private Key in Windows using putty You can create your Private Keys on your Windows computer by following these instructions: 1.
- Page 5 4. After selecting these two options, press the 'Generate' button, and then move your mouse over the blank area. 5. You should see something similar to:...
- Page 6 6. Select and copy the entire box that says: Public key for pasting into OpenSSH authorized_keys files. Paste it in your remote server on: ~/.ssh/authorized_keys 7. If you want to enhance the key security by adding a passphrase (password), enter the passphrase in the provided input:...
- Page 7 8. Export your Private Key: Go to Conversions > Export OpenSSH Key and save it in a secure place. 9. Finally, copy the content of your converted Private Key and paste it into the Gateway UI (in this example, we are using 192.168.0.3). Navigate to Settings > SFTP/Archive and select Enable SFTP.
- Page 8 You have to wait for at least 15 minutes to check if the data has been successfully saved to the server.
